QUOTE(eric_tan @ Sep 2 2009, 10:48 AM)
Hi,
I need to protect a PABX system that I will be installing in the the office soon. We have 3 incoming lines, thus I need to protect this 3 lines.
I think I need the following items. Can you confirm that?
MLPX9708-BB
SKPX modules x3
SL Series
OR
SP9201 x 3
SL Series
I would also be connecting a APC battery to the power source. Do I still need the SL series connected?
Tell me more about the RM10/year insurance. What would the setup be, to qualify for the insurance?
Eric
if u have puncher to punch the wire into MLPX9708-BB and the MDF module... you can choose the combination between MLPX9708-BB and SKPX-M... for the power source u can look for SL9602F or MDSC0039 (5A) as well...
but if u dont have the puncher and your PABX system come with RJ11 interface, then u can choose SP9201AR as well to protect the surge from tel line...
still recommended to protect your APC system, it no designed for lightning surge purposely... it lightning hit your APC, the surge may bypass it and going toward to your PABX system...
insurance only valid for complete protection setup which the surge may no able to come from other source, for ur case may no efficient enough because the surge may able come from the extension (telephone) line which no protected and the surge still able to direct into your PABX system...
