QUOTE(keropi88 @ Mar 16 2019, 06:53 PM)
hi guys i need some help, i searched internet but i think i need the answers for my situation
my plan : UNIFI 100mbps
house : 3 storeys
PC location : 2nd floor
setup
Router at 1st floor : UNIFI D LINK Router (AC1200)
Extender at 2nd Floor : Tp Link RE450 (AC1750 )
After asking UNIFI technician to come, he replaced my Tp LINK C9 router with UNIFI's own DLINK AC 1200 router. I used my iPhone X to connect and it shows 100mbps speedtest , exactly the speed i subscribed
In the second floor my room , i just build a new PC. its a MSI gaming motherboard that comes with a build in wireless AC receive capable of 433mbps. (
Specification Page - Intel Wireless AC receiver model 9462 )
the problem is , my PC is connected to the TP LINK extender RE450 , i run speedtest i got like max 50mbps, average 35-40mbps speed
i sit in front of my PC, i use my phone connect to the same extender, i got close to 100 mbps speed, exactly the speed i subscirbed to
so whats the problem ? my build in receiver of motherboard capable of 433mbps but only gets 35mbps ...
initially the technician said the extender might have speed loss, but my phone connected to it no problem it still gives 90-100mbps
what do i need to do ?
thanks in advance
Layman explanation ahead. iPhone X Wireless is rater at 867Mbps while your MSI is rated at 433Mbps. The WiFi chipset on your MSI is pretty old as well.
Considering similar level of signal degradation, it explain why your iPhone X double the speed of your MSI motherboard.
Consider getting a new PCIE wireless adapter. Get the TP-Link Archer T4E, affordable and coming out soon.

QUOTE(cyclone2 @ Mar 17 2019, 12:16 PM)
finally pulling a CAT6A cable yesterday from upstair to downstair. Tested the network speed using iperf3 managed to get closed to 1Gbps speed....
But then using tm speedo meter and speedtest.net only can get 500-600mbps download....
Already made a report to TM.....
Iperf3 test result
[attachmentid=10204907]
TM speedtest
[attachmentid=10204908]
What router you use? Having Gigabit LAN throughput does not mean the chipset of the router is capable of Gigabit speed.
Try Extreme Broadband speedtest server, I find it to be the most consistent.
This post has been edited by blacktubi: Mar 17 2019, 03:35 PM
