 Sandy Bridge Overclocking V1, 2500K/2600K/2700K | LGA1155 P67.Z68.Z77

views

TSowikh84
post Mar 21 2011, 11:56 PM

i7 Clan
Group Icon
Elite
8,711 posts

Joined: Nov 2007
From: Butterworth, PG / Machang, Kelantan



QUOTE(FiragaZ @ Mar 21 2011, 03:20 PM)
Ya, the temp is a bit high, so i roll back to my previous solid hard rock 4.6ghz, only max 74c while running 50x linx. And i found my 4.8ghz is not stable yet, even i ran 50x linx and 1hour prime95, after that i just open winamp listen music and viewing picture in my folder den blue screen.

U knw TMPIN0 temp is from which system component? It hits 79c lol.
*
TMPIN0 = cpu temp
TMPIN1 = case temp
TMPIN2 = mobo temp

Intel Core i7 2600K @ 4.99 GHz (4C/8T) = 104 X 48
Gigabyte P67A-UD7 B3 F2
2x2GB G.Skill RipjawsX F3-17000CL8D-4GBXMD 2133C8 @ 2218Mhz 8-9-8-1T
2x MSI GTX580 SLI, 930/4100Mhz
Corsair AX1200


» Click to show Spoiler - click again to hide... «


* pls ignore the overvoltaging biggrin.gif
** cpu-z reads vcore wrongly.

This post has been edited by owikh84: Mar 22 2011, 12:05 AM
louislkw
post Mar 22 2011, 12:07 AM

Casual
***
Junior Member
434 posts

Joined: Jul 2010
From: ^Newbie^


Trial run, not the limit yet and sub-timing not optimised as well

user posted image
FiragaZ
post Mar 22 2011, 09:39 AM

No Pain No Gain
******
Senior Member
1,745 posts

Joined: Aug 2010
From: Kuala Lumpur


is oc ram related to oc cpu?
TSowikh84
post Mar 22 2011, 09:55 AM

i7 Clan
Group Icon
Elite
8,711 posts

Joined: Nov 2007
From: Butterworth, PG / Machang, Kelantan



QUOTE(FiragaZ @ Mar 22 2011, 09:39 AM)
is oc ram related to oc cpu?
*
Both are tied by BCLK thats da relationship between CPU and RAM.
But i dont see the needs to increase vcore when increase dram from 1866 to 2133.
Arghhh i miss my Maximus!!!
limsa007
post Mar 22 2011, 11:48 PM

New Member
*
Junior Member
29 posts

Joined: Jan 2007
From: Penang


Hi, just success oc my 2500k @ 4.6ghz with hyper 212+ dual blade master.

user posted image

is that ok for 24/7 run?
TSowikh84
post Mar 23 2011, 11:09 AM

i7 Clan
Group Icon
Elite
8,711 posts

Joined: Nov 2007
From: Butterworth, PG / Machang, Kelantan



QUOTE(limsa007 @ Mar 22 2011, 11:48 PM)
Hi, just success oc my 2500k @ 4.6ghz with hyper 212+ dual blade master.
is that ok for 24/7 run?
*
Look fine for 24/7, the load temp is lower if not running stress tests.
arslow
post Mar 23 2011, 04:16 PM

Look at all my stars!!
*******
Senior Member
3,544 posts

Joined: Sep 2008


wat do uguys think is a better choice?

msi p67a-gd55 vs asrock p67 extreme4

(using for i5 2500k and max oc will be 4.0ghz biggrin.gif
kevink82
post Mar 23 2011, 04:47 PM

Regular
******
Senior Member
1,134 posts

Joined: Apr 2008


If max u gonna go is 4 ghz then just pick the one that looks best for you they can all do that with auto overclocking to 4 ghz no problem.
limsa007
post Mar 23 2011, 07:00 PM

New Member
*
Junior Member
29 posts

Joined: Jan 2007
From: Penang


QUOTE(owikh84 @ Mar 23 2011, 11:09 AM)
Look fine for 24/7, the load temp is lower if not running stress tests.
*
after that stress, i do some chatting and browsing, then i run 3Dmark vantage, after 3dmark, bsod.... is that psu problem? cos im using old enermax fma2 465W, and runing 5750. plan to save money get 850W or 1kW
bios setting vcore 1.4v, PLL 1.85v, other auto.

QUOTE(arslow @ Mar 23 2011, 04:16 PM)
wat do uguys think is a better choice?

msi p67a-gd55 vs asrock p67 extreme4

(using for i5 2500k and max oc will be 4.0ghz biggrin.gif
*
msi have the 1 button oc, im using gd65 with 2500k, 1 click i get 4.2ghz drool.gif
TSowikh84
post Mar 23 2011, 07:30 PM

i7 Clan
Group Icon
Elite
8,711 posts

Joined: Nov 2007
From: Butterworth, PG / Machang, Kelantan



QUOTE(limsa007 @ Mar 23 2011, 07:00 PM)
after that stress, i do some chatting and browsing, then i run 3Dmark vantage, after 3dmark, bsod.... is that psu problem? cos im using old enermax fma2 465W, and runing 5750. plan to save money get 850W or 1kW
bios setting vcore 1.4v, PLL 1.85v, other auto.
msi have the 1 button oc, im using gd65 with 2500k, 1 click i get 4.2ghz  drool.gif
*
what's the code of the BSOD? pls refer to Post #1 for details.
If it's one of the listed then should be a bad OC especially the auto settings as these will changed randomly on every reboot.
bad PSU is possible for sure higher wattage offers better OC etc.. nod.gif
limsa007
post Mar 23 2011, 09:59 PM

New Member
*
Junior Member
29 posts

Joined: Jan 2007
From: Penang


QUOTE(owikh84 @ Mar 23 2011, 07:30 PM)
what's the code of the BSOD? pls refer to Post #1 for details.
If it's one of the listed then should be a bad OC especially the auto settings as these will changed randomly on every reboot.
bad PSU is possible for sure higher wattage offers better OC etc.. nod.gif
*
0x124 - but my bios dont have VTT/QPI... left I/O and SA voltage to play around..
TSowikh84
post Mar 23 2011, 11:04 PM

i7 Clan
Group Icon
Elite
8,711 posts

Joined: Nov 2007
From: Butterworth, PG / Machang, Kelantan



QUOTE(limsa007 @ Mar 23 2011, 09:59 PM)
0x124 - but my bios dont have VTT/QPI... left  I/O and SA voltage to play around..
*
If u read again my post, 124 is related to insufficient vcore.
I saw u ran linX in diagnosis mode, may be in normal windows environment u need extra vcore.
one of the reason why i dun wana use diag mode. now linX again in normal mode tongue.gif

limsa007
post Mar 24 2011, 03:33 AM

New Member
*
Junior Member
29 posts

Joined: Jan 2007
From: Penang


QUOTE(owikh84 @ Mar 23 2011, 11:04 PM)
If u read again my post, 124 is related to insufficient vcore.
I saw u ran linX in diagnosis mode, may be in normal windows environment u need extra vcore.
one of the reason why i dun wana use diag mode. now linX again in normal mode  tongue.gif
*
user posted image

finally get 4.5ghz on stable voltage setting, tested 3Dmark, din get BSOD anymore, much more stable then 4.6ghz.. and i din use auto, i set to all default voltage.

thanks notworthy.gif
FiragaZ
post Mar 24 2011, 01:16 PM

No Pain No Gain
******
Senior Member
1,745 posts

Joined: Aug 2010
From: Kuala Lumpur


QUOTE(limsa007 @ Mar 24 2011, 03:33 AM)
user posted image

finally get 4.5ghz on stable voltage setting, tested 3Dmark, din get BSOD anymore, much more stable then 4.6ghz.. and i din use auto, i set to all default voltage.

thanks notworthy.gif
*
nice temp u got there, we got the same cpu and mobo tongue.gif
TSowikh84
post Mar 24 2011, 08:46 PM

i7 Clan
Group Icon
Elite
8,711 posts

Joined: Nov 2007
From: Butterworth, PG / Machang, Kelantan



Intel Core i7 2600K @ 5.04 GHz (4C/8T) = 105 X 48
Gigabyte P67A-UD7 B3 F3C
2x2GB G.Skill RipjawsX 2133C7 @ 2240Mhz 7-10-7-27-1T
2x MSI GTX580 SLI, 930/4100Mhz
Corsair AX1200


» Click to show Spoiler - click again to hide... «

** cpu-z reads vcore wrongly.
» Click to show Spoiler - click again to hide... «


This post has been edited by owikh84: Mar 24 2011, 09:03 PM
Peculator
post Mar 25 2011, 07:40 AM

Getting Started
**
Junior Member
268 posts

Joined: Nov 2010
From: 京都市
Hi tech gurus out there, thinking to build my first custom PC so I need recommendations on sandy bridge mobo with its proc combo as well.
zathaf87
post Mar 25 2011, 01:19 PM

New Member
*
Junior Member
38 posts

Joined: Feb 2010
From: Pahang Darul Makmur



hi there, i'm new sandy bridge user n i noob about oc doh.gif .....wanna ask if i can oc i3 2100?? i do some research n some say can but cannot go more than 3.8 hmm.gif , ....donno...please any "sifu" can help me?? icon_question.gif
duboisi
post Mar 25 2011, 01:56 PM

Casual
***
Junior Member
490 posts

Joined: Nov 2010
From: Damansara Perdana



QUOTE(zathaf87 @ Mar 25 2011, 01:19 PM)
hi there, i'm new sandy bridge user n i noob about oc doh.gif .....wanna ask if i can oc i3 2100?? i do some research n some say can but cannot go more than 3.8  hmm.gif , ....donno...please any "sifu" can help me??    icon_question.gif
*
If not mistaken, 2100 is locked and does not support turbo and therefore you can only oc via BCLK, which means about 5% OC. Let others confirm this.
zathaf87
post Mar 25 2011, 02:09 PM

New Member
*
Junior Member
38 posts

Joined: Feb 2010
From: Pahang Darul Makmur



QUOTE(duboisi @ Mar 25 2011, 01:56 PM)
If not mistaken, 2100 is locked and does not support turbo and therefore you can only oc via BCLK, which means about 5% OC. Let others confirm this.
*
BCLK = Baseclock?? hmm.gif
duboisi
post Mar 25 2011, 03:25 PM

Casual
***
Junior Member
490 posts

Joined: Nov 2010
From: Damansara Perdana



QUOTE(zathaf87 @ Mar 25 2011, 02:09 PM)
BCLK = Baseclock??  hmm.gif
*
Yep.
