QUOTE(kianweic @ Aug 18 2016, 10:58 AM)
horns,
Given your extensive experience in SSDs, I would like to run this SSD configuration through you:
Current:
1. Samsung 850 SATA SSD for operating system (including Steam and sometimes AAA games but limited)
2. Normal Western Digital for everything else
Proposed:
1. Samsung m.2 950 for operating system (including Steam and some AAA games where permits)
2. Samsung 850 SATA SSD for games which require a lot of loading, usually AAA titles such as Fallout 4, Total Wars series and etc)
3. Normal Western Digital for everything else.
Would I be able to experience significant shorter loading time (particularly for games) and boot time comparison with the current setup?
Thank you.
at first glance, yes, the second configuration should have a relatively shorter load time for os and games, generally speaking. (that's how i set up my main rig basically) having said that, however, how many seconds that you can shave off from os and game loading time still depend on other factors that are more contributing, and how significant the time gap is to you is subjective, depending on individual expectations.
1. for os boot time, mobo and os - feature supports like fastboot and uefi boot from mobo and os will help a lot. we already have reports that 3 second is all you need to boot from a samsung 950 pro. however if you leave these two out of the speed optimization equation for boot time, no, you will not see significant boost with pcie ssd.
2. for game loading time, pcie ssd should be faster than sata ssd to load maps and textures because of its lower latency. well, it's not like what we are thinking also for certain games in real world. (most probably because these game files were accessed via 4k reads; usually 4k reads are at the same range for pcie and sata ssd, as of now)
http://techreport.com/review/28032/a-fresh...ith-pcie-ssds/5http://techreport.com/review/28050/intel-7...rive-reviewed/5i myself am fascinated with benchmark scores of pcie ssd, too; but benchmark is one thing, and real world usage is another. pcie ssd can only unleash its full power in intensive work processes that require high writes and iops, but not really in common usage or gaming. (except for the scenarios when you wanna capture your glories in games, then pcie ssd is good to go, but make sure a heat sink is used to help dissipate heat from the controller chip, just in case)
i still think pcie ssd as boot drive, and large sata ssd for game collection, and hdd for downloads and data storage is a go. it's an optimal choice for now imo.
.. and i am by no means someone with extensive experience in ssds. i just happened to test and read more hehe
edit: note that a good amount of system ram also helps to boost responsiveness.
This post has been edited by horns: Aug 18 2016, 03:25 PM
