Did you upgrade to latest firmware?

So far no issues



All system up and running

Last reboot was due to power failure TNB maintenance

Is cloud key gen 2 available in Malaysia already?

yes.... if you see my post.. i did unbox mine... but mine is gen2+

Yup was using the Gen 1 ... latest firmware and kept crashing so decided to give up and moved to NAS.

Can’t really return it either as bought on Amazon , shipping it back wouldn’t be worth the hassle

Mine always stopped working after 1-2-3 days

Could it be the sd card failing?

No idea, it’s possible.

Anyway if I knew setting it up on NAS was so easy I probably wouldn’t have bothered buying a CloudKey anyway , considering that the NAS is running all day anyway.

I know yours was the plus edition. It’s nice but i wonder what’s price for both. I only have 2 AP, don’t need plus 🙂

Yea.. exactly what i did. Installed on my debian and xpenology.

nahh.. not telling you to get gen2+ if u have only 2 AP, why dont get the first gen CK? cheaper than gen2... normal i think about rm400+, gen2 estimated price around rm800+ i think. bought gen2+ around rm1k+

Guys i need some help here. My UAP-AC-LR keep reboot no stop. The LED light show: Steady white > Blinking white > Off > repeat again. Using cat6 connect from DLink router to UAP-AC-LR. It's possible cat6 cable too long ?

What i have try:
Reset UAP-AC-LR but still same keep reboot
Cat6 cable tested no issue

This post has been edited by Xteoh: Jan 31 2019, 09:46 PM

Max cable is 100m... so i dont think ur cable dat super long.. less than 5m? Should not be an issue... steady white blinking seems related with booting if i not mistaken..

This post has been edited by pandera999: Jan 31 2019, 11:00 PM

30M only from ground floor to first floor. Tomorrow I will retest again use other cable

This post has been edited by Xteoh: Jan 31 2019, 11:07 PM

should be fine. just curious. how you manage the AP? on your laptop? or have cloud key?

Do not use non full copper cat 5 the poe will lost it power . Use cat 6 no problem because it full copper

This is normal for cheap cable

Connection at LAN Port.
ISP : TIME
TP LINK :


EdgeRouter Lite

PC at ground floor

I'm using cat 6 cable connect my AP from POE switch

Later night will test again

I understand one straight forward way to setup VOIP on ubiquiti (I am using MAXIS Fibrenet ) is via the the VOIP port on the USG.

With the MAXIS router (TP-Link AC1200 C5v), I just connect the old fashion analog phone cable (with RJ11 connectors ?) directly into the TP-Link router. (I then have the old analog phone with extensions to 2 other phones around the house). So my question is what device/adaptor do I need that connects to the USG VOIP Port that will provide analog RJ11 ports ? (I prefer not to have to buy IP phones and retire my analog phone infrastructure)

What are my options ? Thanks

NOTE. I don't need a PABX system. I just want to be able to use my existing old fashion analog phones.

This post has been edited by teohes: Feb 3 2019, 07:09 PM

no malaysia dont have CK Gen2, most of distri only imported Gen2 Plus since it is integrated with NVR.

There is no other options other than getting a smart switch in between your fibre modem and routers.

Eg;
Fibre ---> smart switch ---> tag vlan 621 & 822 --> tplink --> phone
........................................\
..........................................--> tag vlan 621 --> USG

Yes, u need to tag both vlan 621 and 822 to make voip work on maxis homeline phone. Last year i only need to tag 822 and it works perfectly. But suddenly it needed 621 together to work. Weird but thats the only workaround i can find so far.

This post has been edited by wanttotree: Feb 4 2019, 09:47 PM

@wanttotree, I am trying to get my head around your use of the words “smart switch”. Is this like an ATA ? (I been reading abt FXO/FXS etc and just trying to work out the exact piece of hw I need to get to do this. Can you help with some examples of devices ? For example , will something like this do what I want?
