Selling
*******
WIMAX ANTENNA for P1, YES, Redtone WIMAX modem


****************************************
Benefits of using external WiMAX antenna
****************************************
Boosting P1, Yes, Redtone Wimax signal reception level,
Stabilising Wimax connection,
Improving data transfer speed,
Enchancing Wimax surfing experience!


*************
Product List:
*************
1) Metteor-Link Wimax Panel Directional antenna 14dbi (upgraded version 2.0 - 2015 stock)
2) tba
3) tba
4) tba

This post has been edited by coolstore: Apr 23 2017, 10:35 AM

Product 1:

***************************************************
Metteor-Link WIMAX directional panel antenna TRUE High Gain 14dbi
***************************************************
Boosting 14dbi high gain for Malaysia WIMAX frequency 2.3GHz!
Support P1, YES and Redtone wimax modem device!
Replacing modem internal antenna to achieve better results!
Premium Grade antenna quality.
Can put indoor or outdoor. (Let this external antenna face outside harsh weather conditions from now on, not the modem, protect the modem!)






=======================================
Wimax modem to work with Metteor-Link wimax antenna:
=======================================
P1 modem DV-230, DX-230
YES modem Zoom
Redtone modem





How setup?
Attaching external antenna into modem via a converter cable, plug and play, no soldering job needed.

After successfully attaching external wimax directional antenna, point the panel antenna towards / closer to the direction of wimax base station location and it will yields better result. (see sample of wimax base station on building roof in picture)

Tips:
(1) no need knowing exact where base station is, just adjust your panel up right <> up left, changing direction will see fluctuating signal result, when seeing better signal level from a direction, then the base station is located at that way.
(2) WiMAX modem are using 2 antenna system for running MIMO mode (multi-in multi-out at same time) for doubling data speed, not 1 antenna old technology.



=====
Note:
=====
1) Panel antenna is a kind of 'Directional antenna', which means it works in 1 straight line to receive & transmit signal data (much like the way how a torch light illuminate).
Thus directional antenna capable of achiving long range connection.

2) This specific Metteor-Link panel antenna support dual frequency band WIMAX 2.3GHz and WIFI 2.4GHz. So can apply on both WIMAX & WIFI. While other dedicated WIFI panel antenna works only on 2.4GHz so only for wifi usage! Don't get wrong one!



======================
Why pick Metteor-Link antenna?
======================
Premium grade antenna made by tier 1 antenna pro factory. Not made by 2nd or 3rd class small factory in china.
Most local dealers sourcing overseas antenna stock by online purchasing without really been to the exact factory to survey:
a) quality of factory: small factory or large factory?
b) do they really have wireless engineers? how many workers there?
c) do they really equipped with advanced antenna making and testing pro machinery?
d) what are their standard Quality Control process?
d) do they ever manage to get western countries orders which require stringent antenna quality?



================
Antenna Specifications:
================
Updates: From March 2015 onwards, new stock Metteor-Link panel antenna 2.3-2.5GHz is shipped in upgraded Version 2!



The difference between Version 1 and Version 2 is in V.S.W.R. value.
Version 1 is ≤.15, Version 2 is ≤1.4.

#The VSWR is always a real and positive number for antennas. The smaller the VSWR is, the better the antenna is matched to the transmission line and the more power is delivered to the antenna.#

Brand: Metteor-Link
Model No.: ML-DP-14 (this model support both wimax & wifi) V2
Gain: 14dbi (distance - how long)
Horizontal beamwidth: 30 degree (coverage area - how wide)
Vertical beamwidth: 30 degree (coverage area - how wide)
V.S.W.R.= ≤ 1.4
Size: ~ 20cm x 19cm
Weight: ~ 800g
Accessories: steel mounting clip provided
Cable: RG58 1 meter (minimising signal loss - longer cable more signal loss)



========
Reviews
========
### Testing of external antenna on WiMAX modem. ###
This reviews will be covering:
i) is it really more effective & helpful by using external antenna?
ii) performance testing among different type/manufacturer's antenna product.


This reviews starts with:

Testing (1) - Modem alone (with internal antenna)
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
Conditions:
Wheather: sunny, no rain.
Location: indoor, in a room.
Tips for U: this is not ideal position for wimax modem, just for testing illustration purpose. WiMAX Malaysia is using 2.3GHz frequency band (2375000 showned in picture), you need 2.3GHz antenna for it, not WiFi 2.4GHz antenna.



Results of Testing (1):
Signal Level: RSSI: -85dBm
Bar chart: Weak
Tips for U: RSSI number is signal level, it is accurate signal level measurement against bar chart indicator. RSSI with lower number means higher signal level, RSSI with higher number means lower signal level. User should always refers to this information when available.

Conclusion of Testing (1):
Weak signal reception level at this spot with modem alone.


Testing (2) (Part A) - Modem with fancy design non-tradisional external directional antenna
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
Antenna tested: brand W directional panel antenna - self-claimed MIMO antenna (2 antenna inside & 2 cable output) + High Gain 35dbi AT all frequency band from 700MHz to 2700MHz.
Antenna is positioned in a slope way as seen in picture, as that is the best direction I tested to get outdoor signal.
Tips for U: Why pick this antenna for testing? Because this is the TOP MODEL among those china fancy design non-tradisional antenna flooded into market that self-claiming superb high gain XXdbi AT all frequency band... If this not doing well, no need test others.



Results of Testing (2) (Part A):
Signal Level: RSSI: -90dBm
Bar chart: Weak

Conclusion of Testing (2) (Part A):
Signal reception level is weaker than modem original internal antenna. RSSI -90dBm is weaker signal than RSSI -85dBm.
By viewing their inner antenna component, P1 modem's internal antenna is no doubt of better quality than this so-called 35dbi high gain MIMO antenna. (open up casing and see, you would know).
Tips for U: if you heard some one said after applying external antenna and getting no result or poorer, albeit from user wrong setup, he might already bought himself an inferior quality antenna.


Testing (2) (Part B) - Modem with tradisional panel directional antenna Metteor-Link
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
Antenna tested: Metteor-Link panel directional antenna 14dbi
Antenna is positioned in similar slope way as seen in picture.
Tips for U: 2 antenna is applied because 1 antenna with 1 cable output, 2 antenna needed to run in MIMO mode.



Results of Testing (2) (Part B):
Signal Level: RSSI: -79dBm
Bar chart: Strong
TX power: 14dBm

Conclusion of Testing (2) (Part B):
Now you can see true capability of tradisional panel antenna, it works far better than those good looking toy antenna in market.
Tips for U: When signal reception turns good, you can also see the modem TX power (wireless transimission power) saving energy from previous 23dBm (100mW) to now mere 14dBm (25mW). Lower TX power means modem no longer need to load high wireless radiation power to connect to remote base station. Hense lower TX power is better for user safety and use less electric power. Thats similar to what professionals always advise people don't turn on 3G or 4G of smartphone at indoor when signal is very poor because the phone will load high TX power in order to connect to 3G/4G network.


Testing (3) - Modem with tradisional parabolic directional antenna
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
Antenna tested: tradisional parabolic directional antenna 2.3GHz-2.7GHz gain 25dbi made by KBT antenna manufacturer
Now I even go further to bring test on this giant size parabolic antenna.
Antenna is positioned in closest similar slope way as seen in picture. Since it too big (like a 40 inch LED TV), quite hassle to fine tune it.
Tips for U: parabolic and dish antenna are reckoned as highest gain antenna, but also got limitations. 1 antenna is connected here because no space to put on 2nd parabolic.



Results of Testing (3):
Signal Level: RSSI: -78dBm
Bar chart: Strong

Conclusion of Testing (3):
It perform slightly better than panel Metteor-Link at that testing spot, due to limitations of:
i) size does matter - they are bulky and heavy
ii) narrow direction angle - 10 degree or less, which means u need to tune into precise direction then only get optimum result.
iii) therefore it need professional mounting at outdoor with ample space in order to do direction adjustment.
iv) costly
v) eye-catching stuff
If above limitations are not your concern, then parabolic antenna is a good choice. Else it is more wiser using tradisional panel directional antenna which is more convenient, cost saving and space saving for end user.


SUMMARY OF THIS REVIEWS:
~~~~~~~~~~~~~~~~~~~
1. If you want performance antenna, stick with TRADISIONAL panel, yagi, parabolic or dish antenna, PROVEN RESULT! They are no good looking, but serious antenna! Don't waste money on others.
2. Basics knowledge for end user to identiy fake antenna product:
a) Antenna gain (dbi) is commensurate with SIZE OF ANTENNA COMPONENT. Bigger/longer size = higher dbi, smaller/shorter size = lower dbi. (It is physics)
(# that aluminium parabolic with giant 40inch TV size ~ 100cm x 60cm only can achieve 25dbi, how can a toy size antenna 15cm x 15cm claim itself 35dbi, it is shameful and with obvious intention of cheating end user)
b) Antenna gain (dbi) is also commensurate with COVERAGE ANGLE (HOW MANY DEGREE) of antenna. Wide angle = lower dbi, Narrow angle = higher dbi. (same theory of torch light)
c) Focus-band/Dedicated antenna (for a certain frequency band only) can achieve high dbi. Wide band antenna (supporting from xxxMHz until xxxxMHz) are not able to make it high dbi.

These tips help you stay away from china made fake antenna in market.





============
Common Q&A:
============

Q1: Why cannot use TV or wifi antenna for wimax?
A1: Because they are running at different radio frequancy. TV below 1000MHz, WIFI is using 2400MHz, WIMAX here is using 2300MHz. So must use correct frequency antenna. Just like if u want listen to radio Mix FM in klang valley, u must tune to correct frequency 94.5MHz FM.


Q2: I want longer cable, can?
A2: Wireless users must first understand cables basics before extending:

i) Cables ('coaxial cable') DOES NOT ADD VALUE to the wireless performance, but CAUSING SIGNAL LOSS ('signal attenuation'), i.e. it makes dbi loss.
ii) Longer cable causes more signal loss, shorter cable causes less signal loss, no cable no loss.
iii) Different grade of cable (thin/thick cable?) will cause different signal loss level (how many dbi loss per meter?) at different frequency (at low or high MHz?).
(these technical data that can be found at cable manufacturer technical data sheet)
iv) If total signal loss caused by cables is over 3db, the wireless transmission (TX) power of modem/wireless device will drop half which return an obvious poor performance.

more details:
thin/thick cable?
thin cable = more signal loss; thick cable = less signal loss.
RG174/178/316 are thin cables; RG58, LMR200 thicker; LMR400, RG8 are thickest.
so a 1 meter of RG174 will cause higher signal loss than RG58/LMR200, LMR400/RG8 will be least loss, regardless at what MHz frequency.

how many dbi loss per meter?
This got to read together with at low or high radio frequency (MHz).

low or high radio frequency?
At low frequency below 1000MHz, less signal loss per meter. At high frequency like 2xxxMHz, greater signal loss.

e.g.
Take RG58 cable as example, at 2400MHz (WIFI) it lose 0.77dbi per meter. If using 4 meter, it is over 3db loss already.
LMR400/RG8 at 2400MHz (WIFI) lose 0.22dbi per meter. Even using 10 meter, still not exceeding 3db loss, so these cable very expensive.

IN SHORT, FOR BEST RESULT, ALWAYS KEEP CABLE AS SHORT AS POSSIBLE, REGARDLESS WHAT CABLE.


Q3: Can use TV or Astro cable to extend?
A3: No. TV (RG59) and Astro (RG6) are different spec cable. They are 75ohm impedance. Where as here need 50ohm impedance cables.



===========
Price & Dealing:
===========
1 Antenna: RM80 each
2 Antenna: RM75 each
Adapter cable: RM8 each

note: Yes/P1 modem is using 2 antenna system for MIMO operation (double up speed)

Poslaju:
1 antenna: RM8 peninsular / RM11 sarawak / RM13 sabah
2 antenna: RM11 peninsular / RM18 sarawak / RM20 sabah.
COD available in KL at my preferred location only (free of charge).

Call/SMS/Whatsapp: ZERO ONE SIX - 9963861


This post has been edited by coolstore: Sep 7 2016, 10:24 PM

reserved ......

reserved .......

The new P1 WiMax modem. This white+green modem, how to connect? I'm using this modem. If can use, quote me the price Thanx.

i'm finalising the details, will pm later when ready. yes, it can connect.

Ok, PM me when ready. Thanx.

pm done.....

PM me how much.

Possible to connect to YES huddle? I think got connection point.

What about old P1 black USB?

pm just done.

hi coolstore,

I'm interested to find out how to I connect the antenna to Yes Zoom. PM me the price as well. Thanks in advance.

hi

this antenna can connect to dlink/tplink wireless router right?
how much with postage?

tq

yes, only for this model, it can be used on WiFi and WiMAX both, 2-in-1, more worthy than buying for wifi only panel antenna.

how to connec to Yes Huddle??
PM Me back

Recieved item fast shipping and answer! Recommended!

Btw got question my modem is that Saewon with 2 antenna do i need to let the other antenna attached?



Im getting this after connecting the antenna :

CINR Info 14/4 dBm
RSSI Info -80/-90 dBm
TX Power Info 6
Frequency 2305000

two antenna info:
===========
redtone, p1 and yes home gateway modem all come with two antenna design MIMO (just p1 and yes they use built-in antenna that ppl can't see).

in such design, there may be found a MAIN connector and a AUX (auxiliary) connector. (normally they print these label over the modem connector side).

Main connector having slightly higher wireless TX power (dbm) compared to Aux connector. Thus recommending putting higher gain antenna to the Main connector. And keep the other antenna attached, don't remove it unless some nessesary reason to do so.


CINR & RSSI info:
===========
RSSI simply the signal level: the lower figure the better
CINR the signal to noise ratio: the higher figure the better

u can take a look here: http://forum.vividwireless.com.au/forum/fa...-cinr-all-about

i don't have seowonintech modem details spec, so just borrow P1 modem spec as reference (gues more or less the same):



see the Receive Sensitivity: -82dBm@64QAM5/6

since u manage achieving -80dBm RSSI, thus ur modem running at that -82dBm@64QAM5/6 faster protocol, that's also why the reason u already can get faster speed in speedtest.

anyway, since you are in Sabah, try a bit harder to find more base station location by changing antenna direction may get you more choices which tower better in terms of RSSI and CNIR. yes, i know Sabah Sarawak base station quite far not easily seen (last time a 3G antenna buyer said base station 12km away...), so turn direction to try locate them...

This post has been edited by coolstore: Nov 16 2011, 11:33 AM

Pls pm me the price

Yeah about the RSSi and CNIR is quite familiar to me. I'm just a bit concern since the Modem is not putting signal streght report in both the Module and the program interface.

I will try again tonight and post report (hope will help you sell more

Also time to open the Modem. Ive heard that all AUX (split) antenna module has this Unified main Input...

Im gonna try to get about -65 t0 -75 dBi Levels as well as approx 20 CNiR.

Good item nonetheless. Its just that i need to configure directions...

---

Added on November 16, 2011, 8:12 pmCINR Info 20/-8 dBm
RSSI Info -71/-99 dBm
TX Power Info 4
Frequency 2305000

The best one Mind you the right side value is from normal antenna

Signal strenght 3/5

Improved alot... what happen if you have 2 of these LOL

This post has been edited by xcrave: Nov 16 2011, 08:12 PM

hye,

How much indlucing postage?

TQ

replied in pm already, pls check.


Wimax antenna ready stock, interested lym feel free contact me.

1st batch very limited stock only.

Hi can pm me how to connect with p1 white color modem? and how much you sell?

I'm also using P1 white tower modem.

Pls pm me the price pls.

Thanks.

replied to all .........

if nearest p1 signal is around 1-2km, can use this to get the signal?

base station range: not big deal
====================
3G/WiMax or other metro wireless technology's base station capable of broadcasitng at least X KM or even XX KM. (unlike WiFi normal router/AP which offer such a small area XX meter). if u can detect signal now, ie u r already in the coverage area.


the problem: end user point
==================
it is just the matter 3G / Wimax HIGH FREQUENCY signal can't go well down to the point where end user using it, particularly indoor.

(higher frequency = poorer indoor penetration capability; lower frequency = better indoor penetration capability).


solution: take iniative to 'shake hand' with base station
====================================
so by using external antenna (directional preferable), the purpose is to 'SHAKE HAND' with base station GOOD broadcasting signal area, then can get good signal / speed. It is not must go to reach to the exact location point of the base station, no need for that. (for wifi normal router/ap, then may need such practise bcoz their broadcast area are far small size XX meter only)

e.g a base station 8km away, using modem also still can detect signal, but signal weak/speed slow or frequent disconnection. after using a EXTERNAL DIRECTIONAL antenna focus back to the way base station signal coming from, you are actually taking self-initiative to say warm hello and shake hand with base station to establish a good and stable wireless connection. not just fully count on base station effort alone.

This post has been edited by coolstore: Nov 30 2011, 01:34 PM

Got my antenna from seller just now.

Installed and now monitoring my P1 speed.

Page loading has improved.

Thanks to seller for waiting even though i was late.



This post has been edited by BobThe Builder: Dec 1 2011, 10:29 PM

Received the item; thanks.

My results:

No change on signal strength after mounting (although if i walk around with it i can find spots with 1 bar away from full bar)

RSSI: -59 (Prev. -65)
CINR: 27/19.41(R3/R1) (Prev. 'bout 25/18)
Frequency: 2385000

Noticeable improvement on download speed (+400ish KBs) and slight on upload speed (+50-100 KBs) in speedtest. Previously was 'bout 1.9MBs download and 0.8MBs upload speed.



This post has been edited by glozz: Dec 3 2011, 11:56 AM

to explore full capabilities of directional antenna, you need to find the best direction which can bring in the best result (do more site survey, find ideal spot, ideal direction to surpass current result). Plug & play passive practise alone is not the way to use with directional antenna, it just fine for omni antenna only since they can't adjust direction.

luckily u already "walk around with it i can find spots with 1 bar away from full bar". so, if can, better relocate your modem and adjust antenna direction at those ideal spot, since this wimax modem got wifi, should be not much worry to relocate it to other place as the main purpose is getting the best wimax signal/speed/experience.

Got the unit from Coolstore this afternoon and just finished hacking it.

Here are the brief result from my Yes Zoom gateway....

Before:
[attachmentid=2571600]

After:
[attachmentid=2571602]

A bar increase, now Full Bars ^^)

Hacking the Zoom was bit troublesome especially lifting up the side casing cover. My clumsy fingers broke some of the side plastics... anyway it working now.

Thanks once again Coolstore.

Cheers.


PS*: I have tried both IPX cables, think the gray color one is the MAIN, coz it gave me the best improvement.

glad to hear that.

Bro... i just move out from my last location... there is no coverage here... and even if im pointing out of the window still cant get anything? Any Pointers?

got to check your new area is underserved by Redtone or not, if do, check with them the base station in your area got problem or else.

try this if can't access redtone wimax outside house / outdoor, means the base station got problem or the area totally out of coverage.

how to attach @ p1 wimax modem?

but you said if the base station is a few KM away no problem? im pointing direct to KK base station and im located less than 3 KM away from base station...

Bos, Pm Price ^^, Wimax Black modem... its Just Plug n play right?

that's why u need to notify redtone to let them check if that base station now facing problem or else. Just tell them no signal available. They will go check and fix their network.

---

Added on December 9, 2011, 2:04 pmfor using directional antenna to get improved result, u need to place the antenna to the direction where signal is better (ie closer to base station), so finding direction/ good spot is critical. Please don't have same practise like using wifi omni antenna just plug on router then wait and see...like that may not get any obvious improved result. User self-effort is very important to the end outcome.

but if u just mean the hand on installation matter, yes, u plug in via cable, then fine. no need soldering that kind DIY.

This post has been edited by coolstore: Dec 9 2011, 02:04 PM

I also using huddle, can it work on YES huddle?

I am using P1 white modem, PM me best price.
Also guide how to attach the antenna.
TQ,

pm detail price n how to to install at black wimax

huddle cannot use yet bcoz no suitable converter cable. Zoom confirmed can for the time being.

Today I just mount the antenna, if put indoor not much different, slight improve on CINR. Reduce lag and spike onlige gaming.
Got great improvement on signal strength if put outdoor.
But it is difficult to mount it on the beam, the panel is too heavy and wind is too strong (I stay at 17th floor). It can't hold on the angle I want.
Finally give up just put indoor.
Anyway thanks to coolstore for fast delivery.

This post has been edited by joel80: Dec 16 2011, 02:07 AM

Base is ok... not much i can do now... Selling mine PM me for Offer

a) put at window area (maybe put a table there) , facing out to the sky w/o blocking, don't put behind wall again.

b) or if u got useless camera tripod, also can use it to mount the antenna with anti-slip mat, and put the tripod near window, with that kind setup u can easily do antenna angle adjustment and even relocate tripod with antenna anytime u like, it is full of variety setup way... endless imagination (while got time i shoot a picture of sample)

i suggest (b) as angle adjustment very helpful at your scenario as u r at 17th floor to get desired result.

TS,

PM me ur details & price...interested to know...
fyi, i'm using P1 DX-230 modem....

Actually I am already put it facing out window. If put behind wall really no connection.
Btw, I get better signal using single panel antenna, remove both build in antenna in the modem.

this is very informative feedback. i would tell others to try this way (remove all internal antenna connection instead keep using internal x1 + external x1 and just use external wimax antenna) to see if getting even better result.

---

Added on December 17, 2011, 3:48 pmoh, too bad to hear ur new location is a complete blind spot of redtone wimax. anyway, did u see any neighbour using redtone wimax near to your house? if such the case, it could be to do with the new redtone cpe modem u bought, maybe not functioning well. if really no neighbour around using redtone, then it really a redtone blind spot area.

This post has been edited by coolstore: Dec 17 2011, 03:48 PM

how much for P1 white and green modem?
instruction to open the modem?

hi, guideline sent via pm, pls check, tq.

can you quote me the price plus the instruction for white P1 wimax? Thank you.

I'm interested but please PM me the instruction for P1 Wimax dx-230 and YES 4G ZOOM first with the price quotations. I'd like to know how it's done before buying. Thanks.

This post has been edited by cyphol: Jan 1 2012, 11:00 PM

ok, detailed info through pm already ...

do this come with the converter cable? how much including postage to PJaya?

still got some ready stock now....

bro, question..
can I connect this to YES huddle device, and how ?
coz the huddle doesn't has external antenna output.

thanks.

sorry, yes huddle can't make it. yes zoom can.

PM me price and shipping to Sabah for Redtone WIMAX white blue modem

Hi,
I'm using P1 "white & green" modem.
PM me the price and the howto.

TS, PM me best price including postage to ipoh for p1 white tower..and install guide..thanks.

pm me best price with postage...

ok, details through pm as well.

I am using P1 black modem, PM me best price.
Also guide how to attach the antenna.
TQ,

PM me price and shipping to Kuantan, also to be used with Yes Huddle (if that is possible)...

sorry, huddle cannot yet. zoom can.



This post has been edited by coolstore: Feb 24 2012, 11:16 AM

updates:

LAST 6 UNITS AVAILABLE FOR METTEOR-LINK 14DBI PANEL - 2IN1 FOR WIMAX & WIFI

can the Metteor-Link 14dbi Directional Panel Antenna be use for tplink TD-W8960N wireless router?

does the 14dbi need any booster or just change the existing 1 antenna left/right to it?

do i need to change both the antenna or left/right antenna? is there any different replace left or right antenna with different dbi antenna on either side?

eg the router on the left use 3/6 dbi antenna and the the right use 14 or higher dbi antenna, what will the result be? one antenna cover short distance and the other cover long distance, is that the way? omi and directional antenna together

how much for zoom? to Kuantan.

thanks

can work together, results varied with environment conditions.

booster is to boost device wireless TX power （dbm), not boosting antenna dbi. can use with or without booster. u can later add in booster if really need it for result.

8960N stock firmware should have no option to select how much wireless power for each antenna, so left / right equal, put any side u like, and changing the position to view got any difference.

---

Added on February 25, 2012, 7:45 pmok

This post has been edited by coolstore: Feb 25 2012, 07:45 PM

Hi coolstore,

I'm test use "Redtone" b4. No signal bar, just wimax signal only. But still can use,just some time will lost signal. If i additional WiMAX antenna: 14dbi Panel Metteor-Link will get at least 2 bar signal . Cos redtone station range between my house is around 2 to 3km.

This post has been edited by badboylo: Feb 28 2012, 07:41 PM

Soli wrongly posted, due to my english not good. I just wan to ask if I additional the attenna will increase my signal at least 2 bar?

for wireless matter, performance varied with different environment, there will be no standard answer available to your question. (i would be wireless god if i can tell any one how many bar exactly can up without ever been to some one place to do real testing )

you never know how much it improve before really using it, impossible to do guessing here.

hi bro,

sent you a pm....

thx!

This post has been edited by cincaluk: Mar 4 2012, 10:36 AM

LAST 3 UNITS!



This post has been edited by coolstore: Mar 11 2012, 11:34 AM

LAST 1 UNIT!

Im really interest on the above item...please reply me at dharankri@hotmail.com with good price...thank you

sorry, no stock already.

pm..=)

still got stock or not?
how to use for P1wimax the white modem. cn u give some instructions.
n the price too.
thnks

sorry, no stock already.

haha, i notice a very weird trend that whenever a stock run out, only by that time got a lot demands, when stock ready then seems on the contrary

haha.

me brought wifi directional/omni antenna twice times from you before.

sound interesting..next in plan will try consider this wimax directional panel antenna

Helo.
i'm using modem ZTE MF600.
i'm planning to increase my 3G signal.
any recommanded antenaa?. please PM me
if ur price is ok. i'll buy it now!!.

for 3G, use only 3G antenna: 2100MHz, http://forum.lowyat.net/topic/1731077

not wifi or wimax antenna.

Still avaliable????
How to use with my dv230 modem??

Still available? Using P1 DX230 with 1 bar all the time and 2 bar occasionally.
Pls PM me the price.

Hi,
I'm using P1 "white & green" modem.
PM me the price and the howto.

hi. please pm me price & how to connect to my P1 dv230?

PM me how to open Yes Zoom casing n attach d cable..pricing too
Tq

Please PM me the price and how to install on P1 DX230. Any sample pic on how will it look like after the modification? Thanks.

how much is it ? please send me your contact.

Hi coolstore,

Any more stock for this item?

Hi Bro..i am using yes zoom...got any product to increase speed?

So far i can get only 3/5 bar only...speed only 500kb..damn

bro,is this compatible with uh235 modem? pm/reply me.TQ

pm me price with postage to jb
