what is BSEL actually?? i dont understand lah ^-^ ..

just link the pins i shown in last post will do..

does it have any side effect after doing it??

---

Added on October 20, 2009, 4:29 pmlepas links the pins, naik kan fsb jer..? cm2?

This post has been edited by eikhwan4: Oct 20 2009, 04:29 PM

guys... wanna ask... right now i'm running my e2140 @ 3.0ghz... vcore according to cpuz is 1.36v... i tried running 3.2ghz @ 400x8 but i got a bsod..
is it my proc cannot go any further or my pc not enough power from my psu... my psu is xigmatek 500w...

Did you increase core voltage? E2XXX generally start requiring higher voltage additions for speeds beyond 3ghz. Try 1.4-1.45V for 3.2ghz, if you have adequate cooling for the proc.

1. Lower down ur processor multiplier and set the FSB to default
2. take out the proc and link the pins together
3. boot up to check whether it's @ 300Mhz on giga G31 ES2L

---

Added on October 21, 2009, 5:22 pmLower down ur multiplier to check whether it's a FSB wall there.

This post has been edited by chchyong89: Oct 21 2009, 05:22 PM

Damn, same goes here but in my case, i cant even reach to 300Mhz of FSB .. more than that, it show the artifact thingy .. i have try on low multiplier 6x and also 7x but still the same result.. use easytune increase fsb by 5mhz and so on, but still got the limitation wall.. stress it for 8hours and its stable with no error at all .. help me guys..

using onboard graphic card? that's normal.. there is only two ways to solve it, install a vga on it, or BSEL ur processor.

This post has been edited by chchyong89: Nov 4 2009, 03:04 AM

oo ic.. kk that statement clearing me for now ^-^ ty so mch bro

Get a caplang gc also enough. Anything is better than the intel onboard n will allow oc-ing

just change ur proc bro..here's the new toy to play....bang for buck....hope everyone get one.. RM 160++ only..

wow....successor to E2XXX series. Nice. Is that max OC? I'm sure it can be pushed to 4ghz and beyond right?

My E5300



Attached thumbnail(s)

what's ur temperature for it

My Noob E6300




With OCCT 7 Hours @ 4.30Ghz

This post has been edited by sky5191: Dec 6 2009, 08:56 PM


Attached thumbnail(s)

Is that 24/7? The volts seem quite high

the new E6300 is the same as E5XXX except with VT correct?

E6300 is a 266x10.5 processor
2MB L2 Cache,VT Enable
Cost about RM20-RM30 more then E5300 which probably make it the best value for money processor ATM

Retired my E2160 for the second time. Its still pumping 3.6ghz on stock volts. Damn faithful processor

Any1 out there still playing OC with the original 65NM E2XXX series?

This post has been edited by joe_star: Jan 29 2010, 08:24 AM

my E2180 OCed @ 2.53GHz give me same temps which is 59 as stock @2.0GHz..

When OC'ed @2.8GHz max temps reach 65C... dont feel safe lol..

What's the max safe temp for this E2180? Still at Stock HSF with Tuniq TX-3.. thingking of getting CM Hyper TX3..

75'C still considered safe. Better not to exceed 80'C.
