QUOTE
Guys.. want to ask.. is the cpu of a notebook and a desktop different? the pins, size, etc etc...?
Also the graphic cards are quite different right?
If i buy a barebone. the ram & hdd isn't hard to get. But where can get a cpu & graphic cards for notebook in malaysia?
Yes, the mobile CPUs differ from their desktop counterparts. Some notebooks do use desktop CPUs, but their battery life is compromised meaning that they won't last very long. Be sure to check up on which platform (Montevina / Santa Rosa) the mobo is, as the latest penryn mobile CPUs are not compatible with Santa Rosa.Also the graphic cards are quite different right?
If i buy a barebone. the ram & hdd isn't hard to get. But where can get a cpu & graphic cards for notebook in malaysia?
The latest mobile CPUs are socket P and have 478 pins. Typically having the TDP of 25W. Generally, in my laptop's case (NP8660 based on M860TU), I can switch my P8400 to P9600 on-the-fly without having to flash its BIOS or modding. Mobile C2Qs, however, are not compatible with the NP8660, only the NP8662, which has a revised mobo. The NP8660 can be also affixed with an extreme C2D, however the price for such a CPU is abysmally high.
The laptop's GPU, if it is even upgradeable, should be in MXM form factor, High performance laptops have MXM 2.1 type III/IV module. Now with the advent of MXM 3.0 type A/B, I think newer laptops will be using such form factor. I suggest paying mxm-upgrade.com a visit.
But even then, having the right form factor is never enough for a laptop GPU, the mobo's bios must recognize the device or else the laptop would
1) not POST
2) display an error regarding the unrecognized mxm device
Furthermore, the TDP of a card you want to affix to the laptop must be taken into account, as different types of mxm card has different TDP. Lastly, we have the heat dissipation factor. This is a factor that is not to be taken lightly, even if you DO manage to fit the card in and boot up, but if it's not within the thermal budget of the laptop, it is basically useless as it is unstable and may crash constantly or downclock, whichever comes first, when gaming.
Getting mobile CPUs and GPUs are hard. You may be able to buy them from the vendor that is selling you the barebone of a laptop, this is advisable as the vendor knows what is compatible and what is not.
Going on E-bay is fine too, a seller called extremeprocessor is famous for selling ES Intel processors. GPUs however, are rare and expensive, The most latest mxm based GPUs are usually not sold individually, but, there might be an exception to foreign websites, which do sell parts of laptops to others. Some require you to be an existing customer of their company and some don't.
All in all, if you're staying in Malaysia, I don't really see the point in buying a barebone, with the shipping cost taken into consideration and all that.
This post has been edited by 22: Mar 28 2009, 02:03 PM
Mar 28 2009, 02:00 PM
