Finally found a company that provides Solar Panel as replacement for Awning.
As my house require awning to shield the rain and sun on the 1st floor, was thinking to save cost by having solar panel as electricity generator and sun/rain shield. And they quoted me this:
8.265 KWP Grid-Tied Solar System1. 182mm 144cells 435W Half Cell 19Unit RM620.00
Total RM11,780.00
- Brand : Trina Solar
- Model : TSM-NEG9R.28_435W
- Nominal Maximum Power (Pmax) : 435W
- Optimum Operating Voltage (Vmp) : 42V
- Optimum Operating Current (Imp) : 10.36Amp
- PV Array : 19 x 435W =8.265 KW
2. Inverter 15KW 3 Phase 1 Unit
Total RM3,680.00
- Brand : Think Power
- Rated Power : 15KW
- Max DC Power : 22.5KW
- Maximum PV Array Open Circuit Voltage :1000VDC
- MPPT Range @ Operating Voltage : 250 - 850VDC
- MPPT Tracker : 2 / 3 String
3. Aluminium Profile 42 Unit RM65.00
Total RM2,730.00
- Price : Mtr/unit
- Without Anodizing
4. Metal Structure
Total RM5,300.00
- MS Sq Pipe 4"x4" x 6mtr (Thk 3.0 mm) 3
- MS Rec Pipe 3"x6" x 6mtr (Thk 3mm) 4
- MS Sq Pipe 3"x3" x 6mtr (Thk 2.0 mm) 3
- MS Footing plate & M20 Wallplug 5
- Protecting cover ( leakproof) 1
- Heavy duty paint ( primer + top coat) 1
- Miscellaneous (Silicone glue & others) 1
- Remarks: Exclude drainage
5. Labour Cost
Total RM5,500.00
- Labour + tools + fastener + bracket
6. Wiring from Solar Panel to Inverter & Electrical Cabinet
Total RM3,500.00
- Include all wires &
- Enclosure box
- Electrical components
- Wires & cable
7. miscellaneous Charges
Total RM4,200.00
- Transportation
- Documentation
- Insurance covered
Grand Total :RM 36,690.00
Are the specs of the panel and inverter OK?
Just started learning about solar panel
