......subtitling_type = 0x10 (16)

It just normal SD subtitle instead of progressive subtitle?

RTM HD channels are actually using SD subtitle instead of HD subtitle.

In the TS capture by SmartDVB and ProgDVB programs, the subtitling_type is shown as 0x10 on DVB transport stream analyzer.
If the subtitle is in HD, then subtitling_type will shown as 0x14 or 0x24.

Still, it doesn't explain why my V8 Pro decoder can show Brunei HD channel subtitle while can't display RTM HD subtitle because those brunei HD TS capture via smartdvb and progdvb also show the same 0x10.

It is possible SmartDVB is recording lower level type of subtitle in TS compared to the decoder.

Here two samples. One from openbox v8 pro and one from SMARTDVB
https://www.sendspace.com/filegroup/ysXajSjhZr1IbemcamOCPA

Looks like it's using image subtitles with widths as much as 894 pixels, that's more than SD right? No idea if it's progressive subtitles or not and other details yet since I haven't got a software that can analyze those.

Here's a sample extracted subtitle image:


Other info that are of interest to some:
Video: 1920x1080, 25FPS, interlaced, AVC high@L4, ~3500kbps
Audio: 48kHz, stereo, HE-AACv2, 46~48kbps (24kHz, mono on decoders without HE-AACv2 support)

Tried manual search key in frequency for gunung Serapi no luck getting ntv7 or 8tv. Only got tv1, tv2, HD sports rtm, radio, BES only. Shitty channel. Any solutions to this sifu kopitiam? Change to astro njoi, get new TV with built in dvbt2 or try other antenna?

Mean I shall adjust it higher again?

Already adjusted to point the transmission tower at Serapi. I use the transmission locator app to align the antenna. Where you buy that Yagi in Kuching?

How much ya and you know the shop name? Maybe I try to adjust it higher first my current antenna and see if can capture ntv7 and 8tv. Coz my opposite relative house can watch both channel without antenna coz his TV got built in dvbt2 tuner and maybe his house location is a little bit higher compared to mine

Alright thanks very much bro. Btw how much is rg6 astro cable?

No le, I follow antenna apps and point it straight to the transmission tower.

Confuse, how do we differentiate VHF and UHF antenna?

im use digital tv with dvb-t2. no rtm sport hd. rtm sport hd only for satellite??

my signal strenght 60%
mayb because this i dont get rtm sport hd??

Noted with thanks, digital supposed to be uhf only right

ur right
rescan manual not get rtm channel. rescan auto get rtm channel.
but my rtm channel get on frequency 698.strenght 46% . stuck,ok,stuck,ok
media prima ok.get on frequency 666.strenght 65%

Please , anyone know where I can get last NTV7 Saturday 28-7 schedule

No epg , not everyone subscribe newspaper.

Conclusion,  no other way to check for last week schedule ?

yeah, i know the official box can't do PVR and movie playback. only wifi is not disable, can connect but dunno what function it does.

MYTV can provide HbbTV services, but the hundreds of thousands ringgit question is, which broadcaster are interested to implement that?
If no one wants to provide that, then MYTV is like selling many big nice houses that nobody buy.

what button to press on the official mytv decoder to access for the HbbTV?
