General : GSM 850/900/1800/1900 MHz, UMTS 900/2100 MHz, HSDPA 7.2 Mbps
Form factor : Touchscreen bar phone
Dimensions : 112.4 x 59.9 x 11.5 mm, 113 g
Display : 3.5" 16M-color TFT capacitive touchscreen, 320 x 480 pixels (HVGA)
CPU : Qualcomm QCT MSM7227-1 Turbo 800 MHz processor
Memory : 158MB storage, microSD card slot, 278MB RAM
Operating System : Android OS, v2.2 Froyo
Camera : 5 megapixel auto-focus camera with face detection; QVGA video recording
Connectivity : Wi-Fi b/g/n, Bluetooth 2.1 with A2DP, standard microUSB port, GPS receiver with A-GPS, 3.5mm audio jack, FM radio
Misc : TouchWiz 3.0 UI, built-in accelerometer, multi-touch input, proximity sensor, Swype text input

Other Information From Phone Arena
Other Information From GSM Arena

Unofficial Thread (1219 Replies, Created By Calex @ Feb 21 2011, 02:34 PM)
♠ Samsung Galaxy Ace ♠
Official Thread V1 (2546 Replies, Created By xDragonZ @ Mar 10 2011, 10:58 PM)
♠ Samsung Galaxy Ace S5830 ♠ Official Thread V1
Offical Thread V2 (2505 Replies, Created By stupiak07 @ Apr 15 2011, 07:52 PM)
♠ Samsung Galaxy Ace S5830 ♠ Official Thread V2

Original Samsung Malaysia Electronics (SME) : RM 999 [1 Year warranty]
Original SenQ / SengHeng : RM 899 [Up to 3 Years warranty, up to 36 months 0% interest installment plan
Original from LYN seller : RM795 onwards [Cash, 1 Year warranty]

*#*#4636#*#* - Phone Information
*2767*3855# - Hard Reset
*#*#7780#*#* - Factory Reset
*#*#7594#*#* - Change End Call/Power Option
*#*#197328640#*#* - Service Mode
*#*#273283*255*663282*#*#* - File Copy Screen (Backup Media Files)
*#*#526#*#* - WLAN Test
*#*#232338#*#* - Shows WiFi MAC address
*#*#1472365#*#* - GPS Test (eclair)
*#*#3214789650#*#* - GPS Test (froyo)
*#*#1575#*#* - Another GPS test
*#*#232331#*#* - Bluetooth test
*#*#232337#*# - Shows Bluetooth device address
*#*#8255#*#* - GTalk Service Monitor

Codes to launch various Factory Tests:

*#*#0283#*#* - Packet Loopback
*#*#0*#*#* - LCD test
*#*#0673#*#* - Melody test
*#*#0842#*#* - Device test (Vibration test and BackLight test)
*#*#2663#*#* - Touch screen version
*#*#2664#*#* - Touch screen test
*#*#0588#*#* - Proximity sensor test
*#*#3264#*#* - RAM version

Codes to get Firmware version information:

*#*#4986*2650468#*#* - PDA, Phone, H/W, RFCallDate
*#*#1234#*#* - PDA and Phone
*#*#1111#*#* - FTA SW Version
*#*#2222#*#* - FTA HW Version
*#*#44336#*#* - PDA, Phone, CSC, Build Time, Changelist number
Source from XDA

1.How to take Screenshot ?
Ans: press back + menu button

2. Factory Reset
Ans: Please Refer to post #1 under Samsung Phone Secret Code

3. Forwarding SMS
Ans: Press(2 seconds) the message that u wanted to forward and a menu will pop out and choose forward

4. How to Set Ringtone/Notification/alarm tone
Please refer to here http://forum.lowyat.net/topic/1213449

5. It is Corning Gorilla Glass for SGA?
Ans: Yes, but doesn't mean it's scratch proof

6. Since SGA has Corning Gorilla glass. Does it need a Screen Protector film?
Ans: It is recommended to has a Screen Protector Film to protect the screen from scratch

7. Rooting/Unroot
Ans: Please refer post #2

8. Moving apps from phone to SD
Ans: Your phone need to rooted(which will void waranty temporary). Install Move2SD Enabler&App2SD free from Market to move application that on phone to SD card.

9. Charging phone/battery (how long to charge etc)
Ans : Approximately 1hours 30 minute - 2hours based on battery percentage on standby screen. some says 3 hours

10. Setting phone to MMS only without internet(to avoid unnecessary charge)
Ans: Please Refer to APN Section in post#1

11. Adding New Font for Galaxy
Ans: Go to Setting>Display>Font Style and press Get Font online to download

12. Installing application from apk file
Ans: go to market seach for apk installer or go to My Files to find your apk file location and install it

13. How to Update Firmware and what is current Latest Firmware.
Ans : Current lastest Firmware is S5830DXKC1 on 17/4/2011
Download Latest Kies from Official Samsung website and install it, by the time you connected your SGA device.
It will automatically check your firmware online, if your firmware is older version that it will inform you that your device need to download/install lastest firmware.

14. How to take out Micro SD/SDHC card from the phone?
Ans : You need to go to Menu Setting>SD card and phone storage to unmount the SD card before you removed it from your phone. Remove your Micro SD/SDHC card from your Micro SD card slot of your right side panel of your phone.

15. Does there anyway to solve Screen Of Death or so called SOD on android?
Ans : Currently none. But recommend to send it to samsung service center

16. How to Enable MMS only without Internet?
-go to setting>wireless network>mobiles network >Acess Point Names>choose XXXXX 3G MMS
-go to APN type and choose MMS only
-go to setting>wireless network>mobiles network >tick use packet data.

17. What is root?
Ans : (by stupiak07)
For short. rooting let you gain access administrator right that is locked by the phone company by default. by rooting let you able to modify the system which suppose to be locked to avoid people mess up the system and render it useless.
The most common thing for people to root it is for moving those app/games that can't be moved to memory card by default which.eat up main storage which is phone inner storage. some people wanted to used custom/personnel rom that suite their usage and even some people want to use custom theme for the phone. by right, for those don't know how to use it should avoid it as it will void your phone warrany if you mess up. You no need to root if you are a normal users. You also may unroot back when you want to claim waranty

Add on: even if you moved your application to your memory card doesn't mean will free up all the phone memory as there will be package data left over at phone memory for it to run.

This is what I know about rooting. it may vary from the actual info

The cause could be due to the connected WIFI under idle condition for long period with certain cheapo router (such as Aztech), but some SGA users no issue with Dlink provided by UNIFI and others brand... Either to pull out the battery to restart SGA or keep trying to long press power button for several times to restart SGA...

Solutions:
1. Disable WIFI while no in use
2. Recycle cheapo wifi router
3. Settings > Wireless & Newtwork > WIFI settings > Click on menu and go in "Advanced" > Set the WIFI sleep policy to never (Let me know it if SGA never SOD anymore with his method)

1) Home -> Menu -> Settings -> Wireless & networks -> Mobile networks -> Access Points Name
2) Menu -> New APN
Name : DiGi Internet
APN: diginet
MCC: 502
MNC: 16
APN Type: default
(Others, blank)

APN: digimms
username: mms
password: mms
Proxy: 203.092.128.160
Port: 80
MMSC: http://mms.digi.com.my/servlets/mms
MMS Proxy: 203.092.128.160
MMS Port: 80
MCC: 502
MNC: 16
APN Type: mms

1) Home -> Menu -> Settings -> Wireless & networks -> Mobile networks -> Access Points Name
2) Menu -> New APN
Name = Maxis(3G)
APN = unet
Username = maxis
MMSC = http://172.16.74.100:10021/mmsc
MMS proxy = 202.75.133.49
MMS port = 80
APN type = default,mms
(Others, leave blank)

1) Home -> Menu -> Settings -> Wireless & networks -> Mobile networks -> Access Points Name
2) Menu -> New APN
Name: Celcom3G MMS Combo
APN: celcom3g
Proxy: Not Set
Port: Not Set
Username: Not Set
Password: Not Set
Server: Not Set
MMSC: http://mms.celcom.net.my
MMS proxy: 10.128.1.242
MMS port: 8080
MCC: 502
MNC: 19
Authentication: Not Set
APN Type: Internet + MMS

1. Install Lastest Kies for Samsung Galaxy ACES5830 from samsung website into your pc
SAMSUNG GALAXY ACE S5830 Download page

2.Download and install SuperOneClick 1.7 by ShortFuse
SuperOneClick 1.7 by Sh0rtFuse of Xda

3. Unmount your sd card under setting>sdcard and phone storage setting>Unmount SD card and then remove it from your phone

4. Set your SGA into USB Debugging mode by ticking it USB debugging mode under Setting>Application>Developement>tick USB debugging mode

5.Run Kies and connect your SGA to your pc using the cable (for safety reason don't use bluetooth or other connectivity)


6.Once your Kies show that your SGA is connected to your pc, Extract SuperOneClick 1.70 into a folder using winrar.

7.Run SuperOneClick.exe as administrator.


8.Press Shell Root and the it will temporary root your phone and a small window will pop out
it shown
"Device has a temporary ADB root!
Reboot your device to remove it"

9 Click ok (don't need restart) and continue to press Root.

10. After finished root, it will pop a another small window called Test? and it will shown
Root files have been installed! Would you like to run a test? Press Yes

11. another pop out window will pop out and show "a su. blah blah blah...." Just press ok

12. and finally window will pop out title Rooted will shown

"Your device has been rooted!"
"Would you like to donate now?"
Press yes if you want donate or else press no

13. Unplugged and Reboot your SGA device.

Congratulation, Your SGA Device has been Rooted!

How to Check your device rooted or not?
Ans : Notice there will be a SuperUser in your menu

1. ASTRO File Manager
2. Barcode Scanner
3. Titanium Backup - need ROOT
4. Chrome to Phone
5. Gmote
6. SwipePad Beta
7. Dropbox.com for setting up account and Dropbox Android Apps
8. Shootme (for screen capture - need ROOT)
9. Handcent SMS
10. GO SMS
11. MyBackupRoot
12. Aldiko Book Reader
13. Skype
14. Dolphin Browser HD
15. WhatsApp
16. Lookout Mobile Security
17. Wheres My Droid
18. PULSE News Reader
19. Google Goggles
20. Maxis Movies
21. CamScanner
22. Knots Guide
23. Camera 360
24. Tiny Flashlight +LED
25. Photovault
26. QuickOffice
27. RingDroid (for cutting ringtones)
28. Super Call Faker
29. Super SMS Faker
30.TubeMate (for download youtube)
31. Super Task Killer
32. VPlayer Advanced (for playback video)

For rooted user (try at your own risk)
1. Market History cleaner
2. Market Enabler (for enabler to acess other countries market)
3. Market Enabler Code
4. Move2SD Enabler
5. Move2SD Pro / APP 2 SD free/Pro
6. SD increase

....still updating.....

1. Angry Birds
2. Angry Birds Seasons
3. Super Dynamite Fishing
4. Gun Bros
5. Grave Defense
6. Hungry Shark
7. Demon Hunter
8. Words With Friends
9. Zenonia RPG game RM15.09 also got free version available in market for try
10. Zenonia 2 RPG game RM15.09 also got free version available in market for try
11. Leave Devil Alone HD (seem like not available in market)
12.Guns 'n'Glory RM4.33 also got free version available in market but annoying ads
13.
.....still updating....

Flash from sd card = Clockworkmod
backup image of phone = nandroid backup (also provided by rom manager using recovery startup)
backup simcard = my backup pro
backup sdcard = just copy & paste (Ctrl A and Ctrl C then Ctrl P) your sdcard into PC
backup apps + saves = titanium backup (make sure u have the exact same version of whatever apps u r using previously when restoring saves)

1. Clear type - excellent on screen clarity and colour saturation but will attract more fingerprint.
2. Matte type - fingerprint resistant but will affect the screen clarity or colour. However some users mention the effect is tolerable so it is personal preference.
Note: Can purchase from antho1, about RM5 onwards

1. Silicone/TPU casing
2. Epik Case (can purchase from antho1, about RM12)
3. Perforated Mesh case (can purchase from lhongwuh in garage sale section)
4. Leather bag
5. IDEFENSE PRO & CARBON (you could get it from garage sales)
6. Nillkin

Herlan Satriandi - Yesterday 21:21 (edited Yesterday 21:22) - Public
Coderom (exlusive customROM with +Ketut Putu Kumajaya support)
Changelog:
CFRoot b80 (Official kernel from ketut.kumajaya for coderom)
BLNSupport (BLNControl free added - buy full version if you like it) with meesage notification (exclusive only for coderom version)
cifs.ko (windows share support) dan tun.ko (openVPN)
DT-A2SD
Baseband and Wi-fi modul based on XWKPN
Framework from XXKPH

(i will add later...i wanna pick my wife at her mom's house first)

How to Install?
Unzip the downloaded file.
Open ODIN,
Cooper.ops from KPH,
MODEM_S5830XWKP6_CL260130_CODEROM.tar in Phone and
CODE_S5830XXKPH_CL260130_CODEROM2X.tar in PDA
Leave APBOOT AND CSC blank.
