 Lowyat.Net's Watercooling Club, Pictures of setups & screenies !

views

DaRkSyThE
post Aug 30 2008, 02:48 PM

Look at all my stars!!
Group Icon
VIP
4,809 posts

Joined: Jan 2005
depends la
i can bend my tygons more.
masterkleer is nice if you have colored coolants i guess
DaRkSyThE
post Aug 30 2008, 06:06 PM

Look at all my stars!!
Group Icon
VIP
4,809 posts

Joined: Jan 2005
actually to be honest, i think ghetto tubes are good enough.
ACE sells cheap ones and they're good enough.
doubt the extra special properties of the tubes will help that much ><
DaRkSyThE
post Sep 1 2008, 11:33 AM

Look at all my stars!!
Group Icon
VIP
4,809 posts

Joined: Jan 2005
» Click to show Spoiler - click again to hide... «


eh bro, i think youre loop is suffering a serious pressure drop.
your pump shouldnt be pumping into the GPU and CPU at once.
it should be into cpu and then into gpu.
like that its very uneven and defeats the purpose of getting a etup like that leh
DaRkSyThE
post Sep 1 2008, 03:27 PM

Look at all my stars!!
Group Icon
VIP
4,809 posts

Joined: Jan 2005
im not sure how the flow rate will be, but i am pretty sure that the pressure will drop quite significantly cause its like pushing water thru two seperate ways.

well, im not sure myself cause i dont do it so i dont have any results to back me up tongue.gif
DaRkSyThE
post Sep 1 2008, 07:10 PM

Look at all my stars!!
Group Icon
VIP
4,809 posts

Joined: Jan 2005
QUOTE(IcEMoCHa @ Sep 1 2008, 05:03 PM)
actually that setup is better than going thru cpu then into gpu block however you will need a pump with high flowrate and decent hmax... lets say 2400lph?... lol  biggrin.gif because as you split the pump output into 2, ur flowrate is divided half to both sides... lets say a 1200lph pump is only pumping 600lph thru each block... but i've seen this setting before...

Rad>Res>splitter>pump1>cpu block>join>back into Rad
---------------------->pump2>gpu block>^---------------------

the performance is a lot better than the above setup i would say..
*
dude, thats as good as having two separate loops tongue.gif
that would be better tongue.gif

of course that config is better but take into consideration 2 pumps. and quite a lot of tube mess if you have a small case
DaRkSyThE
post Sep 2 2008, 04:50 PM

Look at all my stars!!
Group Icon
VIP
4,809 posts

Joined: Jan 2005
QUOTE(truzoids @ Sep 2 2008, 01:14 AM)
that loop inside my case dont have same flowrate..that is what i believe... splitting into two way will not make it split the flowrate into half...coz i used d-tek fuzion water block.

this water block have high surface area and high resistance.thus will cause the more flowrate will flow to low resistance area...that what i know from fluid machanic study.

now i still thinking to find best solution to make it really effectie loop... hmm.gif plus both of that thing produce so much heat when running on vista ultimate.

my target is to make it run at 39 - 42 degree...
that gpu success but cpu fail coz idle at 48 - 50
that casing sure stuck with tubing..soon will get one HAF-932 and put complete anti kink coil for all tube... brows.gif
*
bro, never said that your flowrate wil cut into half.
it doesnt, and using a dtek fuzion doesnt mean that your flow rate will be cut into half either. tongue.gif
thats wrong. laugh.gif

well, im not trying to find fault with you.
just that i think your loop can perform way better biggrin.gif
DaRkSyThE
post Sep 2 2008, 10:15 PM

Look at all my stars!!
Group Icon
VIP
4,809 posts

Joined: Jan 2005
yeah and the pro steps into the scene eh? tongue.gif
shucks, i was trying to explain it like that but i had no idea.
just goes to show my knowledge is still sooo shallow tongue.gif
DaRkSyThE
post Sep 3 2008, 04:20 PM

Look at all my stars!!
Group Icon
VIP
4,809 posts

Joined: Jan 2005
QUOTE(truzoids @ Sep 3 2008, 04:17 PM)
still dont understand why clouding happen...before this i make an experiment with chlorine gas go through pvc tube...in a minute the tube become clouding... it is not clear as ori before experiment... so i sure that cl2 cause it not algae...

need to check which chem compound can cause it happen..
*
why did you pass cl2 in the first place?
normally our loops dont even have chlorine inside unless youre not on distilled water.
DaRkSyThE
post Sep 10 2008, 08:02 PM

Look at all my stars!!
Group Icon
VIP
4,809 posts

Joined: Jan 2005
QUOTE(lichyetan @ Sep 10 2008, 07:36 PM)
jet impingement based waterrblock = storm type design...(go google around)
non- jet impingement type = apogee gt etc

fuzion with nozzle kit i dunno wat type oso... hehe
*
non-jet impigment IIRC
DaRkSyThE
post Sep 11 2008, 08:29 PM

Look at all my stars!!
Group Icon
VIP
4,809 posts

Joined: Jan 2005
QUOTE(LExus65 @ Sep 11 2008, 07:22 PM)
yakah, iwaki so terror........ must go and do some research....
*
lo, iwaki are hardcore pumps leh

Ehiem on the other hand, there are several models.
DaRkSyThE
post Sep 13 2008, 09:55 AM

Look at all my stars!!
Group Icon
VIP
4,809 posts

Joined: Jan 2005
QUOTE(IcEMoCHa @ Sep 12 2008, 11:58 AM)
can.. tubing RM10, pump RM40, Custom res(pail for ice) RM3, Cheap water block RM100+ and ice RM1 for 1 bag.. expected to go below 10C..  brows.gif add salt into water for lower temps...  biggrin.gif
*
apa ice.
use la dry ice smile.gif
DaRkSyThE
post Oct 14 2008, 10:41 PM

Look at all my stars!!
Group Icon
VIP
4,809 posts

Joined: Jan 2005
QUOTE(_707027_ @ Oct 13 2008, 05:24 PM)
what a close up view laugh.gif
this one is a one great waterblock.
performs much more better than its sibling, V1.  smile.gif
*
you can always bow your V1.
some people "cough" "cough" bryan "cough" "cough" says that it performs almost on par smile.gif
DaRkSyThE
post Oct 19 2008, 08:24 PM

Look at all my stars!!
Group Icon
VIP
4,809 posts

Joined: Jan 2005
QUOTE(OC4/3 @ Oct 15 2008, 02:55 AM)
Bow V1 void warranty??
And V2 come with pro mounting kit for s775 stock thumbup.gif
*
yes when you bow it definitely.
but then, why do we need warranty for a waterblock? tongue.gif

QUOTE(IcEMoCHa @ Oct 15 2008, 04:00 PM)
eh bro u retired from OC ka?... long time didn't see u active here..
*
no la. just inactive.
i had my Trials and now SPM

QUOTE(dro @ Oct 16 2008, 08:49 AM)
i tink he's in his SPM week
saw it sumwhere in the forum smile.gif
*
kinda true.
DaRkSyThE
post Oct 25 2008, 08:33 PM

Look at all my stars!!
Group Icon
VIP
4,809 posts

Joined: Jan 2005
ok this is kinda sad, no matter how well i clean my rad there is still sediments inside. grr..
almostthere, tolong please

there are white specs inside my res. looks like crytalised salt.
it could be salt from whatever ions that lurk inside my loop haha
DaRkSyThE
post Oct 26 2008, 12:35 PM

Look at all my stars!!
Group Icon
VIP
4,809 posts

Joined: Jan 2005
QUOTE(IcEMoCHa @ Oct 25 2008, 08:49 PM)
hmm... i clean it this way...

1)flush with a lot of water at high pressure
2)pour clorox into it and leave it for a minute then flush again
3)pour boiling water into it leave it for 5 minutes then flush and repeat step again
4)flush through with some soap power and then flush with clean water
5)rad cleaned and ready to rock...  rclxms.gif
*
are you sure about that?
haha ive already flushed it out with high pressure water plus i added loads of vinegar countless times

eh where is this almostthere tongue.gif

Added on October 26, 2008, 12:36 pm
QUOTE(OC4/3 @ Oct 26 2008, 01:52 AM)
Got add biocide?Mind to take a picture?
Is it like some kind of white thingy sticking at res?
*
its like sticking on the wall of my res.
people always report that their loops get cloudy after a while. same thing here

This post has been edited by DaRkSyThE: Oct 26 2008, 12:36 PM
DaRkSyThE
post Nov 28 2008, 11:07 PM

Look at all my stars!!
Group Icon
VIP
4,809 posts

Joined: Jan 2005
QUOTE(lichyetan @ Nov 22 2008, 01:43 PM)
i placed it after the rad.
*
dude you wanna try something extreme?

ok heres the thing
my concept la. works or not no idea(but it may not)

at the exit of the water from the rad, where your bard is screwed in. try placing the peltier there with some thermal conductive paste or whatever but the contact has to be tight between the rad and the perltier and the heat sink of course.
DaRkSyThE
post Jan 8 2009, 08:35 PM

Look at all my stars!!
Group Icon
VIP
4,809 posts

Joined: Jan 2005
QUOTE(aii @ Jan 6 2009, 08:03 PM)
hey, may i ask..
where did u buy that cooling system?
*
haha i used to sell it.
you can get it straight from the states of go to the dark alleys of LYN to find it biggrin.gif
DaRkSyThE
post Mar 1 2009, 09:08 PM

Look at all my stars!!
Group Icon
VIP
4,809 posts

Joined: Jan 2005
QUOTE(general_odin @ Mar 1 2009, 02:17 AM)
great... thats way out of my budget...
thanks for the advice and i'm trowing this project into the recycle bin...
hey where's the recycle bin.... lol

eh, what about peltier? is it good? does it consume alot of power ?
need advice biggrin.gif

Thanks
*
some people are quite against pelts
id just stick with a basic watercooling
DaRkSyThE
post Mar 5 2009, 12:12 PM

Look at all my stars!!
Group Icon
VIP
4,809 posts

Joined: Jan 2005
bryan, tygons tubes ah? tongue.gif
eh i noticed the 90 degree elbow joint below the res
doesnt affect the pressure?

**i want my elbow joints fast. then my turn to revamp my watercooling system tongue.gif **

This post has been edited by DaRkSyThE: Mar 5 2009, 12:13 PM
DaRkSyThE
post Mar 10 2009, 10:54 PM

Look at all my stars!!
Group Icon
VIP
4,809 posts

Joined: Jan 2005
QUOTE(boland89 @ Mar 7 2009, 11:05 AM)
hii..im new in LCS here..
i has a nobe question..
im now usg TT 760i..
upgrade with 2rad,chipse and VGA waterblock..
the pump was so slow.
can i put 2 pump??
any pump recomended for 3/8tube??
help me plsss..
*
you can put two pumps but really, i dont see much point since the current setup isnt that good to begin with
if i were you, i'd save up for a whole new set, much more worth the money if you ask me smile.gif

well, if you wanna get a pump, depends on your budget smile.gif
