Hey i got 54db for line attenuation .. how to improve the statistics? From the 1st page, if 50db~60db is poor and might experience connectivity issues .. please advise thank you

---

Added on June 9, 2010, 8:16 pmMy stats

SNR Margin
:
26.5 22.0 db
Line Attenuation
:
54.0 31.5 db
Data Rate
:
1536 512 kbps
Max Rate
:
7136 1136 kbps
POWER
:
16.0 12.0 dbm

On the left is downstream, on the right is upstream

This post has been edited by xMika: Jun 9 2010, 08:16 PM

Status
Configured Current
Line Status --- SHOWTIME
Link Type --- Interleaved Path


Data Rate
Stream Type Actual Data Rate
Up Stream 506 (Kbps.)
Down Stream 5114 (Kbps.)


Operation Data
Operation Data Upstream Downstream
Noise Margin 41 dB 30 dB
Attenuation 12 dB 17 dB

Defect Indication
Indicator Name Near End Indicator Far End Indicator
Fast Path FEC Correction 0 0
Interleaved Path FEC Correction 0 0
Fast Path CRC Error 0 0
Interleaved Path CRC Error 0 0
Loss of Signal Defect 0 ---
Fast Path HEC Error 0 0
Interleaved Path HEC Error 0 0


is this good???

Hi,

Need help if anyone can advice my line status and what need to be done. it seems Line Attenuation is high right?


Noise Margin - UPstream : 25
Noise Margin - Downstream :12

Attenuation - Upstream : 31
Attenuation - Downstream : 59

Data rate(Kbps) - Upstream : 512Kb
Data rate(Kbps) - Downstream : 1344Kb

hi, anyone can help me clarify my doubt regarding the SNR margin for the Upstream for my modem

modem problem ?
can u try other modem to see if it modem problem or not?

Mode: ADSL2+
Line Coding: Trellis On
Status: No Defect
Link Power State: L0

Downstream Upstream
SNR Margin (dB): 25.8 21.0
Attenuation (dB): 50.5 27.2
Output Power (dBm): 12.2 0.8
Attainable Rate (Kbps): 6024 540
Rate (Kbps): 1535 506
MSGc (number of bytes in overhead channel message): 60 70
B (number of bytes in Mux Data Frame): 47 15
M (number of Mux Data Frames in FEC Data Frame): 1 1
T (Mux Data Frames over sync bytes): 1 1
R (number of check bytes in FEC Data Frame): 0 0
S (ratio of FEC over PMD Data Frame length): 0.9796 0.9481
L (number of bits in PMD Data Frame): 392 135
D (interleaver depth): 1 1
Delay (msec): 0 0

Super Frames: 19360 17287
Super Frame Errors: 0 1
RS Words: 0 0
RS Correctable Errors: 0 0
RS Uncorrectable Errors: 0 N/A

HEC Errors: 0 0
OCD Errors: 0 0
LCD Errors: 0 0
Total Cells: 1132229 358971
Data Cells: 27924 5492
Bit Errors: 0 0

Total ES: 93 1
Total SES: 75 0
Total UAS: 82 26

This is my SNR margin, U see my problem is very very funny and it happen normally in the morning most days. When i awake and try to suft net, i found my browsing speed is very slow so i check my router statistics, it show that my SNT margin for downstream is like 0.1-10 which is very low but funny part is i just need to pick up my house telephone, without making any calls just wait for few second the SNR margin back to normal again. This already happen two months ago yet TM still cant solve it... try resetting port, downgrade to 1MB due to my area cant support 4mb.. bla bla but the same.. The only way to resolve this problem every morning is to pick up my house phone and wait for short while and SNR margin back normal.. sometimes it hav to be done for few times only to get back stable..

What the hell is this funny thing? why each time need to pick up my house phone in order to gain back SNR margin? Any idea? since TMnut cant even solve it..Zzzz

Hi, can I know where to check the snr margin in my Riger DB102 modem? Thanks.

Guys,

Sometimes around 8pm to next morning, the line become unstable or very slow speed, during the day, the speed was around 1.3mbps to 1.6mbps.
However, during the night it can be 0.2mbps to 0.3mbps only.. BTW, im subscribing 1mb package.

If I subscribe to 4.0mbps package, will it increase the night time speed to at least 1.6mbps? or still become 0.2 to 0.3 mbps?

Anybody subscribing to 4.0mbps having slow speed to less then 1mbps?

mine is as below pls advice

noise margin upstream: 23 db
output power downstream: 0 db
attenuation upstream: 3 db

noise margin downstream: 33 db
output power upstream: 9 db
attenuation downstream: 0 db

how to set the modem type and modem port? ><

hello, i think i experience the same problem with you, i didnt notice the snr margin but my attainable download rate and actual download rate drop drastically, usually i get 2048kbps for dwnld and 512kbps for upld but sometimes dwnld rate drop to about 100-500kbps but upld rate stays the same.. sometimes i pick up the phone and then put it back and the speed comes back to normal...

haiz damn sienz... just moved to pj ss2. the line attenuation 60db + really cjb. at kota damansara my line attenuation up stream and downstream 0db.

i got a slow line speed...
below is mine config, any adv?

Mode: G.DMT
Type: Interleave
Line Coding: Trellis On
Status: No Defect
Link Power State: L0

Downstream Upstream
SNR Margin (dB): 18.6 4.0
Attenuation (dB): 48.0 23.5
Output Power (dBm): 0.9 16.9
Attainable Rate (Kbps): 768 1120
Rate (Kbps): 640 512
K (number of bytes in DMT frame): 21 17
R (number of check bytes in RS code word): 16 16
S (RS code word size in DMT frame): 8 8
D (interleaver depth): 8 8
Delay (msec): 16 16

Super Frames: 2560185 2560092
Super Frame Errors: 0 0
RS Words: 21761576 21760782
RS Correctable Errors: 819 13
RS Uncorrectable Errors: 0 N/A

HEC Errors: 0 0
OCD Errors: 0 0
LCD Errors: 0 0
Total Cells: 65695695 0
Data Cells: 8653516 0
Bit Errors: 0 0

Total ES: 51 0
Total SES: 26 0
Total UAS: 301 0

SNR Margin (dB): 25.9 21.0
Attenuation (dB): 44.0 23.5
Output Power (dBm): 12.2 18.6
Attainable Rate (Kbps): 5216 1096
Rate (Kbps): 1536 512
K (number of bytes in DMT frame): 49 17
R (number of check bytes in RS code word): 0 0
S (RS code word size in DMT frame): 1 1
D (interleaver depth): 1 1
Delay (msec): 0 0

internet always disconnect/no respon, can't access router, need restart it

line problem or modem?

where should i see? the up streams or the down streams?

---

Added on September 12, 2010, 12:16 pmhow about mine?
Downstream Upstream
SNR Margin (dB): 6.8 15.2
Attenuation (dB): 56.0 28.5
Output Power (dBm): 10.9 18.9
Attainable Rate (Kbps): 2751 705
Rate (Kbps): 1907 511
K (number of bytes in DMT frame): 56 15
R (number of check bytes in RS code word): 0 0
S (RS code word size in DMT frame): 1 1
D (interleaver depth): 1 1
Delay (msec): 0 0

This post has been edited by krauser95: Sep 12 2010, 12:16 PM

DSL Status: Connected
DSL Modulation Mode: G.dmt
DSL Path Mode: Fast
Downstream Rate: 2048 kbps
Upstream Rate: 512 kbps
Downstream Margin: 25 db
Upstream Margin: 27 db
Downstream Line Attenuation: 33 db
Upstream Line Attenuation: 9 db
Downstream Transmit Power: 11 db
Upstream Transmit Power: 18 db


This is what i have. Any idea this data is good? Any sifus out there. Tks

I need some help here
All my readings are fine
I just realise my attenuation is sky high
Attennuation Down stream 124 Upstream 84.
Does tht means the socket have problem?
I tried remove to connect directly to the wall socket without a spliter and still show same readings.

Mode: ADSL_2plus
Traffic Type: ATM
Status: Up
Link Power State: L0

Downstream Upstream
Line Coding(Trellis): On On
SNR Margin (0.1 dB): 320 281
Attenuation (0.1 dB): 60 25
Output Power (0.1 dBm): 0 102
Attainable Rate (Kbps): 22664 1112

Path 0 Path 1
Downstream Upstream Downstream Upstream
Rate (Kbps): 2048 507 0 0

how is my connection? Is it good, or bad?
