Hi there, i'm deciding to start my project log in Lowyatnet here with not much on the modding parts coz i don consider myself as a real modder.
As a real modder you need some talent and lots of patient, which i don have much on both of it ha.
I got most of the hardware on my hand to water cool an I7 platform inside my TJ07.
I'll try to finish my project before chinese new years. (hopefully )
And i wish this project log will not dissapointed you guys and of course myself.

Playing with computer hardware and all those liquid cooling parts really cost me a bomb, but i'm enjoying it.
Liquid cooling computer hardware already become one of my hobby and it cost me most.

The initial of the project, i bring you guys this:

Starting with this:



Yes you guess it right, its a hammond box.
The essential of murdermod style TJ07.
And yes i'm copycat.

Now bring you to my lovely sweety TJ07, its nake now haha.
This is why i like her most.



to be continue...

This post has been edited by nej: Jul 4 2017, 12:43 AM

Try to cover up this ugly area.



My little hammond box gonna help me out.



Hmmm.... it looks much more better now.


I'm trying to making it better.


Now i can say it's cool enough.



That's all for today, thanks for checking in.

Looking forward for updates. But before CNY ? Thats quite short time.

nice casing u have

can take shots of the other side of the toolbox? i wanna see how to cables come out if you don't mind.

@freeman1314
Ya the time is short, but I'll try my best to complete it.

@jiroHC
Thanks bro.

@don^don
I did make an opening on the other side for cable.
The opening isn't so nice that's why I didn't make a shot from other side.
Hmmm... I think I'll still make a shot or two by tonight.

Can't wait to see the whole build. Do keep update oh!

@rc2x
Working hard now, life is too busy.

Some photo of sleeved psu, my little corsair HX1000.
Its actually a gift from my very very old good friend, bro acther.
It has a story behind this psu, i really appreciate this.

Ya i know, no story here.
Here you go with the picture.

The PSU itself


MDPC-X ftw!



8 pin done.


And the 24 pin.


It took me around 3 days getting to this point.
Wake up--->sleeving--->eating--->sleeving--->sleeping
Ha ha maybe a bit too much on my description.


Proudly to present you the result of MDPC-X sleeving.
I'm satisfied for the result.


Thanks for viewing.

did you use heatgun or hairdryer? that is some awesome job on the sleeving bro.

cheers.

rajin la TS~what are the other items?

haha nej long time no seee

awesome sleeve, hope i can hav tat skill too..

@Hantarkatsini2
Thanks bro, I'm using most common item (lighter).

@da drummer
Thanks, will take picture later.

@acther
Hi bro, long time no see ha ha.
Sure find u yamcha when I go KL.

@lun1986
Thank u, just need more practice and a little bit patience.
I'm sure u can do the same job.

very nice sleeving u done,bro
where to get that Kluang Edition pin remover?
i want to buy also.

i supposed to get my sleeve tonight but..

@mudd123
Thank you, the pin removal I bought directly from MDPC-X.
Sounds like u having problem getting ur sleeve.
I think few forumner was selling MDPC-X sleeve here, maybe u can contact them.

---

Added on January 18, 2011, 11:45 pmBtw i miss out 1 photo that i suppose to post here.

The other side of the hammond box, opening for cable.


This post has been edited by nej: Jan 18 2011, 11:45 PM

nice.... keep it up the worklog of yours nej. i'm waiting for the next pics

@kinozawa
Thanks for the encourage bro, it really means something to me.

I afraid my progress are running too slow, and nothing to show you guys.
So decide to take some picture for my hardware to keep my project alive.

So let the picture do the talking:


The mother board.



Really like the design of original heatsink.
oppps i mean ASUS, not the INTEL heatsink.




The CPU block.



I like this photo.



No sequence photo of installation, because i'm lazy ha.



Take out the original heatsink.



New shirt for my R3E.







Chipset block on.


To be continue.....

This post has been edited by nej: Jan 23 2011, 11:30 PM

Damn it looks sexy...

um, is the ROG logo upside down?

kluang edition??

any story behind that?

@Braynumb



@Jinster
Yup, its up side down to fit my invert atx mobo tray.


@Hilmiangah
I pay nils and he send me the remover.
Maybe he saw my mailing address, so he putting it on.


Continue hardware picture, because cannot load so many picture in 1 reply.
My double blade.





I know its not powerful enough, but its more than enough for me.


My EK twin.

Wait a minute.... it can't consider twin, the color......


No worry about it.





Ahaaaaa......



GC blocks on.



It took me around 3 hours getting to this point.



Last picture i got to show you this.


Thanks for viewing.

hi there, very nice work there...

anyway, can u get the length measurement of the 5870?

thanks.

@ravewar
Thanks you.
The length of 5870 was 11" or 280mm water blocks on.

This post has been edited by nej: Jan 24 2011, 11:09 PM

where to get that hammond box?kinda cool.

u from Kluang dude??

TS modder from Kluang?
It's very rare to find modder in Kluang,probably because of lack of high end computer parts here

thats why

i know u and me are from there

wa banyak cantik la. Lu banyak kaya la. bila datang kl belanja me minum keke

Call silverstone Taiwan call them send u a tj11 for review haha

This post has been edited by acther: Jan 25 2011, 05:19 PM

nice worklog...waiting for tomorrow update...

@kursk
The hammond box I bought from PPCS USA.

@hilmiangah
Yup kluang is my kampung.

@super_evil_alien
Ha ha not a real modder here.
Hardware isn't a big problem here, but not much member with same hobby.

@Acther
Jangan ketawakan saya la, my big brother.
U are the one who poisoning me most hehe.
But too bad, u already retired from wc.
I go KL sure looking for u to belanja me yamcha haha, coz now u big boss lo.
I think taiwan there can't send me the case, maybe u can. (kidding)
Keep in touch bro.

@jungle_boy
Thanks, will update when I have progress.
Looks like wont be so soon, now is critical part.

bro where did u get the 5870 plexi cover ..

@reiben05
The plexi top I get it from brother Vlad.

huhuhuhu terliur tgk TS nyer TJ07...
aritu ade satu tpi sbb xde buyer cosmos1000 ni xleh nak grab...
nak pakai 2 casing mcm buang tebiat plak...hehehehehe

btw nice job bos...

Thank you bro, ok juga guna cosmos1000 cukup cantik tu.



Sorry guys, i cant finish my project as i promise before.
Now CNY was finish, my rig is only half way to go.

I did expect 1 major upgrade during CNY, due to this ETA i stop all my internal parts assembly.
But after so many day and night for waiting, i gain nothing (hmmm... i think i learn something).... maybe the santa claus doesn't like me.
It's ok, the life still goes on. At least i can start to catch back the progress of my rig.

Ok, time to continue my on going project.
This update i'm going to touch my casing, some opening for cable management should be cool ya.

Here you go with the picture:

Some opening for the cable management.
Mid plate, mobo plate and invert atx back plate.



roughly mark up the position for some cable route through.


Items for hole opening-->hole saw+rotary drill.



First hole done, and the second.



closer shoot.




Rubber grommet attach.




Mid plate done.
Finger print all over the place.

I apologise that i didn't going into detail, i'm the kind of person that can only do 1 thing at a time.
I really cant drilling half way then stop and take out my camera taking photo.

Thanks for viewing.

awat tak angkut TJ-11 terus ..

pro modder jor keke. now i bekside itchy wanna play wc again. when u wanna help me out =P

TJ-11 not my cup of tea , and i think the price range i cannot effort.
Btw good job on your modding worklog. looking forward on that.
Just saw that you wreck your mom's civic few months ago, lucky u didn't wreck your dad's Alphard ha. (just kidding)


No la bro, just small mod. there are so many sifu here.
if you really play WC again, i sure help you out. (but must finish mind 1st haha)
I miss your 20k rig hehe.

suggest to cut out this blocking piece of evil to allow molex to EZ plug connection

nice nej. looking forward for the updates on your project

OMG! i totally forgot this little sucker, the little part should be cut on my original plan.
I won't be able to cut it right now, the reason will be show in the photo later.




Thanks bro, hope the result won't dissappointed.



I got my parts back from powder coating factory, the result was so cool...
But bro owikh point out 1 important part that i should mob a little but i didn't.
I afraid if i cut it right now it will affect my powder coating on that part, so right now i shall remain like that.
Might cut the little sucker later, i'll see how this thing go.

Just took a few shoot on some powder coating result.





Test assembly, this is so cool with internal black... yet still long way to go.
I think all the TJ07 should be manufacture internal black by silverstone haha, what do you guys think.




Thanks for checking in.

I think I smell an epic rig is coming out from u.

wow..nice...how much for powder coat cost...?can give some hint..? ..looking frwd for more update..

Cut this piece then the casing not will shaking ? Because this is used to support the panel

there's still a portion of this piece supporting the panel to PCI hole.
so u can cut it partially just to allow that molex connector passing thru.

Thanks bro, the powder coat cost me RM150 for whole internal black.
If you in Kl area, Ronzmod should provide you better price on that.
the only problem is he too busy.

Bro owikh already answer ur question.
As i think there will be reduce some degree of rigidity (minor), but still within acceptable level.
It confirm workable and proof by our legend modder Mr. Ianho.

I'll test fit 1st then only decide whether to do a plastic surgery for that little sucker or not.

bro your inverted mobo plate who did for u..? very nice

before this i didn't know Ronmodz can fabricate, so i bought it from Chillpc UK.
Really cost me a bomb haha.




And the progress going on.
today gonna show you guys the radiator and fan that i'm using.
Its TFC480 and Scythe S-Flex 1600RPM.

Here you go:



Small box underneath hehe.



Fan wire going underneath with p-clip attach.



Black color fan molex.



Overall shot.




Test fit to check the space between bottom and mid plate of my tj07.
Exactly the height that i want.



On the othere side.



Thanks for checking in.....again.

TFC480 is a damn thick rad. push pull fan is highly recommended.
but for this setup to in order to close the side panel u need to push in the rad a lil bit towards the PSU. and this time u gonna need 2 slim fans to fit into the clearance between PSU and the rad.
inverted ATX, I'm sure u need to extend that casing cables as well as USB cables right coz the Q connector and USB connectors are at the top now. correct me
ehh that day I also forgot to paint the two vertical supporting metals at the back case.

ic..how much did u pay for it..? if u dont mind sharing.. and how are u planning to mount your rad at bottom case..? are those doublesided tape..?

how heavy for that TFC480 and Scythe S-Flex fan?
dont think so to double side tape that. must need other support material.
if that rad get fill up with coolant, lagi berat.

Yes TFC is a thick rad, but now doesn't have plan to use push pull configuration since its fpi doesn't as high as BI rad.
I'm not a hardcore OC'er, and i'm searching for balance between OC/temp/noice/performance/appearance.
I need some clearance between rad and psu for tube looping, it will more clear after i show you the picture......later(not so soon).
You are right, i need to extend the power switch cable and usb cable. Thats why until now i haven't sleeve the power switch cable.
Actually i purposely leave the 2 supporting frame like that just to creat some contrast effect. And most important its murdermod style ha.
Thanks for the suggestion.

For the price you can always check it on chilledpc's website.
Very eye sharp bro, yes i'm using doublesided tape upside down hehe.


Not so sure about the weight, but the 3M doublesided tape is quite strong.
Try shake a bit after i tape the rad, it remain steady.

This post has been edited by nej: Feb 20 2011, 10:58 PM

ic thanks bro.. cant wait to see u finish it. hahaha

looking good there bro ..

wish i got a case to stuff a 480 too

Not so soon, i'm still lack of 1 important item.
Will update when i have prpogress.

Thanks bro, you can always have a.....FEW case for 480 rad if you want to.

---

Added on February 23, 2011, 1:23 amHi all, no progress until now.
Received 1 parcel few days ago from far far away, haven't try all the stuff out there.
But decide to show you guys what's inside.



Well.... i guess all of you will know what's inside after i show you the 1st picture haha.
Here it is...

No! Its not sleeve inside, its some other things.


A crimping tool, i know it can be purchase locally.
Just cannot resist to spend money to Nils' MDPC-X when i saw the stuff.
Well, i guess i have to stop browsing MDPC website..... or maybe not too offen hehe.



Here is another shot of the crimping tool or can i call her a "T-Rex"?


Its pretty much a "T-Rex" right now.



The molex power connector.





And the crimp contact for fan.





The crimp contact for ATX and PCIE.





Try to fabricate some wire for cable management with all the stuff above.
A bit worry on that, because never done all this before.
It should take me a week or 2 to make some cable.
If the next update i'm showing other things than this, you know i'm fail haha.

Thanks for viewing.




This post has been edited by nej: Feb 23 2011, 01:23 AM

nice bro, i hope u can do a bulk so other can join to

aiya.. but nvm i will wait.. hehehe this is gonna awesome i guess

DHL snail took u 3 weeks to arrive. That's damn long.
Guys who wanna do bulk order for cable sleeve take note that it's a taxable item, 23% tax, unless if total value+shipping is less than RM500 then u will get away from tax. Just to share.

if the item is marked as 'gift' also wun get taxed right? i bought shoes from outside, the values itself already more than RM500.

Yes depends on qty brought in also, 1-2 ok la can mark em as gifts. But can advise the shipper to declare total value under rm500 then u will be fine.

I see. Thanks for that info bro.

Thanks bro, bulk is not a problem.
I think few forumner carrying MDPC-X stuff, it will be easier if they have ready stock.

My project is running much more slower than i expect, still encounter few problem at the moment.
I'm just kind of lazy......

DHL took 3 weeks to arrive!? I have some experience shipping with DHL, it took only 3-4 days from Uk to MY.
Maybe it was the custom problem that delaying ur stuff.
Btw thank for sharing bro.

Answered by bro owikh.

Hmmmm..... very important information.




Ok Its me again.
I have very little progress, manage to make some cable for my GC power cable.
the original corsair's power cable was not long enough.
Try out my "T-Rex" today, the result are satisfactory.


here you go.....

Cut out some wire to the length that i need.





My T-rex was crunching the atx crimp connector.



1st wire done, the result not bad.
What you pay is what you get, Nils' product was always perfectly done.





All 6 wires done, i finish all 6 wires at around 1 hour times.
I was surprise it was quite easy to handle, maybe the tools just right.





6 Pin power connector.



My 1st 6 pin GC power cable consider done.
Will sleeving it later.



This update was actually quite boring i think, hopefully the next update will be more interesting ha.
Thanks for checking in.

nono, customs handled it efficiently, just that Nil sent it by DHL snail mail, not Express.
And was too overcharge for such a slow postage.

This post has been edited by owikh84: Mar 2 2011, 07:01 AM

bro.. got confused with 1 thing.. u doubleside taped ur rad to the hammond box. but how are u gonna secure it to the case..? do u just leave it like that..?

Where's the finish product???

Now I understand that.

I applied double sided tape on my rad to my box and taped the box to my casing. Hope this is clear for u.

Sorry guys, another delay on my project.
I promise to get back on track later.

2 things that delaying my project.
One is changing my precious proc and wait for the Aquaero 5(Already place order, eta mid Mar).
2nd is working out some job for my very very good friend bro Acther. You guys will see the result soon, either in this thread or a new thread.

Update coming soon....

nice BOB!

Bro I have a question, where did you buy the hammond box?

Hey Jen.... Wassup dude.... that gc is our 5870??? U still keep her ya? Btw, very nais done Jen.....

Thank you.

Actually i source it from chilledpc UK together with my others WC stuff.

Hi bro, the 5870 gonna kicking in my rig later.
I think i have to rush up my project a bit, the gc are sleeping too long haha.

hahaha.. time to wake them up... nais modding bro..... dont forget gimme ur benchmark result soon...

myself also taping my PA120.4...
my tape can hold 20KG = =

i still got few hammond box left to sell.. anyone need it ?


did u extend ur casing wire and psu wire....?
after btx like not long enu to do cable management.... jus gam gam reach

This post has been edited by pennykia: Mar 21 2011, 04:11 PM

interested with the hammond boxes. could you drop me a PM bro? thanks.

Bloody nej!! Sneaking at my back play PC kao kao....

CrossfireX summore.... Say wanna retire.... HAHAHA!!!

ha ha, coming soon...

Ya some cable cannot reach, have to extend some wire on it.

lol, i retire 1 year then come back again.
kena poison lo.

Hi guys, i'm digging up my old and long project again.
Lots of things to settle on last month, and most of the times i spend on the sleeving project.
And i'm spending quite some times to selling some hardware for 1 of my very good friend.
My time frame of own project really beyond my expectation or maybe i'm just a bit lazy on this.
Sometimes i just feel like not going to continue this project, but its a shame to have this kind of thinking. (i knew)
So this is the time that i think i'm ready to continue and finish it in proper way.
So this time i'm not going to set a dead line for myself, but i'm sure that all my hardware are 99% on hand now.
I expect my project can be complete before the "sandy EE" or "Ivy bridge" launch.
So today i'll just bring you guys some teaser shoot.
Not really have some real progress here, but just to show that my last piece of puzzle was arrived.

Here you go.

I'm proud to show you my newest, hottest and beautiest fan controller.

Brought to you by.....




And the real little b**** that let me wait for more than 2 months, but it worth for waiting.




Ha ha there is another brother that come along together.
Ya 2 units of Aquaero 5, 1 for me and another for my best friend bro 'acther'.




The backside of the Aquaero 5.




With the heatsink on.




The only problem is i received this beauty without software. lol
The Aquaero 5 software still under developing, its just like a body without soul hehe.
I ordered the black colour faceplate as well, they will ship to me later.




Thats all for today, the progress of assembly water cooling and computer hardware will coming along.
Thanks for dropping by...

if no software..then need to wait some more lu~

Aquaero 5!!!

how much per unit bro...? really nice...

Haha i'll do other parts first.

Ya Aquaero 5, you can get it from forumner "jibek".
For the price, i think you need to get a quotation from him.

Hi everyone, i'm here to bring you guys some update.
Today i connect some tubing on the water block.
Primochill 3/8ID 5/8OD tube on Bitspower 1/2 barb, without clamp.
Although its a bit difficult to push the tube into the barb, but the result come out quite nice.

Here is some of the result.

With the motherboard load on the TJ mobo tray together with my dual 5870.








I like the D-plug between both GC than crystal link.




1st tube on.




And the second tube.





To be continue... soon...

That is.. Beautiful....

woah..u're making people feel very eager haha

oh my this work log filled with poison... must resist

Ahh... That's so beauty... keep 'em coming ><

Thanks bro.

Opps, seriously i didn't mean it.

Ha ha sometimes a little bit poison is good for ur health.

Thank you.
I'm trying my best.

Hey,nej,where are you located?
I would be interested to get some case mod done

step-by-step~~ lead to poison me tooo.. urgghhh.. nice worklogs..

I'm glad to heard that u interest on some case mod.
I'm from Johor.

Hope you like it my fre.
