Link(s) to previous thread(s):
DELL Studio XPS™ 13 & 16 Notebooks [V2]
Dell Studio XPS 13 Notebook
Available options for customization(Malaysia)
Color
» Click to show Spoiler - click again to hide... «
Processors
Intel® Core™2 Duo Processor P7450 (2.13GHz/ 1066 FSB/ 3MB Cache)
Intel® Core™2 Duo Processor P7550 (2.26GHz/ 1066 FSB/ 3MB Cache)
Intel® Core™2 Duo Processor P8400 (2.2GHz/ 1066 FSB/ 3MB Cache)
Intel® Core™2 Duo Processor P8600 (2.40GHz/ 1066 FSB/ 3MB Cache)
Intel® Core™2 Duo Processor P8700 (2.53GHz / 1066MHz FSB / 3MB)
Intel® Core™2 Duo Processor P9600 (2.66GHz/ 1066 FSB/ 6MB Cache)
Operating System
Genuine Windows® 7 Home Premium 64bit (English)
Genuine Windows® 7 Professional 64bit (English)
Genuine Windows® 7 Ultimate 64bit (English)
Memory
4GB (2 X 2GB) Dual Channel 1066MHz DDR3 SDRAM
6GB (1x4GB/1x2GB) 1066MHz DDR3 SDRAM
8GB (2 X 4GB) Dual Channel 1066MHz DDR3 SDRAM
Chipset
NVIDIA® GeForce® MCP79MX
Graphics
NVIDIA® GeForce® 210M – 512MB
Display
13.3 " WXGA (1280x800) WLED Display
Audio and Speakers
Integrated Stereo Sound
Integrated CREATIVE Sound Blaster® X-Fi MB Audio Software Solution
Hard Drives
320GB (7200 RPM) SATA Hard Drive
500GB SATA Hard Drive
500GB 7200RPM SATA Hard Drive
128GB Solid State Hard Drive
256GB Solid State Hard Drive
Optical Drives
Slot Load 8X DVD + /-RW Drive with double layer write capability
Power
6 cell 56 WHr Li-Ion Battery
9 cell 85 WHr Li-Ion Battery [Additional Purchace Only]
Camera
1.3MP Integrated Webcam (with WLED display)
Dual Digital Array Microphones
Wireless
Dell 1520 Wireless-N card(Wi-Fi)
Dell™ Wireless 370 Bluetooth Module
Ports, Slots, Chassis
Externally Accessible
(1) USB 2.0 compliant ports
(1) USB 2.0 compliant / e-SATA port with Powershare
15-pin VGA video connector
IEEE compliant 1394a port
Integrated network connector 10/100/1000 LAN (RJ45)
54mm Express Card slot (DOES NOT SUPPORT PC CARDS)
Display Port
HDMI Port
AC adapter connector
Audio jacks (2 line-out, 1 Mic-in)
8-in-1 Media Card Reader
Dimensions & Weight
Width: 12.56" (319mm)
Height: 0.88" (22.55mm) front / 1.35" (34.34mm) back
Depth: 9.3" (236.12mm)
Weight: Starting weight of 4.85 lbs. (2.2 kg)6(13.3" display, 6 cell battery). Weights will vary depending on configurations and manufacturing variability.
[Click here to start your customization]
[Click here for closer view]
Dell Studio XPS 16 Notebook
Available options for customization(Malaysia]
Processors
Intel® Core™2 Duo Processor P8700 (2.53GHz /1066 FSB/ 3MB Cache)
Intel® Core™2 Duo Processor T9550 (2.66GHz/ 1066 FSB/ 6MB Cache)
Intel® Core™2 Duo Processor T9600 (2.80GHz/ 1066 FSB/ 6MB Cache)
Intel® Core™2 Duo Processor P9700 (2.80GHz/ 1066 FSB/ 6MB Cache)
Intel® Core™2 Duo Processor T9800 (2.93GHz/ 1066 FSB/ 6MB Cache)
Intel® Core™2 Duo Processor T9900 (3.06GHz/ 1066 FSB/ 6MB Cache)
Intel® Core™ i5-430M Processor(2.26Ghz, 4Threads, turbo boost up to 2.53 GHz, 3M cache)
Intel® Core™ i5-520M Processor(2.4GHz, 4 Threads, turbo Boost up to 2.93GHz, 3M cache)
Intel® Core™ i5-540M Processor (2.53Ghz, 4 Thread, turbo boost up to 3.06 GHz, 3M cache)
Intel® Core™ i7-720QM Processor (1.6GHz,4 Cores/8 Threads,turbo up to 2.8GHz, 6MB Cache)
Intel® Core™ i7-820QM Processor (1.73GHz,4 Cores/8 Threads,turbo up to 3.06GHz, 8MB Cache)
Operating System
Genuine Windows® 7 Home Premium 64bit (English)
Genuine Windows® 7 Professional 64bit (English)
Genuine Windows® 7 Ultimate 64bit (English)
Memory
3GB (1x2GB/1x1GB) 1066MHz DDR3 SDRAM
4GB (2 X 2GB) Dual Channel 1066MHz DDR3 SDRAM
6GB (1x4GB/1x2GB) 1066MHz DDR3 SDRAM
8GB (2 X 4GB) Dual Channel 1066MHz DDR3 SDRAM
Chipset
Intel® PM45 with Centrino® 2
Intel® PM55 with Intel® CoreTM i7 processors
Intel® HM55 with Intel® CoreTM i5 processors
Graphics
1GB ATI Mobility Radeon HD 4670
Display
15.6 " 1080p WUXGA (1920x1080) WLED Full HD Display
16 " 1080p WUXGA (1920x1080) RGBLED Full HD Display
Audio and Speakers
7 Watt Integrated Stereo Speakers with Subwoofer
Integrated CREATIVE Sound Blaster® X-Fi MB Audio Software Solution
Hard Drives
320GB (7200 RPM) SATA Hard Drive
500GB SATA Hard Drive
500GB 7200RPM SATA Hard Drive
128GB Solid State Hard Drive
256GB Solid State Hard Drive
Optical Drives
Slot Load 8X DVD + /-RW Drive with double layer write capability
Slot Load Fixed Blu-ray BD-ROM / DVD + /-RW Combo Drive
Slot Load Blu-ray BD-R, BD-RE / DVD+/-RW Drive with DVD+R double layer write capability
Power
6 cell 56 WHr Li-Ion Battery
9 cell 85 WHr Li-Ion Battery
Camera
Integrated 2.0 mega pixel web cam
Dual Digital Array Microphones
Wireless
Dell 1520 Wireless-N card
Intel® WiFi Link 5100 (802.11a/g/n) Half Mini-card
Intel® WiFi Link 5300 (802.11a/g/n) Half Mini-card
Dell™ Wireless 370 Bluetooth Module
Ports, Slots, Chassis
Externally Accessible
(2) USB 2.0 compliant ports
(1) USB 2.0 compliant / e-SATA port with Powershare
VGA video connector
IEEE compliant 1394a port
Integrated network connector 10/100/1000 LAN (RJ45)
54mm Express Card slot (DOES NOT SUPPORT PC CARDS)
Display Port
HDMI Port
AC adapter connector
Audio jacks (2 line-out, 1 Mic-in)
8-in-1 Media Card Reader
Dimensions & Weight
Width: 15.15" (384.9mm)
Height: 0.95" (24.1mm) front / 1.34" (33.95mm) back
Depth: 10.02" (254.6mm)
Weight: Starting weight of 6.3 lbs. (2.87 kg)5(15.6" WLED display, 6 cell battery). Weights will vary depending on configurations and manufacturing variability.
[Click here to start your customization]
[Click here for closer view]
Reviews, Hands-on etc
Dell Studio XPS 16 Reviews: Notebookreview.com, PCMag.com, PCWorld.com, LaptopMag.com, CNET.com, DigitGeek.com, ComputerShopper.com, Notebookcheck.net, PCPro.com, Trusted Reviews.com & HardwareZone.com.
Dell Studio XPS 13 Reviews: PCMarket.com.hk, CNET Australia, NotebookCheck.net, PC Pro.com, PC Advisor.com, Comp Reviews.about.com, TechRadar.com, Pocket-Lint.com, Trusted Reviews.com & Hot Hardware.com.
Dell Studio XPS Hands-on Pictures: Engadget.com (Studio XPS 13 & 16), CES.CNET.com (Studio XPS 1640), Engadget.com (Studio XPS 13).
Dell Studio XPS 13 First Impressions.
Powered by
» Click to show Spoiler - click again to hide... «
Credits to Onyx_black
Studio XPS 16 User Bar
1.

2.

3.

Credits to lee_what2004
This post has been edited by outlife11: May 19 2010, 10:16 PM
