ASUS T-Topology 2.0 is working fine here testing 2 vs 4 modules

2 modules -- 6m 17.871s


4 modules -- 6m 16.562s


Same as T-Topology 1.0 on Z77, 4 modules (populated DIMM) is faster than 2 modules, at the same memory settings and voltages.





This post has been edited by owikh84: Jun 13 2013, 10:53 PM

Asus overclocking software seems pretty good. Probably will save time & can help out those who never OC before. Most likely that is an ES chip since 4.8GHz is pretty high but nevertheless, the OC-ing software concept is pretty cool.

4x 4GB 2800MHz 11-14-14-25-1T is prime95- stable for 3 hours.

is this 1.65v set??
cause why is it running more than 1.65v. hmm funny i cant flash to shamino bios anymore. i tested it in the beginning and it sux and when back to 0503. and now wanted to go back but cannot.

This post has been edited by cstkl1: Jun 14 2013, 08:03 AM

may i know what type of cooler u using? 4.6 ghz with less 80 temp and 1.4 Vcore. cool

Check his review thread of m6e. Theres a pic aswell.

BIOS set is 1.66v, DMM reads 1.67v. Anything lower will result in error in HyperPi unless if the subtimings and command rate are loosen then only can reduce the vdimm etc.

It is a custom watercooling kit consisted of EK Supreme HF plate #6 CPU waterblock, 2x XSPC RX360 radiator, Swiftech MCP655 pump, EK FC7970 GPU waterblock, EK Multioption X2 Advanced reservoir, XSPC 1/2" ID 3/4" OD white tubing, 12x Scythe GT AP-15 1850rpm 120mm fan + Aerocool Shark 120mm fan, Coolaboratory Liquid Pro thermalpaste etc.

You have new 0017 BIOS out.

by ezflash or usb flashback?

ezflash on bios setup.
really odd it was working fine last time.

think it was bios 0013.

will try bios 0017

This post has been edited by cstkl1: Jun 14 2013, 04:58 PM

try USB Flashback if have any problem with EZ flash, rename BIOS filename to M6E.CAP
0017 just released last night

Ok. Same prob with ez flash. Reboot stuck at 62. Then on off stuck at 00 forever.

yeah curious about the vttdram bug. i didnt find any bug. so far running at 0.5xvdimm seems to be perfect.

Working with usb flasback.

Oh bios hmm before i had a way of reducing vccin for 2133 c7 to default 1.75v.
New bios back at the old vccin.

Hence my vote it sux for now

This post has been edited by cstkl1: Jun 14 2013, 05:57 PM

Btw coolice whats the safe range for vccin on 24/7.

4 X 4GB 2800 11-14-14-25-1T @ 1.63v (BIOS), 1.646v (AI)



HyperPi:


Prime95 27.9 w/ AVX:


This post has been edited by owikh84: Jun 15 2013, 09:31 AM

Another one......+Hero.

Btw,

Intel Removes ‘Overclocking’ From Non-K Series Haswell Parts.....

http://wccftech.com/intel-removes-overcloc...-haswell-parts/






This post has been edited by stasio: Jun 15 2013, 01:01 AM

I think there should a way to unlock it. Maybe squeezing a little extra out of the chips by increasing the Turbo Boost 'bins' - multipliers that apply only during certain CPU activity. The standard non-K CPUs will have Intel's latest TSX extensions and enterprise virtualization technologies enabled. .

This post has been edited by khaidir1976: Jun 15 2013, 01:21 AM

Bios 0017 awesome.
Mobo dead n stuck n code 78.
Was just priming 2250c7.
Before that already noticed my g19 was behaving oddly during bootup.
Second bios also cannot boot.

Clear cmos now with no power n waiting 20mins
Shld be ok after this. Odd same timings were ok on 0503.

This post has been edited by cstkl1: Jun 15 2013, 01:44 AM
