 Ivy Bridge Overclocking V1 | 3770K/3570K | Z77, Torture Your CPU, Post It Here!

views

ketapang
post Nov 6 2012, 01:40 AM

GG
******
Senior Member
1,115 posts

Joined: Nov 2006
From: .......


QUOTE(usop8290 @ Nov 5 2012, 11:24 PM)
My first try since using stock i5 3570k..sorry for big pix..  biggrin.gif

usop8290 | 3570k | 4400MHz | ASRock Z77e itx | Water

cannot boot @4.6 at 1.285V Vcore...maybe next time i'll try harder  tongue.gif
*
Bro your gflops is low. Already on service pack 1? 4.4 should get 120+ gflops.
ketapang
post Nov 6 2012, 05:39 PM

GG
******
Senior Member
1,115 posts

Joined: Nov 2006
From: .......


Stressing my ram @ 2400mhz 11-13-12-35 2T, i already loosen up the ram timing. So far 50min stable prime95 90%>ram. Should i stick @ 2200mhz 10-11-10-28 1T? hmm.gif
ketapang
post Nov 6 2012, 08:23 PM

GG
******
Senior Member
1,115 posts

Joined: Nov 2006
From: .......


QUOTE(owikh84 @ Nov 6 2012, 06:53 PM)
If the 2400C11 is stable, i'd choose whichever performs faster.
Run several benchmarks such as Pi, 3DMark etc to compare.
What's the vdimm for 2400C11?
*
I set it @ 1.65v. Here's 2400Mhz 10-12-12 2T, 1 hour stable. Will stress test longer tonight. biggrin.gif

user posted image

This post has been edited by ketapang: Nov 6 2012, 08:23 PM
ketapang
post Nov 7 2012, 12:13 PM

GG
******
Senior Member
1,115 posts

Joined: Nov 2006
From: .......


Going strong for 5 hours but ended up 1 error, 3 cores still going. Need to loose the timing again. sad.gif

user posted image
ketapang
post Nov 7 2012, 12:43 PM

GG
******
Senior Member
1,115 posts

Joined: Nov 2006
From: .......


QUOTE(owikh84 @ Nov 7 2012, 12:35 PM)
Good attempt bro. I believe you should get the error faster if min FFT is set to 128k.
*
How about max fft? I use 8k min & 1792k max. Usually I will get error around 10min if not stable. I read somewhere 1792k & 1344k is good for checking instability.

This post has been edited by ketapang: Nov 7 2012, 01:16 PM
ketapang
post Nov 7 2012, 04:42 PM

GG
******
Senior Member
1,115 posts

Joined: Nov 2006
From: .......


So far 3 hours stable with a bit loose timing, using your recommended setting. Will try for long run tonight. smile.gif

user posted image
ketapang
post Nov 9 2012, 12:21 AM

GG
******
Senior Member
1,115 posts

Joined: Nov 2006
From: .......


Successfully delid my 3570k. laugh.gif
http://valid.canardpc.com/show_oc.php?id=2574826

» Click to show Spoiler - click again to hide... «

ketapang
post Nov 9 2012, 08:43 AM

GG
******
Senior Member
1,115 posts

Joined: Nov 2006
From: .......


Okay, here's the result after delid smile.gif :
8 hours prime95, 90% ram, 4.5Ghz @ 1.3v.

user posted image

Before this, my temperature will hit 104-105c @ 4.5Ghz. So delid improve my temperature by 9-10c. Not to mention, im only using cheap TIM here, deepcool thermal compound rclxub.gif . I bet i will get 12-15c improvement if i use liquid ultra wink.gif . Now im perfectly stable with this speed flex.gif. Btw, it took me around 10min only to delid, seriously im really glad i do it right. laugh.gif


Added on November 9, 2012, 9:37 amUpdate:
It seems 4.5Ghz is the max oc i can get with my cooler. 4.6Ghz already hitting 104c (after 20min) & I need at least 1.4v to be stable without any WHEA error. rclxub.gif I really have a bad chip here. So 4.5 it is. flex.gif

This post has been edited by ketapang: Nov 9 2012, 09:37 AM
ketapang
post Nov 9 2012, 10:55 AM

GG
******
Senior Member
1,115 posts

Joined: Nov 2006
From: .......


QUOTE(owikh84 @ Nov 9 2012, 10:35 AM)
What a huge drop bro pretty sure you could shave off another 9-10C with liquid Ultra.
I will collect liquis Pro today & to be compared with Ultra this weekend, hopefully.
Salute to your bravery on delidding. Congrats!
*
Thx bro.smile.gif Idk what happen to me yesterday. I was finding stability for my ram and when i saw the temp, i was like "ok delid time" laugh.gif. 100Mhz might not be big improvement but it really worth it. Seriously why Intel use those really2 cheap TIM. When i touch those stock tim, its already hardened and there's only little contact between the IHS and the die. No wonder the temp is really high rclxub.gif.
ketapang
post Nov 9 2012, 04:51 PM

GG
******
Senior Member
1,115 posts

Joined: Nov 2006
From: .......


QUOTE(captvizcenzo @ Nov 9 2012, 04:27 PM)

I've hit my limit. Can't get close to 1.4V vcore, temps will be too high.
Now stressing 4.7GHz @ 1.34V. If this won't last for 18+ hours, that means I need to be happy at 4.6GHz.
Temps spiked to 100C at small FFTs. sad.gif

Might delid in near future tongue.gif
*
I think you can hit 4.7-4.8 with delid + liquid ultra. brows.gif Even wit cheap tim i manage to decrease the temp by 9c. thumbup.gif
ketapang
post Nov 9 2012, 07:47 PM

GG
******
Senior Member
1,115 posts

Joined: Nov 2006
From: .......


QUOTE(lat_lonelyboyz @ Nov 9 2012, 07:05 PM)
Liquid Ultra is the best thermal compound available in market?
*
Not exactly but for ihs to die tim, yes its the best out there because its almost identical to fluxless solder. Metal>TIM in heat transfer. smile.gif


Added on November 9, 2012, 7:49 pm
QUOTE(owikh84 @ Nov 9 2012, 07:42 PM)
Liquid Pro is the best TIM & 2x better than Ultra.
*
Not to mention hard to remove. laugh.gif Anyway bro you already order liquid pro? how many months it takes to ship to malaysia? any local dealer you know selling liquid pro?

This post has been edited by ketapang: Nov 9 2012, 07:49 PM
ketapang
post Nov 9 2012, 11:08 PM

GG
******
Senior Member
1,115 posts

Joined: Nov 2006
From: .......


QUOTE(owikh84 @ Nov 9 2012, 09:19 PM)
I ordered Liquid Pro from their website on 21/10
The parcel actually reached Msia shore few days ago while I was not at home.
So roughly took 2 weeks to arrive.
*
How about the price & payment method? Might interested in getting one. smile.gif
ketapang
post Nov 10 2012, 06:48 PM

GG
******
Senior Member
1,115 posts

Joined: Nov 2006
From: .......


QUOTE(owikh84 @ Nov 10 2012, 05:24 PM)
Hands itchy and bought this ASRock OC Formula from lingloong (RM855), with the touch of nickshih

user posted image

Liquid Pro also arrived...
» Click to show Spoiler - click again to hide... «

*
drool.gif Looking forward for that liquid pro bro. rclxms.gif

This post has been edited by ketapang: Nov 10 2012, 06:49 PM
ketapang
post Nov 11 2012, 09:33 PM

GG
******
Senior Member
1,115 posts

Joined: Nov 2006
From: .......


Guys what do you think the right price for delidded processor?
ketapang
post Nov 11 2012, 10:01 PM

GG
******
Senior Member
1,115 posts

Joined: Nov 2006
From: .......


QUOTE(lat_lonelyboyz @ Nov 11 2012, 09:41 PM)
I can smell 3770K in da house brows.gif
*
3770k too pricey for me bro. laugh.gif Not really satisfied with my current proc, 1.4v for 4.6ghz. rclxub.gif Might go for another one later. biggrin.gif
ketapang
post Nov 12 2012, 02:37 AM

GG
******
Senior Member
1,115 posts

Joined: Nov 2006
From: .......


QUOTE(lat_lonelyboyz @ Nov 11 2012, 10:12 PM)
Means u gonna hunt for a good chip of 3570K?
*
Need to see 1st if my budget allows. tongue.gif
ketapang
post Nov 13 2012, 07:37 AM

GG
******
Senior Member
1,115 posts

Joined: Nov 2006
From: .......


Finally found the lowest voltage for 4.6Ghz, stable for 10 hours. smile.gif
user posted image
ketapang
post Nov 13 2012, 09:17 AM

GG
******
Senior Member
1,115 posts

Joined: Nov 2006
From: .......


QUOTE(owikh84 @ Nov 13 2012, 09:05 AM)
well done mate. Looks to be a sweet spot for 24/7.
*
Thx bro. Liquid pro still not tested yet? brows.gif looking 4ward for it.

QUOTE(arerife @ Nov 13 2012, 09:09 AM)
ketapang temperature at load was very awesome with that vcore.
Should i delidded my proc. Haihhh.
*
Up to you bro. nod.gif
Btw this is still using cheap deepcool tim, wait until i replace it with liquid pro. possible 10c lower than this one. brows.gif
With this voltage i should be getting around 4.8-4.9 but my proc is so......shakehead.gif
ketapang
post Nov 13 2012, 07:41 PM

GG
******
Senior Member
1,115 posts

Joined: Nov 2006
From: .......


QUOTE(arerife @ Nov 13 2012, 09:24 AM)
i really want to delidded but haihhh. susah mau bicara tongue.gif
perghhh, tahniah2 rclxms.gif
power gila oc hang even air colling!

please don't mad to your cpu, nnt dia buat hal baru tau.
*
Proc ak ni manja sgt, nk "susu" lebih. laugh.gif Klu xnak delid, go hunt that golden chip! tongue.gif


Added on November 13, 2012, 7:59 pm
QUOTE(lat_lonelyboyz @ Nov 12 2012, 07:03 AM)
Bro, ur sammy green run at 2200 @ C9 or C10? Can give me detail of its timing and vdimm as well?

1.35v or 1.5v or 1.65v?
*
Mine 2200 @ CL11 1.5v, lazy to tweak tongue.gif. I could run 10-11-10-28 with 1.575v. smile.gif

This post has been edited by ketapang: Nov 13 2012, 07:59 PM
ketapang
post Nov 13 2012, 08:29 PM

GG
******
Senior Member
1,115 posts

Joined: Nov 2006
From: .......


QUOTE(lat_lonelyboyz @ Nov 13 2012, 08:18 PM)
What's tighest timing to make sure its will run stable at 2200 or 2400?
*
The tightest timing i could get is 10-10-10-25 2200Mhz with 1.65v. I could boot 2400 CL11 but really hard to make it stable, even after loose some timing only stable around 1 hour then crash. So i ended up @ 2200Mhz, so far no problem at all. nod.gif

This post has been edited by ketapang: Nov 13 2012, 08:29 PM
