Home solar 4 months in.
|
Jason
|
 Sep 5 2024, 09:52 PM
|
|
QUOTE(bee88 @ Sep 5 2024, 01:51 PM) They are facing two different side are they? Thst could explain the voltage difference. Same side. No shading whatsoever, terrace house all level. I will ask them how they wired the panels later.
QUOTE(adamw @ Sep 5 2024, 02:03 PM) Check during noon time see have much difference, morning & evening definitely have! I check morning, noon, evening. MPPT1 is always higher than MPPT2 in terms of voltage, amps will be close. |
|
|
|
|
|
Jason
|
Jul 10 2025, 04:36 PM
|
|
|
QUOTE(ad2000 @ Jul 8 2025, 11:44 AM) My solar average output with 8.2kWp capacity per month is around 900kWh while daily is around 34kWh QUOTE(lkyoong @ Jul 8 2025, 01:06 PM) Looks to about the same. 8.05kWp and getting about 850kWh with daily about 32kWh in June. 850kW for June on 8.05kWp? What’s your inverter size? I did 865kW for June… 6.8kWp on a 5kW inverter. Wow I am very very very very happy with my system’s performance… all the homework I did paid off! June is my best month this year. |
|
|
|
|
|
Jason
|
Jul 11 2025, 03:31 PM
|
|
|
QUOTE(GuyM @ Jul 10 2025, 08:38 PM) Today is the best achievement since installing think it’s the same for plenty here Same here 42.21kW 5k Huawei Sun2000 3phase inverter. Hehehe What’s your setup size? QUOTE(I-Kurosaki @ Jul 11 2025, 10:20 AM) Was sunny and clear yesterday. The chart was almost bell curve perfect. Mine generated total of 74.8kwh. That's equivalent to 5.8 sun peak hours  Big system, 8kW inverter? This post has been edited by Jason: Jul 11 2025, 03:32 PM |
|
|
|
|
|
Jason
|
Jul 11 2025, 11:32 PM
|
|
|
QUOTE(GuyM @ Jul 11 2025, 05:33 PM) 7.38kW 12 panel single phase micro only Gotta admit yours perform very efficient |
|
|
|
|
|
Jason
|
Jul 18 2025, 12:43 PM
|
|
|
QUOTE(nite_eif @ Jul 16 2025, 12:08 AM) can u share ur setup..wondering what mine can be improved.. mine is 6.15kWp on 5kW inverter also, max achieved so far june n july 581kW..daily max around 24-25kW only.. roof facing south, using huawei sun2000-5ktl-m1..single orientation..10 panels.. You’re looking at my setup in the quoted message. 6.8kWp panels on 5kW huawei inverter. The trick is to oversize more for huawei inverters, and you get better yield during ramp up and down before the peak sunlight. Would not spec it this way if it was other inverter. I feel huawei is king when oversized accordingly. My panels are facing north. 0 shading. |
|
|
|
|
