QUOTE(shinkawa @ Oct 19 2017, 09:13 PM)
interested with your DIY. can share pictures and teach us?
I also planning to soundproof abit to enjoy my music
Sure, I can share pictures of the spare tyre boot area this weekend, other areas probably when i re-open again to do some improvements.
Not easy to do and if 1st time, do expect some broken or scratched clips especially those holding the boot area carpet.
The rear doors are pretty easy. The 'phone cup' area, just insert four fingers (except thumb) into the 'cup' and squeeze with your palm very tightly, then try to yank it out. Sometimes the clips get caught and you need to use force, whatever it is do not do too much front-back or left-right motion, only up down, otherwise you will break or bend the clips. After you get that out, two screws to remove + one more at the door opener handle. Remove the power window connector. Then just pry out the door panel from it's clips from the sides.
The front doors, you will need to remove the 'triangle thing' near the side mirror, just yank it out, again, it must be vertical 90 degree from it's mount point. The rest is the same. After you remove the cabin door panels, remove the plastic covering the inner door and you have access to the door skin. Beware of the black 'AC glue' when removing the plastic cover, it can become messy. Then, You need to cut the soundproof material smartly and apply it. Clean the door skin with some cleaner and dry it with lint-free cloth, wait awhile to make sure really really dry. When you apply the soundproof, try to be in hot weather and use a 'roller' to apply force on the material. I used my fiance's nail polish remover bottle, with force make sure you press and 'roll' thru every inch of the material. It must stick. I took 4 weekends with the door. 2 weekend to apply 2 pair of door (4 hours per weekend, 1 pair 1 weekend). Then remaining 2 weekend open again and use your 'roller' to press and make sure it sticks well. Maybe dont need to do this because on mine it stuck really well, but i did it for piece of mind. I used a combination of nakamichi q-pad (expensive but heavy and thick) and some green generic brand. Do it slowly and take rests, grab a beer, play a short game, chill... dont rush, it's not worth the lousy results. For the plastic door panel, you can apply a layer of insuflex or other closed cell foam before attaching it back to the door panel.
Boot, there is alot of clips, you need fingernails or a credit card/thin plastic ruler for the 'mushroom button clips'. The 'handle clips' are very hard to come out, you will need to figure this out with a flat screwdriver or some really hard thin yet long plastic 'screwdriver alike' thing. Insert into both 'handle', yank it out vertically to the mount point with extreme force really quick. This is where i got injured and literally blood sweat and tears

Boot area 2 weekend. 1 weekend to apply, 1 weekend to re-press. Use CLD tile soundproof method but add abit more (google), dont need to overdo the boot. 'Knock' on parts of the boot and boot side body, find the most hollow sounding (tonnng tonnggg/dok dok sound) and apply it at that part. Don't use big cuts, use it in tiles but generously. If you knock and hear 'dip dip', that area is very strong already, it wont vibrate, no vibration=no sound=no need apply. You will know when you do it

You need to remove the spare tyre, also need to 'climb' and 'sit' in the spare tyre area to reach some areas. Reason to not over-apply or cover the whole boot, you may create a new 'big panel' just with a different vibration frequency. If this frequency matches the exhaust/engine/road, it will amplify and make a loud bassy boomy note at that frequency.
» Click to show Spoiler - click again to hide... «
Below the rear seat, youtube some tutorials, hard to explain with words...
I have not done anything in front of the rear seats. And this is really good enough already. On smooth road,pretty silent, on rough road, the thin front floor, side panels and firewall still make low frequency rumble. But overall much much better ride quality, if you have friend with bezza, do an A/B test and you will just smile...

And after doing it, you know why you are paying so much for a pro to do it, the immense time needed, carefulness, brain and strength just doesn't justify business cost of doing it cheap

I was foreman for a short while when younger, so i have some experience. Do at your own risk. Also, wind-noise rubber seal on all door, b-pillar and boot is a must.
