Useful Links for LC Owners :

King Of Moped 135 (KOM135)
Yamaha T135
Malaysian Bikers Community (MBC)
Moped Riders Community (MRC)

LYN 135LC Club V1
LYN 135LC Club V2

Whose name is not in the list, kindly PM me your model or just post in the thread.



This post has been edited by Are_keem: Dec 21 2009, 08:54 PM

Our Proud Ride!!

1. Spayz's ride :

2. xtreme_paranoid's ride :

3. charge-n-go's ride :

4. Are_keem's ride :

5. scoffer's ride :

6. kinwei3250's ride :

7. LilCroSs's ride :

8. samba18's ride :

9. UncleCheang's ride :

10. budakmentah's ride :


This post has been edited by Are_keem: Sep 3 2009, 06:13 AM

Our Proud Ride V2!!

11. Na0ki's ride :

11. DontdoDRUG's ride :


This post has been edited by Are_keem: Nov 9 2009, 04:45 PM

Tips to Improve Engine Performance

Minor mod (increase acceleration)
1. Remove air filter. (Penang people can find me, FOC)
2. Reset carburetor air-fuel setting. (Penang people can find me, FOC)
3. Set valve tapette to 10 IN and 15 OUT. - RM30 labour charge @ New Bee Hock motor, Penang.
4. Change to 15-40 with 415 chain. - RM100

Major mod
coming soon...


Tips to Improve Handling Performance
coming soon...


Sprocket Combination (Stock CDI)

acceleration + = increase by xx%
acceleration - = decrease by xx%

15-35 - 1st : 48kph, 2nd : 90kph, 3rd : 130kph, 4th : 180kph; acceleration - 10.0%
15-36 - 1st : 46kph, 2nd : 86kph, 3rd : 125kph, 4th : 175kph; acceleration - 7.8%
15-37 - 1st : 44kph, 2nd : 83kph, 3rd : 122kph, 4th : 169kph; acceleration - 5.1%
15-38 - 1st : 43kph, 2nd : 80kph, 3rd : 118kph, 4th : 160kph; acceleration - 2.6%

15-39 - 1st : 42kph, 2nd : 78kph, 3rd : 115kph, 4th : 155kph; acceleration no change

15-40 - 1st : 41kph, 2nd : 75kph, 3rd : 111kph, 4th : 151kph; acceleration + 2.6%
15-41 - 1st : 40kph, 2nd : 73kph, 3rd : 108kph, 4th : 148kph; acceleration + 5.1%
15-42 - 1st : 39kph, 2nd : 71kph, 3rd : 105kph, 4th : 144kph; acceleration + 7.8%
15-43 - 1st : 38kph, 2nd : 69kph, 3rd : 102kph, 4th : 140kph; acceleration + 10.0%

After changing racing CDI >> top speed for 4th gear can add about 10 - 20kph.

*Note* The above data is an estimation of potential top speed for each gear, and may vary from bike to bike.


Carburetor General Tuning Guideline:

A. Change the idle air-fuel mixture setting 1st.
B. If still not satisfied, change the needle position.
C. If none of the needle position is good, change the jettings.


A. Idle air-fuel mixture settings
1. Air screw set at about 2.5 turns for stock airflow. Modified exhaust + air filterless can use 2 turns.
2. Idle rpm increase a little more than normal.

B. Needle setting
1. There are 3 ticks on the needle jet.
2. The lowest tick will give us good FC, as it limits more petrol to flow from mainjet @ half throttle
3. The highest tick will give us bad FC, as it let more petrol flows from mainjet @ half throttle.

However, highest tick does not mean best acceleration. If too much petrol flows into the venturi, the mixture will become too rich. This will decrease the power at high rpm. So, try different needle clip position and feel which one has the best results.

C. Jet size setting
1. Change mainjet to #107.5 (stock #105)
2. Change pilotjet to #22.5 (stock #20). If there is no performance increase, then stick back to #20.
3. Change mainjet to #110 + pilotjet #22.5. <-- this should be a good pair.

Anything more than #110 mainjet will make the engine feels heavy, bcoz the mixture becomes too rich.


Disc Brake Tuning Meteorology

The theory covers the relationship between the total areas of the brake pots (Note, its area not count), brake pads, masterpump, the rigidity of the brake hose and the property of the brake pads. The point of improvement is to look for the limit of the system and upgrade it.

1. Single pot is less prone to uneven brake force compared to multiple pots when in case one of the pot jams.

2. Changing the brake rotor is a start. But if you do not see improvements, that means rotor is not the limitation, and you need to change other things to do a stopee (Nose brake).

3. Change brake hose to steel braided, so it is less likely to expand and eat up the brake budget. Try this, wrap ur hands around standard brake hose, and press the brake you will feel it expand. Anymore you press also won't increase braking performance.

4. Change to DOT5 brake oil (normal 1 can, but easily overheat. I go hill run for >1 hr, DOT5 is mandatory)

5. Change brake pads, I use Ferodo imported by Racing Boy. Ask for original ones, one set front about RM30~40. You can see more copper strands on the pads. Other good pads use metal strands so u can see silverly metal strands.

6. Must stiffen front fork absorber, and add a stabilizer bar. Use 15W-20 fork oil, make it about 25% stiffer than stock. 20W-50 fork oil is too stiff bcoz the oil is too not lean enuf, the bound and rebound SUX, I feel like riding on a horse. The traction sux too, bcoz front tyre can hardly grip on the road when going through uneven road (esp penang road).

7. Use ABS device (about RM100) <-- optional

** many thanks to bro charge-n-go and bro alexei for the useful tips
stay tune for more tips

p/s : if anybody wanna share their modding tips too, you can PM me or just post in the thread, and I will update this post

This post has been edited by Are_keem: Nov 9 2009, 04:12 PM

omg~
good luck~

Vrromm....Vrroommmm.....Vrrrrrrooommmmmm......

lol, copy-paste... re-register the proud owner list...

WHOOOOOOOOO

Spayz reporting in!

yes!!!the fifth person to post in the new topic!!!!lucky...haha

^^

Cos that Nob1 SSS pipe too quiet.... Police dont even wanna to saman me for using that pipe And btw i just bought another pipe from samba and the pipe more loud and sound more like Superbike Btw after i put samba pipe I kena 2 time blocking. 1st blocking normal police infront my house but i escaped and have to wait untill 12AM than only can go back home. 2nd time kena blocking by police traffic, this time i just come out from my office they stop me i never even try to escaped coz i cant i was surprised he ask me license, IC, Road Tax, and he say nice pipe where u buy it. i say " I buy from Indonesia" coz i tell him i alway travel there. Here cannot find this kinda pipe than i tell him i work at travel agency nextime if u want fly u come find me i give u discount we chat for awhile than he let me go ler

---

Added on July 30, 2009, 12:32 amu offer me the price laa?? Me very easy to negotiable 1 so no need to worry just offer me a price than will see how to adjust Thanks

This post has been edited by TryX: Jul 30 2009, 12:33 AM

WTF!
police traffic didnt EVEN saman ar?
OMG i wanna put that pipe d la
but too late, i already got my sss
err please share if u ever encounter JPJ with that pipe anytime soon yeah ,

---

Added on July 30, 2009, 12:43 ambtw Penang TT anyone???
lets have a big LC gathering this time

This post has been edited by Spayz: Jul 30 2009, 12:43 AM

Haha if JPJ sure i tolak motor pretend tyre puncture and i let go all my wind from the tyre and tolak pass JPJ only if cannot escaped Lastime JPJ blocking i only kena check my license and road tax and that time stock pipe but Racing boy Footrest. They don't even bother to go check out my cool racing footrest also

don't mind me?

whysomany, you serious? I charge expensive wey... :offtopic

when gathering ??? if i free i will join

actually leh, i think horr, trafik saman 2stroke straight pipes one loh. those very loud at night one.

just yesterday i was stopped at a road block, then another bike just zoomed past without helmet. police just let them past... bullies i tell you.

I've been asked twice by police about my bike, and they commented it's well restored. They'd even let me go once because I forgot to put number plate on new windscreen. Thank him.

Twice, i saw road block with a trooper and 3~4 Kips standby. this roadblock don't play2, if lucky can see some action like on TV3 one...

For aftermarket mods leh, i think only puspakom don't approve. I think as long as we all ride safe, don't rempit, the police also won't go out and penalize us lah.

wahh.. da v3.. laju jer.. mcm motonyer.. ha3.. gratz..

bump

Uncle Cheang reporting

Wah so fast V3 liao ah? Good on ya

Anyway this is my little 135 LC, this pic was taken long long time ago...

Bro Are_keem pls help me to update my pic in 1st page ok? Thanks



This post has been edited by UncleCheang: Jul 30 2009, 10:55 AM

Checked In

report in ^^
EviLRegioN l Penang l SS - Red l July 2009

long time no see bro
added liao

added oredi

wah...thought want to post 1st reply d...

yay! V3 ;3

lol...alex work as??
and WHYSOMANY report in^^

Na0ki update..

bizzy123 到！！！ I got 1 question to ask.. If u r using nob1 SSS when the police or JPJ stop u then he ask : Adakah kau ubahsuai motor kamu?? What will u ans?? If u ans ''yes'' u kena, if u ans ''no'' but the guy noe tat u had mod ur bike then, how??

This post has been edited by bizzy123: Jul 30 2009, 09:18 PM

normally they don't even perasan it's aftermarket one (and I hope they will never )
but incase they know, just be honest with them la. but at least try to make them lost,
just say that you had excident before and those are 'ayam brand' replacement muffler..

You tell him yar u modified bike but not for racing just for urself to admired only And the Nob1 SSS pipe u put to safe fuel coz stock pipe is very heavy so will burn more petrol, but Nob1 SSS light so wont burn so much petrol both sound identical also

---

Added on July 30, 2009, 9:51 pmUncle Cheang ur bike doesn't look like uncle at all. Very nice and well maintain bike So i think u should change name d " Brother Cheang "

This post has been edited by TryX: Jul 30 2009, 09:51 PM

Uncle Cheang live penang where?

---

Added on July 30, 2009, 10:59 pmbtw, TS mean?

This post has been edited by whysomany: Jul 30 2009, 10:59 PM

any1 noe whr to get exhaust cover¬¬?
gt how many kind of exhaust cover¬¬?

i think i can tell where uncle cheang live from the picture...i dono how to say that place but i been there before

Yar yar i being there before too .... Look like Rifle range from the look of the behind flat. I used to stay there if not mistaken

you all ah, don't scare Cheang off lar, like some stalker wey...
TT Penang, how?

Today dark blue shirt police blocked me to check IC and license.
Then, one of them ask me why my exhaust so loud.

I said to myself:"WTF, like this also loud"

I told him that my stock exhaust got problem after accident. But he knows I am lying. (seriously, i think this is not a good reason, but I can't think of any at that moment).

He said:"I got accident before too, and my bike is right in front of you"

I look in front..... and its another green LC.

lol charge.. and then? got 'love letter' or not?

Thanks bro.
Yeah now only i a bit free cause my dept start hiring new people, hehe...
How is your bike now? Top sepeed can reach 180 kmph already? LOL



Haha this pic i took long long time ago, a few weeks after i got my bike. Now my LC already got scratches liao, the chain cover also broken liao lor...



Last time i used to live in Rifle Range. But now moved to Jelutong liao.
You leh?
Huh? What TS?



I live in Jelutong area. Somewhere opposite Jelutong market. You live there too?
I saw a lot of LC around Jelutong area. Some of them mod like crazy...



Haha that place not Rifle Range lah, it is one of the Jelutong apartment. But sometimes i do travel to Rifle Range to have breakfast, i miss the wan tan mee and char koay teow...



TT ah... I will try to make myself available...
Weekdays should be OK
Weekend sorry liao, haha... have to jaga anak...


How are you Mr. Chan? Still working in "I" company ma?

Let me guess.. u kena block in bayan baru area. That LC is green in color and the rims is some sorta cream like color.. he's a young policeman.

Match?

100% match...thats the 1^^
haha..joking..
charge...story tell finish 1st la...

interested to know more....... fast continue charge^^

hmm...then i can 80%sure where is ur house le..i use to stay at my grandma house at the evening and from my place to ur place....walk also can reach...haha

ya that place quite a lot of lc....all too crazy le...don dare to run with them....





charge...i'm interested too......how it continues?

lol.. charge finish ur st0ry le.. all waiting... haha..

later charge say....~the end~
haha...

then, two green LC went for a race, one with GiVi box, the other without... the moment of truth... haha.

haha.. race between kaki leper aka lap vs kaki saman orang

As usual, he asked me to take out IC and license, then said:" Why your IC and license lipat ady one"
oh well, i think not long ago I dropped my wallet, then one big car went over and bent my cards inside.

The last thing he asked was my road tax. I accidentally flashed the $ inside my wallet as I take out road tax.

Actually not much la, just a piece of RM50, and there are 5 - 6 police.

ok, everything is checked, no loophole to catch. So he asked, "mana lu beli pipe?"

I said:"you mau ar, Bee Hock ade jual" then i continue to ask:"apa lu punya top speed?"

he said:"I tak pergi top speed punya." (ya right... he looked away slightly when he said this)

then continue to ask:"bila mau tukar balik?"

I said:"ada wang baru tukar, stock banyak mahal."

then, he js let me go.


OT: The police green LC is not a standard color green. A bit pale and yellowish green.



yeah, and now that's the end.

---

Added on July 31, 2009, 8:23 pmYo Mr Cheang, still working in 'I'. long time never see u ady.


Sg Nibong, near public bank. I went there da pao breakfast almost everyday before work. I see them almost everyday this week. I know they are looking at my bike when I passed by, but today only block me.
That LC is cream like green (coverset), rim didnt notice, haha.

This post has been edited by charge-n-go: Jul 31 2009, 08:23 PM

lol....
~the end~
guys...got any way how to get back my LC?
sad la..see my dad ride it everyday...
then i cant ride it..
stand beside and watch him ride...haiz...

go picit2 his body laa.. bodek2 haha..

no use la...
he want me to give him a strong reason why he need to give me ride back my LC...and how sure and confirm that i dont overlap after i getting back my LC...

Duplicate 1 more LC135 key than when your father sleep ler you take out the bike go enjoy laa after comeback put it back nicely. If he ask why petrol meter suddenly go down ler, u tell him now weather very hot and humid so maybe the petrol dry off itself So like that, you got free petrol and can enjoy riding LC135. Happy Riding !!! " The End "

This post has been edited by TryX: Jul 31 2009, 09:59 PM

hahahaha.... nice 1 tryx.. g00d idea.. LOL !

Make them trust you to handle the road wisely. Ask your dad on a trip. You ride a Lagenda now, rite?

yaya...then my alarm how to duplicate?

Haha.... Alarm de remote u steal from ur dad and u bring to a key shop than u buy another remote than ask them set the frequency for you. As long as you have the courage and the money nothing is impossible Btw don't tell your father i teach you this har






WARNING!!!!! KID UNDER 18 YEARS OLD PLEASE DO NOT TRY THIS AT HOME, WITHOUT THE SUPERVISION OF AN ADULTS

THANKS AND REGARDS
TryXxX

This post has been edited by TryX: Aug 1 2009, 01:10 AM

i suggest TT Penang on FRIDAY next week 7TH AUGUST 2009
meet at MC D GREENLANE
time 8.30PM??
LETS MAKE THIS TT THE BIGGEST!

all penang LC ppl cool with that?
if got u guys wanna go please reply
or not its cancel again la


[/quote]

This post has been edited by Spayz: Aug 1 2009, 02:42 AM

bro...penang SPM trial exam on 10th august lo...
i cant attend...how bout other?
and tryx...thx for your idea^^

friend....don scare me a....our trial exam at 10th of august?not 3rd of sept meh?

can i joint u guyz..?
i own an ES one.. bought in april 2008
i'm from salak tinggi

sure.. welcome

ES what colour one?

say 2 ur father... "ask hong leong make 1 "low speed" CDI for my LC" then pasang...
100% gerenti giv back ur LC....

calvin..i dont know whether your school got take that whole penang d trial exam or not...by JPN d...
so...to those in 10th of august is the whole penang island who is taking paper from JPN 1...

hello i'm new to this forum actually....
just want to have you all suggestion...
i've installed new keihin 28mm carb just now...
but the size of the cart intake did't match with the airfilter box....

any suggestion??

hey wanna giv u guy see this...



thnx... luckily cucuk tepi...

This post has been edited by kinwei3250: Aug 1 2009, 11:49 PM

LOL.. very lucky liao..

Is time to change tire d la it is going to worn out d.. Btw how much is the keihin 28mm carb?? Rm380???

This post has been edited by bizzy123: Aug 2 2009, 12:25 PM

Guys anyone crazy about GP Style pipe can check this pipe out is on sale at ebay



Or can visit the link here. http://cgi.ebay.co.uk/YAMAHA-R6-R6R-06-7-M...%3A2%7C294%3A30


http://www.yamahat135.com/forum/viewtopic....der=asc&start=0

it's a red/black one..
forgot to mention to you

btw, i just wondering.. is there an original yamaha 60 mm block?
i only know about dolphin and shark brand..
if there is, where can i find that?
anyone know it?

LoL shark and Dolphin is Taiwan brand don't really think that is count as original our original blocks is Diasil the biggest size so far is the blocks from yamaha FZ150I or Vixion it is 57mm if not mistaken. I Think the block could be fitted on our bike if not mistaken as well Or can try this block
http://www.yamahat135.com/forum/viewtopic.php?t=1187

last friday ,i kena saman because din't place sticker' P 'in front after accident 2 month ago. i wan to ask if kena saman got potong pemandu 's markah ?
i wan to ask u all remove airfilter are remove untill kosong ,din't cover anything on the box ??

No no remove air filter only the the cover of the black box stil hv to put bak, if not the sampah, water and dirt all go in then u hv to eat Penadol liao... Ei 1 question here when rev got black smoke cumin out means incomplete combustion right?? Do i nid to adjust the carb so tat more air go into burn together wif the petrol?? And if it is needed to do so which screw should i turn?? The left 1 or the right 1?? And should i turn it anti-clock or clockwise?? Pls help me =(

Dont stingy laa take to the mechanic u trust ask them adjust for you i think they wont charge u anything. They more experience than u.... if you adjust wrongly later ur bike wont run smoothly and spoilt your bike only

If you've installed the Keihin 28mm, dont use the standard Airbox. take it out. you can use the UMA RACING mushroom air filter costing around RM65.00

try it and review to us here how it feels.

=.= ans = no ans...

that was very lucky man ... but that is one biiig nails...

---

Added on August 2, 2009, 7:12 pmHi Monitorhead,

welcome!. where were you from ?
okay, Yamaha did not produce 60mm block for LC. other than Shark and Dolphin, try to look for MDS Brand. I'm using the MDS Brand and a lot of my friend also use this Block. if they are installed properly, its a good block.

hope that helps.

This post has been edited by alcalie: Aug 2 2009, 07:12 PM

v3 already~~~

i reporting in
sorry for being a slowpoke~~~

i've installed an airfilter...but FAITO racing one.....
feel so lite...
but need some adjustment on the carb..
didn't find the match yet....
hehehe
so far it feels much better then with filter box

its okay, as long as you have an airfilter, it should be all right. do you know what pilot and mainjet settings you're using on your bike ? care to tell us ?

Removing air filter is fine.

The position of the carburetor intake can hardly allow big particles to get into the engine.

Remove the airbox is even better, with one drawback - noisy.

i use the standard from factory pilot jet n main jet.....
any suggestion for the jets??

You use #20 PJ and @105MJ in your 28mm Keihin?

This post has been edited by charge-n-go: Aug 3 2009, 01:51 PM

Latest Pics of My bike Bored today at office, posting for the sake of humble coz all of ur bikes better than mine..









Please neglect the messy surrounding, my mom's house in renovation process..

This post has been edited by rainingzero: Aug 3 2009, 05:26 PM

EEEEiiiii u take off the catalyzer and the silencer??

huhu.. act, i didn't mean.. shark and dolphin are original.. i know they aren't.. my bad for not making the statement clear..

actually, i asked if there is a original yamaha 60 mm block around because i found this blog http://rahsiakelajuan.blogspot.com/2009/06...-hand-part.html .. it says that "Yamaha Thailand Genuine Racing Part. Guarantee!".. actually never heard of the genuine one before just want to verify with u guys..

tq.. i'm from salak tinggi.. how bout u?

how's the block? does it cause the engine to be louder or produce any awkward sound?
how much did u bought for urself?

What's the bore and stroke size of std LC engine?

---

Added on August 3, 2009, 7:27 pmOk, found it... 54 x 58.7.
Hmmm, you guys upgrade it to 60mm bore.

I was just thinking, changing to bigger piston/block, are you guys still using stock head, or there is one matching the new block?
If no change head, I guess that's why some of you are hearing 'weird' sounds from the engine, especially if skim block and racing gasket some more...

This post has been edited by alexei: Aug 3 2009, 08:19 PM

brother...how much u bought the yamaha disc??...u should fix together with yamaha logo sport rim ma....

Chongkiatz, selling LC aftermarket parts also call yourself humble ah? Really humble loh... Bike looks ok marrr...

lol, you remove the end cover along with the silencer inside?
hows the sound? last time my friend also did like this,
and the sound is foookinggg loud, same par as AHM one I think

I am currently using the 60mm kit with S6 racing cam. and previously, I also use 22/19 head. This head is kicking good, but eventually the timing chain tensioner spring was broken, it damages my cam bearing (all the ball bearing come out), then 1 of 4 of the valve broke which causes a hole in the piston face and also damages the head chamber. a modified head (22/19) will cost around RM600. if you really want to change, please keep your original head in all good condition. you may want to use them back later...

I think the weird sound you're talking about is coming from either the valve tappet, or the head knocking. just bring to the shop and ask for TOP HEAD service and see if that works. it has works for most of my friend.

---

Added on August 4, 2009, 8:04 amumm... I think from that picture.... isn't that an ABM Exhaust without the Silencer ?
this pipe is quite good if you know how to set the carb to match it... some friends are using this too..

---

Added on August 4, 2009, 8:08 am




I'm from KL, and work in Cyberjaya, so Salak Tinggi is not that far from my working area... and I have a friend who lives there too..
the Block set that I bought is okay, it fits right in, but here, we do a little modifications to the coolant flow so that the coolant will recycle through the block and the radiator. I'll show you guys some pictures when I have a chance to snap them later. its really a simple mods but good for big bores and long distance traveller like me.

I bought the block set for RM125.00 not including the coolant mods. well... it the block did not make any weird sounds, its very quiet. and that really depends on who installs it and is it installed properly.

This post has been edited by alcalie: Aug 4 2009, 08:08 AM

This one is an aftermarket exhaust..

Yup, just same like AHM...this is my everyday ride to workplace...

@chongkiatz
forgot already how much i paid for the disc. bought few months ago, maybe around rm150++.
