A.C.Ryan | Playon!HD



Watch Full High Definition 1080p video content on your Full HD screen. Play from the (internal/external) harddrive, USB storage, SD media card or stream across wired or wireless** network.

Enjoy your music collection while sharing your holiday pictures with the rest of the family in the living room. Enough of your own music collection? Switch to hundreds of Internet Radio stations that bring you new tunes 24/7 or stream your content from one of the available Internet Feeds (Picassa, Flicr, News Feeds).

The Playon!HD series are the ultimate Media players for your digital lifestyle. Easy to use, perfect for playing your downloaded video’s and music in the comfort of your living room.

** Wired Network is included / Wireless Network is an optional extra, not included in the standard package. To enjoy wireless network at up to 300Mbps, purchase the Wireless option

Supported Formats:




Playon!HD ACR-PV73100 Vs. Playon!HD mini ACR-PV73200
Specifications & Comparisons

Official Site:
Playon!HD

Official Forum:
A.C. Ryan Forum

Playon!HD How To Guides
How To Guides


Firmware Update

AC-Ryan 73100 ( Big )
URL=ftp://MediaUP:mediaup@mediafw.thruhere.net/Update/AC Ryan/73100

AC-Ryan 73200 ( Small )
url=ftp://MediaUP:mediaup@mediafw.thruhere.net/Update/AC Ryan/73200(Mini)

---

Added on July 1, 2010, 10:23 amWelcome to post it here

This post has been edited by BoxBuilder: Jul 3 2010, 10:22 AM

Hoi! how many threads you want to open?

Elite marah liao...

Don't so hot with Boxbuilder lah. The other thread the TS want to close already

--------------------

Hehe I just saw another 2 extra threads for V2 opened by Boxbuilder including this total 3 already.

I also must marah

This post has been edited by Ngto: Jul 1 2010, 11:03 AM

he must have press the button 3 times...hehe

anyway welcome to new home !

anyway ngto have you register for the coming event?

This post has been edited by soulquarianz: Jul 1 2010, 11:16 AM

has hd audio firmware release yet ? sorry , was tied-up with my projects , a bit slow lately

I would suggest you name this thread title v3 to reduce confusion.

And put a link the old thread.

This post has been edited by auhckw: Jul 1 2010, 11:27 AM

Not sure yet. Still considering.

hehe, may be lo ^^

Sorry all of the member Computer lang just now, so double click on that.

Brod, I have a noobie question here.

Today I just bought a Samsung hdd to be fixed inside the POHD. Unscrewed behind lid and then fix the hdd on the lid, screw it and then trying to fix it into the POHD but found that the space is too small for my HDD to be go into the poh. As I'm frustrated, finally I'm ended up just put the HDD inside the pohd and screw the cover without screw the hdd on the lid.

What bout you guys? have you encountered the same situations as mine? Do you screw the hdd onto the lid or just put your hdd inside the pohd?

Hi Bro, I think your installation is not correct. Pls see below video on how to install hd into POHD.
http://www.youtube.com/watch?v=7cCwr3Ukiuc

Cheers.

thanks bro..some error in my earlier installation.

working good now

I hope I can get some help here:

I got my PlayonHD mini two days ago. I manage to connect it with my WD Mybook World Edition NAS. But I still have problems getting the subtitles to work. The movies played flawlessly, but I couldn't turn on the subtitles.

I'm wondering if I'm doing it wrong with the subtitles format.

Movie Name (Year).avi
Movie Name (Year).srt

Both of the files are in the same folder, and of course together with all the other movie files I got. Still, I couldn't get the subtitles to work. When I press the "subtitles" button, the OSD appeared with subtitle in OFF mode, and there is no way I can get it turned ON.

Thanks.

Boxbuilder, Pls do not post any sales related things here...wanna tell you long time ago till a forumers reported you for keep on posting trading/ workshop thingies..

hv to start deleting your post dy..Any sales posting, do it in Garage sales hor

ok, sorry for that, for all the people want to see the promotion on going you may see it at Promotion AC-Ryan
Cheers!

---

Added on July 3, 2010, 1:02 pmCan you use the external hard disk to try the same file? If the .srt works properly, it may due to the WD NAS problem.

---

Added on July 3, 2010, 2:41 pmAdoi, sorry bro, Box Builder open this thread only and this thread open for orang pantai, like you to help me to solve the POHD technical problem face by our brothers and sisters. Will you joint the workshop? I buy you a teh tarik. Moderator already warned me don't post the promotion and events at here after someone reported to him. So, to announce our events, we will post at the tradezone, as below my statement.

Thousand apologies to stimix because he might kena tembak liao. Let me buy you a teh tarik ya.

Cheers.

This post has been edited by BoxBuilder: Jul 3 2010, 02:41 PM

got my playon big + 2TB hdd. thing is, on booting, always got this [format hdd] option .. i got 2TBs of movies, hv to always click [cancel].

n cant seem to connect to torrent download, my playon is wired to the wireless adsl modem tho.

One day you accidently format your 2TB of movies you gonna cry.

i think when u first u got HDD u didnt format it with pohd. if not i guess u need to redo it (format using pohd) or theres an option (go to acryan forum - how to section), how to create partition etc.

if possible try to format using firmware 1402 because with this samba and bt is automatically installed in the HDD. whereas later version of firmware 2388 and above, u need to install the additional service pack in order for you to use bt and browse your pohd in your network.

currently i have 2tb samsung install at the pohd formatted with 2901 so everytime (basically i like to toy around with the firmware) i update pohd firmware i need to reinstall the additional service pack whereas my other 1.5 which i format using 1402 firmware i dont have to install the service pack.

currently the best firmware i'm using in my environment is 3875.

p/s: careful when turning on your pohd if u didnt format it using pohd coz like ngto said one day u might accidently deleted (format) your hdd.

act the 2TB HDD was preppd by my playon seller. playon + samsung 2TB + 200++HD Movies, mix of mkv, BD ISO.... got it for rm940.

yuo found the solution @ playon firum, hv to slave the playon with a oc n partition magic. m currently out of town nao... just hv time to watch the preinstalld HD movues, no time to fiddle yet.... thts y torrent oso not working... bt overall veli satisfied. used to hookd up my laptop to the tv, nao hv playon,....

ok share with us the outcome.....if too troublesome...reformat using pohd is only choice....

Finally figured out the problem. This problem only occurs when I browse in UPnP mode. But if I used Network or NFS mode, no problem at all, subtitles work perfectly.

By the way, is there a function to adjust the time delay and advance if the audio and video don't sync?

Thank you.

Nop, it is file porblem. You need to use software to adjust it. A bit complicated. But srt can be sync under subtitle button.

hi anybody interested to get a used POHD big comes with Compatible Wireless Dongle? if so kindly PM me as i want to let go mine....comes with official firmware 3875.

p/s: i'm jumping ship to other media player.....

How much u want to sell if with wireless dongle

hey boy & girl i hear that the up coming POHD got open a training or an gathering on the coming 31july2010. who wan to join. i think i will be there. get more info on that, some more the gathering is also free de. very good also lo.

i'm already confirm and registered as participant ! u better send yours now coz seat is limited !

WoW, okok, i will mail to them now...

Getting the Dune 3 I presume ?

that one too high end...cant afford.......

after all "why pay more" eheheh...

i'm just waiting for confirmation of HD supported Firmware only...before switching...

It's clear you won't be getting any HD Audio with the old 1073DD model . You going to get the new 1073DD C+ ?

I know you are going to get Xtreamer!!! Go for Pro or Sidewinder? Semua pun ada kat saya sini.....

guys e my my friend bought this player 2 days back, today he try to update the firmware and sudenly sometin hapen and now his player doesnt start it seems, im woried briced or someting? can some1 help me pls

i'm getting Pro but i have already made my reservation with Boxbuilder. thanks for the offer

---

Added on July 9, 2010, 8:36 amtaken from acryan how to section

Follow the instructions below to update your Firmware for the Playon!HD:

Standard updating of firmware

1. Download the latest firmware from our download section or our latest beta version from our forums.
2. Unzip your downloaded zip onto an empty USB stick. Make sure that the files within the zip are unzipped within the root of the USB stick.
3. Put your USB stick into one of the USB ports of the Playon!HD.
4. Startup your Playon!HD if it not already on.
5. In the menu, go to Setup, choose System, then go to System Update and select the option System Upgrade.
6. Your Firmware Update will now be progressed. Do not shup down your Playon!HD while the Playon!HD is processing your Firmware Update. The Playon!HD will reboot automatically.
7. After the Playon!HD has rebooted, your new Firmware is installed.


If you are unable to access your main menu, please proceed as follows (this also installs the extensions):

Safe-Mode Reflash

1. Download the latest firmware from our download section or our latest beta version from our forums, also download the extensions.
2. Unzip your downloaded zips onto an empty USB stick. Make sure that the files within the zips are unzipped within the root of the USB stick.
3. Disconnect the power cable from the Playon!HD.
4. Put your USB stick into one of the USB ports of the Playon!HD.
5. Push the power button and hold it pushed.
6. Connect your power cable again.
7. Hold the power button pushed until you get a screen which says that the firmware is updating.
8. Do not release the power button between the time of connecting the power cable and the appearing of the screen.
9. After firmware update the Playon!HD will reboot itself, with the extensions installed and you're done.


hope this helps


This post has been edited by soulquarianz: Jul 9 2010, 08:36 AM

Hi Bro, u really a sifu now. Thanks for your info. Remember bring your 2 friends to join the Playon!HD Workshop ya. A lot of surprise.

i'm not sifulah but i do acknowledge that i play around with pohd. in fact i have tested almost 95% in the acryan how to section (from tweaking speed to enabling service) hehehe....just to get the best out of it.

So, what is the more stable firmware up to date?

the best firmware in my setup currently is 3875.

my current firmware is way old back..... few generations behind.

I should not have any concern to jump directly to 3875 right?

Hi all,
I need some clarification regarding POHD connectivity with home theater setup (I'm thinking of getting Sony DAV-DZ610)

Which 5.1 surround sound quality is better? between HDMI vs optical connection? I'll be streaming .mkv movies

Is my setup below correct?

yes. but if the internal HDD is formatted with later version 2388 then u might need to reinstall the additional service pack.

p/s: to be safe please unplug your internal HDD prior to flashing / upgrading / downgrading firmware.

---

Added on July 12, 2010, 3:43 pmif you using HDMI then u dont need to use the optical link. HDMI will carry both audio and video.

then in pohd under setup / audio u need to set HDMI RAW.

This post has been edited by soulquarianz: Jul 12 2010, 03:43 PM

@soulquarianz
But without optical, how can the AVR separate the sound channels? The only HDMI connection into the amp is from TV, not the POHD itself..

duh! Better connect your POHD HDMI to AVR ... AVR to TV. And try to understand HT 101 basics. It's very simple actually ...

bro, sorry your HTIB is not capable of handling 5.1 from pohd. it will downmix to 2 channel stereo. i just ran thru the manual. suggest u get proper AVR to do this like most of us.

---

Added on July 13, 2010, 8:56 amagreed. look for 2nd hand AVR that can do DTS and Dolby decoding only unless u got a newer chip of pohd then get a HD capabilites AVR .



This post has been edited by soulquarianz: Jul 14 2010, 10:07 AM

goodbye POHD !

good product after serving me close to 10 months

sad to say goodbye but i'm jumping to another product ! same realtek chipset but advance version that support hd sound.

adios !

Which one? HDPro from yangxi ar?

let us know which one, I oso wanna jump ship dee

I bet he's most likely jump ship to Xtreamer

Echo and la soul,

i'm now sailing with Xtreamer Pro

What is the benefit of xtreamer pro compare to POHD?

Pro can host 2HDD, pohd only 1 HDD.

How much? YAMJ supported out of the box ar?

Just cod pohd with soul this evening..nice seller

nice dealing with you bro...hope u like it. if u need any help or assistance feel free to PM me.

This post has been edited by soulquarianz: Jul 15 2010, 08:23 AM

Wow Bro, u must get a very good deal ya . Wonderful.

So, due to many request, we also open workshop for the POHD fans. Pls register to us first ya. Don't forget to bring your name card. For lucky draw.

i was wondering does this ACRyan support BD-ISO??

just purchased a unit for myself. hehehe...

The current FW 3875 got some glitch with BD ISO. You will experience stuttering with some titles and loss of sound. BDMV got no problems.

Wait for upcoming FW next week to see if the ISO problem is fixed.

ooo icc....wat is BDMV?? BD ISO comes with True HD audio rite?? and i thought ACRyan does not support True HD audio??

btw....wat is the 1080P 24FPS under the Video Settings?? shud this be ON or OFF??

BDMV is the full Folder and File Structure extracted out from ISO. It's the same actually.

For the older POHD with the 1073DD chipset , you can play the movie from BDMV or ISO, but you won't get HD Audio of course, just Core DTS extracted from DTS-MA.

For True HD, sadly you won't get any sound. Fortunately, True-HD titles are much less compared to DTS-MA titles.

But since you newly bought your POHD unit, chances are it's using the new 1073DD C+ chipset. This means it can handle HD Audio, but the problem is will AC Ryan be willing to pay for the license to enable it in future FW? That's the Big question.

As for the 24fps feature, your TV must support 24FPS in order to play at that framerate. Don't turn that on if your TV does not support.

This post has been edited by Ngto: Jul 17 2010, 11:38 PM

Just bought POHD mini at digital mall yesterday very satisfied with pix and sound performance.........

Bought the mini last 2 days. sometimes can't play MkV and unable to play .mp4 files.

Some 720 files slight lag when moving/action.

anything i can do ?? harddisk issues or the files problem ?

Wonderful Bro. Do you want to joint POHD workshop to study more about POHD? It is free.

---

Added on July 20, 2010, 8:53 amIt may due to file problem or hard disk problem. Have you scan disk periodically and fix the corruption files in MBR? Just like car, hard disk need to do maintainence also. Come for workshop to learn more and ask Eugene about this question.

Bro ralli_art, you can ask about HD Audio question and when can AC Ryan gain the licence at workshop. We need your participantion to stress more on AC Ryan to speed up the process of HD Audio pass thru. If waiting for me to ask, power not enough wor. Come come, let force A C Ryan to look seriously on certain issue we need most ya.

This post has been edited by BoxBuilder: Jul 20 2010, 08:57 AM

BoxBuilder, thanks for the prompt reply. Those unable to play and lagging movie files no problem when play using laptop.

Just sent my request to the workshop email. Awaiting their confirmation.

Cheers.

*btw, any idea where can i get the wifi adapter ? brand or model ?? thanks again

Boxbuilder, sorry bro not free la that day...thanx for invitation

D3vilsim, what muvi u play problem maybe can check mine...
what is ur F/W ver I'm just update to 3875

This post has been edited by shenmui: Jul 20 2010, 09:29 AM

We have a showroom in Petaling Jaya SS17. Anyone interested can visit our showroom to try out AC Ryan. Check out my signature or Click Here..

Thank You.




This post has been edited by blitzboy: Jul 21 2010, 10:29 AM

Yes Bro, when you playing thru laptop, if got problem on the hard disk sector, it will pass by and continue the running. But media player do not have this command and will hang at there. Anyway, have to thoroughly check your files and hard disk b4 come to conclusion. So, you have to check disk first by using MS command ya.

We recommand using A.C.Ryan wifi. Although a bit high price but quality and performance is certained. Tips: come to workshop and use the gift voucher.

Alright got the email reply ... oh got voucher geh ngek ngek ngek. good good good.

btw, how much is the A.C.Ryan wifi adapter ??

shenmui, i play Star trek 720..when the space ship flying..the background a bit lagging . not smooth. Also the gundam HighDef.

Eh eh.. workshop got free fullHD "share" or not =P

As mentioned, any info after check disk?

Hi Bro, no 'share' activities la or workshop kena banned. But it is a good bridge to bring you all togehter. You know what I mean.

BoxBuilder, will perform the check disk when i back home. Now in office. Alternate will get a new harddisk to try..since i need it for the new moviessss.

btw, i using Apple Mac. Anyway i can perform the HD check u mention ?

Alright.. i like the bridge. laptop ready....

i got the wifi adapter to sell...i buy from soulquarian..but not using the adapter

any others 3rd party wifi adapter compatible with POHD.....

As long as using Realtek 307X chipset, it is compatible....

BoxBuidler, can provide me the price of the wifi adapter from POHD ? thanks

Hope below list can help for those who plan to use 3rd party wifi adapter.

If you examen the inf-file of the original driver, the dongles here below should surely work:

"Corega CG-WLUSBNM"
"Corega CG-WLUSB300NM"
"D-Link DWA-130 Wireless N USB Adapter(rev.C2)"
"D-Link DWA-130 Wireless N USB Adapter"
"D-Link DWA-131 Wireless N Nano USB Adapter"
"EnGenius 802.11n Wireless USB Adapter"
"Belkin N Wireless USB Adapter"
"Belkin Basic Wireless USB Adapter"
"Belkin Connect Wireless USB Adapter"
"Hercules Wireless N Mini USB Key"
"Edimax 802.11n Wireless USB Adapter"
"Sitecom Wireless Nano USB Adapter 150N WL-353"
"Sitecom Wireless High-Gain USB Adapter 300N X2 WL-356"
"Sitecom 150N Wireless USB adapter WL-349v2"
"Sitecom 150N Wireless USB adapter WL-349v3"
"Sitecom 300N Wireless USB Adapter WL-352v2"
"Sitecom 300N Wireless USB Adapter WL-352v3"
"Hawking Hi-Gain USB Wireless-N Dish Adapter"
"Hawking Hi-Gain USB Wireless-G Dish Adapter"
"ASUS EZ N 802.11b/g/n Wireless USB Adapter"
"ASUS WL-167G V3"
"Amigo 802.11n Wireless USB Card"
"Zinwell 802.11b/g/n USB Wireless LAN Card"
"Sweex LW154 Wireless 150N Nano Adapter USB"
"Logitec LAN-W150N/U2 Wireless LAN Adapter"

Please note that for instance the "Corega CG WLUSBNM" is also sold as the "SABRENT USB A11N WIRELESS ADAPTER" and also as the "TRENDNET TEW 649UB WIRELESS".
The "Corega CG-WLUSB300NM" is also sold as the Asus USB-N10 and some more.

So as stated before, the above wireless dongles should surely work. But probably many, many more.........
as long as your wireless dongle uses the same driver as the Realtek RTL8192S and equivalents

http://www.acryan.com/forums/viewtopic.php...t=2952&start=60

This post has been edited by shenmui: Jul 20 2010, 03:45 PM

Been looking around and can't seem to find an answer for this..

Is there a way to 'repeat' my slideshow? I want to have my slideshow run constantly... through out the whole day...

It already automatically repeats.

yeah I also notice little bit lagging for ac ryan mini.......

PlayOn!DVR just landed...There will be a demo on the wokshop for this new model as well.

would like to find out from u guys on this POHD. anybody using this POHD connected to a DTS, Dolby Surround, TrueHD AVR??

if let say i have some DTS/Dolby Surround/TrueHD movies and i connect this POHD to all those audio supported AVR. will the audio come out from the AVR in Stereo or Surround Sound??

hope any of u can enlighten me on this. thanks!

it's depend on source audio...............

i know....it the source audio is DTS 5.1 or DTS-MA?? will the audio out delivered from the AVR in these formats??

It's been repeated so many times already.

Refer post #1, check for Audio Format Supported

if not mistaken anything DTS-XX (MA/ES/HD) will be downmix to core DTS. Older generation of AVR should be able to pick it up.

Unless u want full HD sound then u need a newer chip POHD (wait for firmware) and AVR that support full DTS-HD and TrueHD

D-Link DWA-130 also got lot of version..not all using Realtek..so have to be careful..

sorry want to ask noob question ..

1. is that DTS-XX (MA/ES/HD) same as lossless (actually dont know much what meaning of lossless )? my pren told me that lossless=very good.

2. is there any big different between core dts and lossless sound?

3.newer chip.. already in market?

still confuse to buy acryan or dune player

thank you

i'm a ACRyan pohd mini owner here....still waiting for the firmware release to support for DTS-HD or TrueHD passthru since 1 year ago til today....looks like it wun happen...our friendly competitor Xtreamer already can support d....abit regret buying this media player.....

Hi, Pls read below link:
http://playonhd.spaces.live.com/blog/cns&#...3!522.entry

PS: The firmware is planned for release during end July/Early August.

Wanna know more? Come for the workshop lor.

Hi i got a question for all the sifus here
recently i just downloaded a movie with ass file(Soft Subs)
i try loading it in the acryan but it just wont load ...
i double checked and all the names are the same.. when i watch on pc.. i could see the sub..but when i load it on acryan..i could not turn it on at all?
anybody got a solution?

sigh...too bad it only apply to those who bought in April 2010....I bought this end of last year....

Don't be disappointed because you need latest Amp and good speakers to enjoy HD audio which will cost you another >RM5K. The old version still can support DTS pass thru which is good enough for normal people as us lor. Btw, if you want to know more about HD Audio info and other functions of POHD, pls join us for the fun workshop ya. Free gift will be given out and you may win away new DVR wor.
Cheers!

---

Added on July 27, 2010, 9:17 amPOHD support ssa subtitle wor, not ass...

This post has been edited by BoxBuilder: Jul 27 2010, 09:17 AM

Cheap HD Audio Amp only around RM1.5K, maybe less. As for speakers up to individual tastes

Old POHD if you play Dolby TrueHD = No sound

This post has been edited by Ngto: Jul 27 2010, 10:28 AM

errk so whose coming for the workshop?

i got 1 extra seat !!! hehehe

Count me out. Since must submit questions for preview , I pesume can't ask direct questions about HD Audio, no point going. Will be jumping ship soon anyway like you

This post has been edited by Ngto: Jul 27 2010, 10:57 AM
