QUOTE(nasi lemak 20 sen @ Oct 12 2021, 08:01 AM)
Kedah class upgrade proposaloriginal Kedah
[attachmentid=11007168]
Questions about your proposal.
1. top deck weight.
That area is designed to have just 1 RAM launcher of about 6tons of weight. Adding a total of nearly 30tons of weight (5 times the designed weight of that area) will seriously alter the ships balance. The ship would be bow heavy, and momentum of such heavy weight at that height will worsen the ship roll and pitch behavior.
1 RAM launcher = 6tons
1 Adaptable Deck Launcher = 7.5tons, 2 of them 15tons
8 Exocet missiles + launcher = 8tons
total of at least 29tons of weight
2. Area.
At most, the area is about 15m in length. As the area is at the bow, the width tapers towards the 76mm gun. So the minimum width is just around 6-7m. A single adaptable deck launcher size is 7.2m x 3.9m x 3.1m. You cannot fit RAM + Adaptable Deck Launcher + Exocet/NSM in that area. There is no space.
3. Putting Mk41 VLS.
Mk41 VLS shortest height is 5.2m and weighs 12.2t for the 8 cell version. A lot of things you need to remove, at least 2 decks below.
4. Shooting ESSM to the side.
You need a lot of extra space to shoot it, if you don't want to hit other ships.
