10900k - SP81
M12E - Bios 098

50|45@ 1.33v L4
4x8gb 4133 17-17-17-37@1.4v
vccio/vcssa 1.15/1.15



This post has been edited by cstkl1: Aug 4 2020, 08:26 AM

fft112 test
adjusted trdwr_sg/dg to 11 finally


10900k -SP81
M12E - Bios 098

50|45@1.33 L4
4x8gb 4133 17-17-17-37@1.4v
vccio/vcssa 1.15/1.15




now how to test cache 47 next.. hmm linpack & hci was top easy.. so its either fft112..
edit
tested fail on the 7th min. so looks like a good way to test cache.

4133 Final


10900k - sp81
M12E - Bios 098

50|48 @1.33v L4
4x8gb 4133 17-17-17-37@1.4v
vccio/vcssa @1.17/1.175
MCH FULLCHECK enabled

10900k - SP81
M12E Bios 098

51|48 @ L6 adaptive Auto
4x8gb 4000 15-16-16-36@1.45v
PPD 0
vccio/vcssa 1.15/1.15



for ppl who want to run their 4kc15 kits..

Testing BIOS 0098, finally managed to stabilize this after multiple trials...

10900K @ 5.1/4.6 @ 1.20v LLC8
Maximus XII Formula | BIOS 0098
B-die 4x8GB 4133 CL17-17-17-37-2T @ 1.40v
VCCSA 1.25v, VCCIO 1.20v, TXP 4, PPD 0 at boot





Some 4200 CL17 fun, not gonna be 24/7 stable though...

B-die 4x8GB 4200 CL17-18-18-38-2T @ 1.45v


This post has been edited by owikh84: Aug 10 2020, 10:37 PM

10900k - SP81
M12E - BIOS 0606

51|48 v/f 1.274@L6
2x16gb 4400 16-17-17-36@1.5v
vccio/vcssa 1.25/1.25

10900k-SP81
M12E-Bios 098

53|51@v/f 1.414 L6
2x16gb 4600 16-16-16-36@1.6v
txp/ppd 0|0
vccio/vcssa 1.35/1.35




Final Daily


10900k-SP81
M12E-Bios 098

51|48@v/f 1.274 L6
2x16gb 4400 18-18-18-38@1.4v
txp/ppd 0|0
vccio/vcssa 1.25/1.25



This post has been edited by cstkl1: Sep 14 2020, 09:20 AM

FFT112

10900k - SP81
M12E - Bios 098

51|48 - 1.273 v/f L6 vmin 1.15xx
2x16gb 4400 18-18-18-38 @1.40v
vccio/vcssa - 1.3/1.3
txp/ppd - 0/0


52|49 -1.373 v/f L6 vmin 1.24xx
2x16gb 4400 18-18-18-38 @1.40v
vccio/vcssa - 1.35/1.35
txp/ppd - 0/0



This post has been edited by cstkl1: Sep 16 2020, 11:17 AM

Starting to see Core I5-10600K availability. RM1199.

"i believe i can fly"
gonna be doing tuf 3080 testing


10900k - SP81
M12E - Bios 098

51|48 v/f 1.274 L6
txp/pp - 0/0
2x16gb 4133 15-16-16-35 @1.5v
vccio/vcssa -1.00/1.100



2x16gb 4400 16-17-17-36 @1.5v
vccio/vcssa - 1.30/1.30

10900k@SP63
M12F-098

Gskill Trident Z Royal F4-4266C17D-32GTRGB

51|48 - v/f 1.36 LL6
2x16gb 4300 16-17-17-36 @1.5v
vccio/vcssa - 1.25/1.25
txp/ppd - 0/0






feedback.. this board trains differently than m12E.. the sequence etc etc...

This post has been edited by cstkl1: Sep 25 2020, 10:23 AM

10900k@SP81
M12E - Bios 098

Gskill Trident Z Royal F4-4000C17D-32GTRSB

51|48 - v/f 1.274 LL6
2x16gb 4533 16-17-17-36 @1.55
vccio/vcssa - 1.4/1.35
txp/ppd - 0/0




cl16/cl17 stuck at 4500.. hmm trying to figure out this problem. benching all cls at 4600 no issue but stable hmm cl16 easiest.

Last bench before 11th Gen and Z590

10900K SP94
M12F BIOS 2002
G.Skill Trident Z Royal F4-4000C17D-32GTRSB

5.3GHz OC TVB LL6
2x16GB 4266 CL16-17-17-36 @1.50V
VCCSA/VCCIO - 1.25/1.25V





Thanks to bro cstkl1 for the guidance

Okay can't resist myself from keep benching LOL...

10900K SP94
M12F BIOS 2002
G.Skill Trident Z Royal F4-4000C17D-32GTRSB

5.3GHz OCTVB LL6
2x16GB 4400 CL16-17-17-36 @1.55V
VCCSA/VCCIO - 1.35/1.35V

mine :

CPU-z Validation : https://valid.x86.fr/j0vnxj

Description
- Update ME 14.1
- Support Re-size BAR function to enhance GPU performance including the Nvidia GeForce RTX 3000 series and others.
- BIOS updated to be compatible with 11th Gen Intel Processors
- Improved compatibility of PCIe-based devices.


anyone tried this new bios from intel which supports resize bar yet on z490 chipsets?

This post has been edited by Bonchi: Feb 17 2021, 06:04 PM

I did but don't see any benefit cos I'm using an NVIDIA GPU.
Can't wait for that new driver and vBIOS.

Need some advice on my klevv bolt XR DJR DR settings:



VCCSA 1.2V VCCIO 1.18V VDIMM 1.48V. Ring is max at X40 on the 10400F

messed with trefi set to 31200 and most of the sub timing are left as it is on auto.
Tfaw is auto @ 42. set to 16 and actually got higher latency and lower bandwidth, not sure why (current settings passed memtest86 8 passes)

Pretty hard getting it to boot with anything lower then current settings. adding more VCCSA and VCCIO up to 1.3v doesnt seem to help at all.

Perhaps a bad IMC or bad lottery DIMM but still wondering what could improve the read speed. altho the aida value is quite inconsistent. it can get up to 57K but hopefully can hit closer to 60K.

This post has been edited by Bonchi: Apr 12 2021, 04:58 PM

try tRFC 630

Anyone still benching 4x8GB DIMMs? 🤣
Here's my random B-die SR kits of F4-4266C19D-16GTZR on Maximus XIII EXTREME Z590...




4x8GB 4266 17-17-17-37-1T @ 1.50v with 11900K RKL


4x8GB 4200 17-17-17-37-2T @ 1.50v with 10900K CML


#ASUS #ROG #MAXIMUS #EXTREME #RocketLake

This post has been edited by owikh84: May 22 2021, 10:14 PM
