QUOTE(dilin @ Apr 11 2016, 09:16 AM)
I'm interested with the your PID project, please keep us updated!
I think that depressurizing has a larger effect on your shots rather than temperature. You might want to go ahead and try it!
I have replaced my pressurized basket (Delonghi EC155) with a normal basket, and this impacts the shot more than temp surfing.
For the temp, I warm the machine for 30 mins, prior to locking in the shot I put it in steam mode. Once the green light hit, I flush for one second (vapor from group), lock and pull.
More than half the time I would get consistent bottomless pours. Taste-wise, it's not too bad... lol.
HTH
Hi dilin et al,
For sure! Will be placing the orders for the parts today-ish.....
Latest update:
- I've kinda finalised the model of PID controller I will be getting from this project: a
REX-C100 rip-off. I learnt to ensure to get one designed for SSR control, as the relay model requires some additional surgery.
- Also, I have found out that this model is really designed for a K-Type thermocouple, so the PT100 RTD sensor is not viable. Oh well, at least cheap & easy to get.....
Thank you for the suggestion for depressurising the portafilter... I have indeed done so last weekend. You are right! A significant difference... I am getting a much fuller body in some shots. Why I say "in some shots" is because tamping is really new to me, and I am still using the plastic scoop/tamper that came with the Poemia.

The proper 53mm tamper is on order & should arrive perhaps tomorrow.
My findings so far:
- depressurized means tolerance for overextraction is very low.... I pulled an extra 10ml (16gm to 55ml is my usual target) to 65 ml and it was way bitter & had a burnt aftertaste.
- I still cannot get to the 25sec to 30sec extraction time.... so far only 16sec (same as pressurized). I tried grinding finer once no real difference & the taste was also slightly overextracted. However, most likely this was also contributed to a coffee-water ratio that was out due to quite a bit of grounds being lost due to levelling. Not used to finer grounds as this results in more air that makes it overflow. Now I grind halfway, shake/tap to redistribute, then grind the rest of the way. Will try again.
Thanks for the great pointer on setting a relatively stable temperature with your technique! I usually warm up the machine, pull a shot without any coffee to warm the portafilter (& use the hot water to further warm up the cup). Dry out the filter, grind & tamp the coffee, lock & pull. Works out to be about 15 extra seconds after the brew light comes on again. I find this give the max temperature without going into steam mode, but you are right... still way low.
So much to learn... so many things to try!!
