 Ivy Bridge Overclocking V1 | 3770K/3570K | Z77, Torture Your CPU, Post It Here!

views

TSowikh84
post Apr 9 2013, 02:31 PM

i7 Clan
Group Icon
Elite
8,711 posts

Joined: Nov 2007
From: Butterworth, PG / Machang, Kelantan



QUOTE(codenamew @ Apr 9 2013, 01:31 PM)
kevin, will setting LLC to Turbo affect the cpu life span?
*
I don't think so.
Ivy Bridge will not degrade at all, unlike Sandy Bridge & SB-E that degrade so fast.
I have been using Very High/Turbo LLC since one year ago.
Tortured up to 100C, my chip is still performing as perfect as brand new.
Ivy Bridge is as fast as lightning, as strong as a steel. biggrin.gif
TSowikh84
post Apr 10 2013, 12:24 AM

i7 Clan
Group Icon
Elite
8,711 posts

Joined: Nov 2007
From: Butterworth, PG / Machang, Kelantan



QUOTE(ocz @ Apr 9 2013, 11:23 PM)
Hi guys, this would be my very2 1st OC try since the E2140 era. Forget all those OC thingy.
Please do correct me if im doing wrong.  laugh.gif

[attachmentid=3385263]

Motherboard : Gigabyte GA Z77M-D3H
Processor : i7 3770K
Ram : Corsair Vengeance 8GB DDR3 1333.
PSU : OCZ 850watt
*
Is that a stable OC? What's your max temp and what cooler are you using?
TSowikh84
post Apr 10 2013, 06:43 AM

i7 Clan
Group Icon
Elite
8,711 posts

Joined: Nov 2007
From: Butterworth, PG / Machang, Kelantan



QUOTE(wongtheboy92 @ Apr 10 2013, 12:34 AM)
Bro owikh84, is this okay? 4.7GHZ with air
Perfect! Nice chip you got there rclxms.gif

QUOTE(ocz @ Apr 10 2013, 03:05 AM)
havent test any stability or stress test yet. still getting the knowledge of overclocking, im currently on stock cooler. waiting for wc.
Stock cooler can't go higher. Put it under water is your best choice. But nothing can beat a delidded chip, which will offer 15-20C improvement. biggrin.gif
TSowikh84
post Apr 10 2013, 10:10 AM

i7 Clan
Group Icon
Elite
8,711 posts

Joined: Nov 2007
From: Butterworth, PG / Machang, Kelantan



QUOTE(wongtheboy92 @ Apr 10 2013, 09:22 AM)
Thanks bro, i manually set it to 1.28V instead of 1.27V for vcore and 1.28V yields me stable gflops and tremendous reduction in the intel burn test duration. I'm completely satisfied with my chip. biggrin.gif
*

A happy Ivy Bridge owner spotted. biggrin.gif
Now it's time to play with mem OC. laugh.gif
TSowikh84
post Apr 10 2013, 10:07 PM

i7 Clan
Group Icon
Elite
8,711 posts

Joined: Nov 2007
From: Butterworth, PG / Machang, Kelantan



Got this PSC kit today... G.Skill Flare 2000C7

user posted image

stock 2000 7-9-7
user posted image

quick test on 2400 7-11-7

user posted image


TSowikh84
post Apr 11 2013, 02:45 PM

i7 Clan
Group Icon
Elite
8,711 posts

Joined: Nov 2007
From: Butterworth, PG / Machang, Kelantan



QUOTE(wongtheboy92 @ Apr 11 2013, 02:33 PM)
DDR3 2200MHZ @10-11-10-27
Good job bro.
What vdimm, VCCSA, VCCIO?
TSowikh84
post Apr 11 2013, 05:45 PM

i7 Clan
Group Icon
Elite
8,711 posts

Joined: Nov 2007
From: Butterworth, PG / Machang, Kelantan



QUOTE(codenamew @ Apr 11 2013, 05:02 PM)
mine is still working but then again,the first 2 memory slots are not working. i can even oc my gc n stable but one thing is that no matter how many times i apply TIM on my chip,the temp is still that high and worse than before delidd. Have tried many methods of TIM application from line method to dot method but still same. Using mx4. perhaps someone can tell me what mistake that i made. Sometimes, one core is 15C hotter than the other core.
*
I suspect there is a bad contact between your IHS or die with your waterblock/ heatsink base.
TSowikh84
post Apr 11 2013, 10:54 PM

i7 Clan
Group Icon
Elite
8,711 posts

Joined: Nov 2007
From: Butterworth, PG / Machang, Kelantan



QUOTE(codenamew @ Apr 11 2013, 05:53 PM)
im thinking the same thing too. no matter how thin is the TIM btw the IHS-DIE with dot method/line method, the temperature is still not even. kevin, do u have any idea on how to check the surface contact btw my nochua nd d14 with the IHS?
*

No idea with D14.

QUOTE(wongtheboy92 @ Apr 11 2013, 08:58 PM)
Hope it does have what you want, bro. This is my max memory oc, cause can't boot @ 2400MHZ ><

Samsung should be able to take any voltage. I would bump it up to 1.65v etc it won't die without heatspreader.
TSowikh84
post Apr 11 2013, 11:33 PM

i7 Clan
Group Icon
Elite
8,711 posts

Joined: Nov 2007
From: Butterworth, PG / Machang, Kelantan



QUOTE(wongtheboy92 @ Apr 11 2013, 11:14 PM)
no luck i even tested with 1.68Vdimm ... keep failed to boot...until one time, i lagging in the uefi bios...luckily manage to restore to default and restart to do my cpu oc then do again the ram oc... Sigh sad.gif

and thats my best shot...msi boards aint tat good as asus maximus v boards in ram overclocking as I reckon...there are may ram issues with this board.
*
Yes it could be board issue or RAM chip itself has hit max capability.
I must agree with that statement, Asus & ASRock have been awesome at mem OCing whilst MSI is not doing good due to rubbish BIOS (sorry sweat.gif )
TSowikh84
post Apr 13 2013, 11:58 AM

i7 Clan
Group Icon
Elite
8,711 posts

Joined: Nov 2007
From: Butterworth, PG / Machang, Kelantan



QUOTE(hypermax @ Apr 13 2013, 11:32 AM)
Just got a 3770k Costa Rica. To my surprise, temp when running Linx at 4.4ghz @ 1.24v actually shot up to 90c. My proc is cooled by h100 with 4 gentle typhoon push pull configuration with arctic mx4 tim. Looks like h100 performs worse than some of the high end air cooler.
*

No matter how good is your cooler, even a quad TEC, you wont be able to tame the Ivy Bridge because there is still a culprit underneath the IHS, until the IHS is delidded, black adhesive glue is removed and TIM is reapplied. Then only you will see the improvement. So guys, dont waste your money for expensive cooling gear, if you dont plan to delid your chip.
TSowikh84
post Apr 13 2013, 03:23 PM

i7 Clan
Group Icon
Elite
8,711 posts

Joined: Nov 2007
From: Butterworth, PG / Machang, Kelantan



QUOTE(hypermax @ Apr 13 2013, 12:17 PM)
Thank you for your advice. But i have seen some posts in this thread people using air cooler like noctua D14 and CM air cooler actually have better temp than mine.

Could it be H100 pump failure?

No idea bro what's happening but H100 is supposed to perform as good as the D14. You should check your radiator mounting so that your pull fans are intaking cool air.
For the cost of H100 + 4x GT, I think better get a RASA RX240 kit or even the RS360, beat those out of craps lol. More interestingly, RASA kit is upgradable.

This post has been edited by owikh84: Apr 13 2013, 03:27 PM
TSowikh84
post Apr 13 2013, 03:41 PM

i7 Clan
Group Icon
Elite
8,711 posts

Joined: Nov 2007
From: Butterworth, PG / Machang, Kelantan



It's been quite a while I don't run stress test. So recently I had some time to play with these TridentX kits.

user posted image

G.Skill TridentX 2666 10-12-12-25-1T @ 1.65v (Samsung IC)
user posted image

I have never seen anybody LinX @ DRAM 2800MHz successfully yet, so here is it now biggrin.gif

G.Skill TridentX 2800 11-14-14-25-1T @ 1.66v (Hynix CFR IC)
user posted image

Running 11-13-13-25-1T now... Don't know whether my stuffs can make it or not. Stay tuned...

This post has been edited by owikh84: Apr 13 2013, 05:25 PM
TSowikh84
post Apr 14 2013, 01:45 AM

i7 Clan
Group Icon
Elite
8,711 posts

Joined: Nov 2007
From: Butterworth, PG / Machang, Kelantan



QUOTE(codenamew @ Apr 14 2013, 01:20 AM)
Just got my 3570k water cooled but when running at 1.34 vcore during prime, my highest temp is as follows
Core 0 80c
Core 1 88c
Core 2 83c
Core 3 79c

Is the temp normal? When I do Linx, the temp can shoot up till 105 for core 1 and core 2.

I'm using xspc raystorm ex240 d5 kit.

Pls advise.
*
Pls show us some screenshots. How did you run the prime95 and for how long? Using custom blend with at least 90% RAM stressed?
What version of prime95? Older versions than 27.7 don't have AVX instruction to max stress.
Supposedly prime95 is slightly lower temps than LinX after a few hours whilst LinX can shoot up drastically within seconds.

my 3570K (undelidded) @ 4.6GHz with 1.376v cooled by two 360 rads in none airconded room with ambient as hot as 35C.

user posted image

So i think to hit 105C with your 240 rad is quite normal. That's why I said earlier.

QUOTE
No matter how good is your cooler, even a quad TEC, you wont be able to tame the Ivy Bridge because there is still a culprit underneath the IHS, until the IHS is delidded, black adhesive glue is removed and TIM is reapplied. Then only you will see the improvement. So guys, dont waste your money for expensive cooling gear, if you dont plan to delid your chip.



TSowikh84
post Apr 14 2013, 08:16 AM

i7 Clan
Group Icon
Elite
8,711 posts

Joined: Nov 2007
From: Butterworth, PG / Machang, Kelantan



QUOTE(codenamew @ Apr 14 2013, 01:51 AM)
Ahh, luckily u shows me this sc. I perform the test as per the instructions on the 1st page of this thread. Guess its normal. Thanks Kevin. Thought I did sth wrong with the wb placement.
*
It's ok. There is nothing wrong with the wb mounting.

I got one extra delidded 3770K 5.0 1.42v LinX stable IMC 2776 max to let go for RM2k. Those who got money please PM me.
TSowikh84
post Apr 14 2013, 11:53 PM

i7 Clan
Group Icon
Elite
8,711 posts

Joined: Nov 2007
From: Butterworth, PG / Machang, Kelantan



QUOTE(taxidoor @ Apr 14 2013, 07:00 PM)
Ibt 4.5ghz with 3770k gflops around 102 normal?
I saw i5 run faster
*
Actually 3770K should yield 110+ GFlops, 3570K 125+
TSowikh84
post Apr 15 2013, 06:54 AM

i7 Clan
Group Icon
Elite
8,711 posts

Joined: Nov 2007
From: Butterworth, PG / Machang, Kelantan



QUOTE(Dreamworks @ Apr 15 2013, 12:10 AM)
Upgraded my cooler from CM Hyper 212 EVO to NZXT Kraken X60, finally can do 4.9GHz but temps still shoot up to 104'C ... 5GHz throttled laugh.gif Forgot to buy new thermal paste and IPA 99%, so just cincai wipe off old Arctic Silver 5 from IHS with tissue paper and use pre-applied stock compound by NZXT ph34r.gif
*

Not bad at all. X60 performs really good like any reviews recommended. List updated.

QUOTE(wongtheboy92 @ Apr 15 2013, 01:21 AM)
I would say 120+ for 3570k...for my experience...it varies with memory used...and how fast ur RAM tweaked
*

Yupe, sometimes GFlops could be fluctuating depending on voltages ie vCore, vdimm, VCCIO, VCCSA, RAM timings, as well as RAM amount selected.


QUOTE(raydenex @ Apr 15 2013, 02:08 AM)
These are my idle temps; Comments and suggestions are very welcomed.. please teach me thanks smile.gif
*
Welcome to the club. Your temps look fine. Try start OC to 4.0 with stock voltages then slowly go up further.
TSowikh84
post Apr 15 2013, 02:42 PM

i7 Clan
Group Icon
Elite
8,711 posts

Joined: Nov 2007
From: Butterworth, PG / Machang, Kelantan



QUOTE(hypermax @ Apr 15 2013, 01:56 PM)
Funny things that I observed. My system passed Linx 25 runs and aida64 stress test > 12hrs, but failed prime95 large fft within 15mins. So it's my overclocking stable? I am now trying for 4.5ghz.
*

Nothing new for me, it's been discussed earlier that from my own experience prime95 requires more juice than LinX. You might wanna have a look at post #4 of this thread.

QUOTE(owikh84 @ Apr 20 2012, 12:34 AM)
3770K @ 5.0GHz

LinX for 1 hour @ 1.416v... passed
» Click to show Spoiler - click again to hide... «


LinX for 7 hours @ 1.448v... 1.416v-1.434v BSOD
» Click to show Spoiler - click again to hide... «


straight away run Prime95 at 1.448v... failed in 1 hour +
» Click to show Spoiler - click again to hide... «


bump up to 1.48v... passed 4 hours + prime95
» Click to show Spoiler - click again to hide... «


Another thing I saw your GFlops is not 110+, which is not really showing a correct figure for 3770K. Most probably a slight bump on voltage is needed to get higher GFlops. Good luck

This post has been edited by owikh84: Apr 15 2013, 02:49 PM
TSowikh84
post Apr 15 2013, 04:09 PM

i7 Clan
Group Icon
Elite
8,711 posts

Joined: Nov 2007
From: Butterworth, PG / Machang, Kelantan



QUOTE(hypermax @ Apr 15 2013, 03:51 PM)
Means I got a dud chip then. Needs such high voltage for a mere 4.4ghz overclock.

BTw, When I first overclocked my chip to 4.4ghz,  I set my voltage to auto. Then it turned up that the stupid mobo put 1.47v to the vcore. The pc managed to boot into windows then shut down by itself. Just wanna ask Could the initial high voltage damage the chip and made it requires more vcore when overclocking?

Sorry for the noob question. Still new to the overclocking world.
*
I have been using 5.0GHz @ 1.48v for 24/7, haven't seen any degradation since the first day.
Ivy Bridge is a lot more durable than Sandy Bridge in which the latter is a hell of degrading craps.
In conclusion, IB will not degrade at all, until you put an extremely high voltage on it say 1.9-2.0v.
TSowikh84
post Apr 15 2013, 07:34 PM

i7 Clan
Group Icon
Elite
8,711 posts

Joined: Nov 2007
From: Butterworth, PG / Machang, Kelantan



QUOTE(codenamew @ Apr 15 2013, 06:23 PM)
Batch 3231b is a golden chip batch?
*

Batch is meaningless, total crap shoot. It's all about draw of luck.

TSowikh84
post Apr 15 2013, 08:38 PM

i7 Clan
Group Icon
Elite
8,711 posts

Joined: Nov 2007
From: Butterworth, PG / Machang, Kelantan



QUOTE(hypermax @ Apr 15 2013, 08:17 PM)
Thanks for the info.  notworthy.gif

Btw, how reliable is aida64? Asus opines that it is THE ONLY software which understands ivy bridge, thus passing aida64 stress test > 12hrs indicates stability. This is quite different from what I have learned previously. I always thought stability is only achieved by passing prime blend test 24hrs.

Btw, I bumped my voltage to 1.3 from 1.288. The GFlops in Linx is still the same sweat.gif is my proc something wrong?
*
Voltages could be vCore, vdimm, VCCSA, VCCIO, vPLL.

Seems like AIDA64 Stress Test uses its own engine so just noticed that they have updated their version to support AVX instruction.
I will try it later when I have free time. A quick note from me is:

The higher the core temps and heat generated, the more stressful the test.
The lower the vCore under load (vdroop), the more stressful the test.

This post has been edited by owikh84: Apr 15 2013, 09:07 PM
