MD 530G Scout Attack Helicopter

MD 530G is a next-generation armed scout-attack helicopter developed by MD Helicopters. It is designed to provide enhanced agility and firepower for the armed forces.


MD 530G is a next-generation armed scout-attack helicopter developed by MD Helicopters. It is designed to provide enhanced agility and firepower for the armed forces.

The armed aerial scout helicopter can be deployed with any rotary-wing unit to provide a comprehensive battlefield command-and-control coordination for the successful execution of attack, reconnaissance and security missions.

The helicopter was unveiled at the Helicopter International Association conference and exhibition (Heli-Expo) held in Anaheim, US, in February 2014. It successfully fired 0.50 calibre and 7.62mm ammunition, and four Raytheon TALON laser-guided rockets during live-fire qualification exercise at Yuma Proving Grounds, Arizona, in August 2014.

Orders and deliveries
MD Helicopters was selected by Malaysia’s Ministry of Defence to supply six MD 530G helicopters to the Malaysian Army Aviation in February 2016. The company selected CTRM Aviation as the exclusive authorised service centre to support the entry of six MD 530G helicopters into the Malaysian Army Aviation in April 2016.

The US Government announced its commitment to provide six MD 530G light attack helicopters, associated equipment and training to support the Lebanese Armed Forces’ rotary-wing close-air-support missions in December 2017.

The US Army Contracting Command awarded a $1.4bn contract for six armed MD 530G helicopters in October 2018. Scheduled to be delivered to the Lebanon Air Force (LAF) by the fourth quarter of 2020, the helicopters will be equipped with two Genesys Aerosystems IDU-680 LCD primary displays, Tek Fusion Global’s PATHFINDER™ mission management system (MMS), and Harris Falcon III RF-7850A-MR multi-channel airborne networking radios.

MD Helicopters partnered with Elbit Systems to provide the advanced weapons and mission management capabilities to MD 530G Block II (BII) helicopter in December 2019.

The new MD 530G Block II (BII) helicopter with advanced avionics system was first displayed at the Helicopter Association International Heli-Expo held in Anaheim, in January 2020.

MD 530G design and features The MD 530G armed aerial scout helicopter is designed based on the MD 530F airframe and is engineered with advanced technology to deliver enhanced combat capabilities. It offers efficient and effective performance in adverse conditions.

The Armed Aerial Scout 72X (AAS-72X), an advanced derivative of UH-72A light utility helicopter (LUH), is being offered for the Armed Aerial Scout (AAS) programme of the US Army.

The helicopter is 7.76m long and 3m wide and has an overall height of 2.88m. It has five main rotor blades and two tail rotor blades. The main rotor diameter is 8.38m, while the tail rotor diameter is 1.55m. The helicopter has an empty weight of 885kg, maximum internal gross weight of 1,520kg and maximum take-off gross weight of 1,701kg. It can carry an increased useful load of 816kg to operate with additional range and endurance.

MD 530G weapon systems
The helicopter is equipped with Raytheon’s 70mm TALON laser-guided rocket to provide precision engagement and firepower capabilities against soft and lightly armoured point targets. The rocket features a laser guidance kit incorporating digital semi-active laser seeker, a three-axis control actuation system, guidance electronics, and the TALON roll-optimising tail-fin assembly.

A Heavy Machine Gun Pod (HMP-400) developed by FN Herstal is mounted in a 14in Nato standard bomb rack on the helicopter. It features a 12.7mm FN M3P machine gun with a rate of fire of around 1,100 rounds per minute. The helicopter is also equipped with a Rocket Machine Gun Pod (RMP), which is effective against both guided and unguided rockets. The RMP combines a 12.7mm FN M3P machine gun and Nato Standard 70mm three-tube rocket launcher into a single weapons mount. The machine gun can store up to 250 cartridges.

The helicopter is fitted with Dillon Aero’s 7.62mm M134D-H (Hybrid) mini Gatling gun that can store up to 3,000 rounds of ammo magazine. It also features an Arnold Defense M260 seven-shot rocket pod.

The third-generation, 24.2lb Moog Weapon Stores Management System (SMS) is installed to manage and control the helicopter’s weapon systems. It consists of a Stores Management Computer (SMC), two Stores Interface Units (SIUs), two Lightweight Rocket Interface Units (RIUs), a Multi-Function Display (MFD), and a Stores Control Panel (SCP). The MFD and SCPs are installed on the cockpit panel, while the other systems are incorporated in the cargo compartment.

The helicopter is also configured with a lightweight Mace Extended Range Weapons Wing (ER2W) with four-station weapons mounting structure. It can carry more than 1,300lb of weapons and ammunition.

Sensors on-board MD 530G
The MD 530G armed aerial scout helicopter is equipped with combat-proven L-3 Wescam MX-10 and MX-10D EO / IR tactical surveillance systems in a single line replaceable unit (LRU) configuration. The payload incorporates multiple infrared imaging sensors, precision optics, laser designator, and an advanced communications suite.

The infrared, colour HD and electron-multiplied Charge Coupled Device (CCD) imaging sensors are used to capture simultaneous full-motion digital video and high-resolution imagery.

The 43lb multi-spectral targeting system features a built-in embedded GPS inertial navigation system to provide high-accuracy geo-point and geolocation capabilities. It is equipped with four-axis stabilisation with vibration isolation to support laser designation of more than 10km.

A Scorpion Helmet-mounted cueing system, developed by Thales, is also fitted to the helicopter.

MD 530G engine and performance
The MD 530G scout attack helicopter is powered by a Rolls-Royce 250-C30 engine, which generates a power output of 485kW.

The helicopter can fly at a maximum cruise speed of 240km/h at sea level under international standard atmospheric conditions. It has a maximum permitted speed of 282km/h at sea level and can fly to a range of 426km. The MD 530G can operate for two and a half hours with an auxiliary fuel tank.

The helicopter is also installed with a ballistic tolerant crashworthy fuel system, which includes both main and auxiliary tanks.MD 530G BII

The MD 530G BII helicopter features pilot-friendly integrated weapons system (IWS), which includes a helmet display and tracking system (HDTS), weapons management system (WMS) and mission management system (MMS).

The HDTS supports both day and night operations and allows the pilot to easily manoeuvre the helicopter into attack positions and lock targets heads-up and eyes out.

The WMS has enhanced the helicopter’s capability to carry diverse precise strike weapons and suppressive fire munitions including a twin Hellfire launcher, and two M134 7.62mm mini guns.

The MMS includes digital mapping application (DMAP), which is managed by a touch screen graphical user interface (GUI). It enhances the situational awareness of the pilot with aircraft positions.

This post has been edited by Raddus: Feb 22 2022, 11:16 PM

Can fight with Apache?

nope..

this is light attack helicopter..

Apache is like heavy attack heli

Wow so cute

look more like a scout helipcopter...lol. like when you play Starcraft send the scout to survey landscape and prepared to lose the asset.

This post has been edited by diffyhelman2: Feb 22 2022, 11:13 PM

can fight with airwolf?

I though it is people who identify as attack helicopter.

Lmao

Apache is not an attack heli anymore but a muthaf**king Gunship

the TD A109 is a scout heli
this is a light attack heli dues to its weapons and system onboard

This post has been edited by Raddus: Feb 22 2022, 11:21 PM

berapa billion ni

RM300m+ flyaway cost

It is for surveillance and light attacks not meant for heavy attacks.

use to fight PH or DAP ?

I feel safer now

this?

10 yrs ltr we see how many engine can start

Berapa songlap

Should buy Apache

Hnnnggghhhhh

this better la, upgrade sikit

Letak kat sabah.. boleh la sergah geng sulu tu

Should buy black hawk.

with MD530G we learn how to walk first
then we run


lepas tu kene CAATSA
mampus

btw the last time, we are more favouring the Zulu Cobra then the Apache

mana pasal Mat Sabu ngan Former PTD punya statement ESSCOM lucut hak untuk pakai MD ni
beli guna bajet esscom pasal Mat Sabu ESSCOM tak dapat pakai
padan muka

akan ditempatkan kat Pahang kat sebelah kem aku ni
kem baru MAB, kalo rajin nak jenguk nanti aku try tangkap gambo hahaha

very nimble

what helicopter? I don't see anything

Better buy md 969,at least can carry some troop and can carry weapon.

This post has been edited by ledtechn: Feb 22 2022, 11:59 PM

Kek.... So cute wei.... Ok la at least can bomb pinoy

Pintu boleh cabut la
969 beat the purpose for this heli in the first place la
asal untuk QRF kat ESSCOM
ni pun bleh letak outer platform for special forces duduk

shd be enuf to counter sulu or abu sayyaf invasions.

yes should buy this to scare off the china ships in SCS.

I prefer we buy AH-1Z Viper. Better for our purposes.

salahan Mat Sabu as predicted

.
you should see Mat Sabu and former PTD statement about the heli
they said that no one wanted this heli even the ESSCOM
so MAB take the ownership of the heli instead

yea, Singapore Indonesia also have already

Why are you happy that the heli stationed near your place? heli crashes are common occurrence

kalau nak terhempas kau duduk mana pun terhempas jugak dia
Kuantan ni macam2 sortie heli ada baik dari Tentera, Polis, Bomba dan awam
jet je kurang sejak Pulatibang 3 ni tak terbang and MIG decomm

This post has been edited by atreyuangel: Feb 23 2022, 01:05 AM

More hggghn

Wah nice, 1980s helicopter.

I dont think so. If you watch airwolf, this looks like the helicopters easily shot down by airwolf

Fly with that camo? I tot that camo for land use. Greenish one for jungle.

got auto flight or not ???

This type of helicopters was always use to be an inferior copters and easily knocked out in Airwolf.

This post has been edited by Cincai lar: Feb 23 2022, 06:38 AM

Should buy this....should buy that....yes we in armed forces always look for the best. But the final say is from MOF. whetever we propose....when presented to MOF.... they will say:
Our policy is this..., hence our budget more to this.....our priority is this.... your price ceiling is just this etc in the end this is what we get.

Finally after so many controversy. Hope it served well for many years to come.

Pictured: Major Suhairi (Malaysian Army Aviation) and Keith Lacy, Lead Military Pilot (MDHI).

MD Helicopters, Inc. (MDHI) announced the initial acceptance of six MD 530G Light Scout Attack helicopters for the Malaysia Ministry of Defense via their agent Halaman Optima/ Destini Prima. The aircraft are now in transit to Malaysia for final acceptance and expected to arrive in-country by the end of the first quarter of 2022. As part of the contract eight pilots and nine mechanics from the 881st Regiment of Malaysia Army Aviation have completed forward arming and refueling point (FARP) operations training in West Texas.

Destini Prima’s Senior Vice President, Ek Sing Nguong, Lt Col RMAF (Retired) said, “We are very pleased to accept the delivery of this outstanding aircraft at MD Helicopters on behalf of the Malaysian Ministry of Defense. It is with great excitement that we are able to take this program to the next stage. We look forward to the equipment’s arrival in Kuala Lumpur to complete the in-country final acceptance training.”

The 530G is the latest in a long line of light attack helicopter configurations based on the Model 500/530 airframe. The 530G for Malaysia continues to raise the bar on performance with the integration of the Wescam L3 MX10D sensor and the Pathfinder Ares Weapons Management System from Tek Fusion. These integrated systems are used to support the Dillion M134 Mini Gun, FN Herstal Heavy Machine Gun and Rocket Machine Gun pods, and 2.75-inch Folding-Fin Aerial Rockets (guided and unguided). The aircraft provides overwhelming close-in support night or day, as well as outstanding reconnaissance capability.

MDHI Vice President of Programs, Duncan Koerbel noted, “The 530G continues to build on the outstanding history of the MDHI light scout attack platform. This aircraft brings the best value and performance in its class. Hands down. It is easy to maintain, incredibly agile, and with over 27,000,000 flight hours, mission ready. MDHI is pleased to be a part of helping the Malaysian government provide land and maritime security.”MD

When do you want to lead a bunch of officers in a T72 convoy to march down putrajaya and demand your just rewards ala Thai and Myanmar "government"?

but singapore ada Apache

Singapura bila

MOF make decision one meh ???... MOD Ministry of Defend is the head of military mah,.... every year got budget given to the ministry one mah,.

This post has been edited by Cincai lar: Feb 23 2022, 07:19 AM

Still embarrassing that North Korea has more than 60 of these while we got 6 only ....
Like sohai walk into Makro during the good old days and want to buy 1 tin of cola

On the same context , companies are now run by finance team. No longer by the subject matter expert.

Betul tu. Malaysia yang bayar income tax to sikit. Yang songlap pulak banyak. With shallow pocket can only buy this instead of Apache la like Singapoe.
Bukan salah MOF pun. Kesian our tentera.

This post has been edited by JasonTheGreat: Feb 23 2022, 07:23 AM

Issue on priority & management by top leadership (ministers).

Actually quite cute looking... like pepatung.

Ok lah...we don't need expensive choppers or fighter jets to shot at Suluks.

Good buy

MD Helicopters partnered with Elbit Systems to provide the advanced weapons and mission management capabilities to MD 530G Block II (BII) helicopter in December 2019.

Elbit Systems is a reknown Isreali Defense company.

berapa markup price for songlap?

Ya, looks very comel. Should have drawn some puppy face to complement the baby toy-like frame. These small heli sure will be popular with kids.

keyword found: elbit systems lol

when p1 p2 use all that nap maney to upgrade n producing own tanks n heli.

Flying tank

this one can blow up pilak to smitereens

Apache too overkill lar bero.

We bukannya ada issue berat sampai nak beli apache.

Lagi bagus beli scout heli, banyak kegunaan praktikal.

title is confusing.. i tot malaysia attack USA helicopters so powderful.. mana tau

love the night attack capability, found video about our pilot training in US.....

Lu jgn tanya soalan yg susah!

After all songlap budaya kami!
#ApaMaluBossKu?

Buy from kawan baik Yahudi. Why no protest from those celaka and bangsat NGOs?

Back then the Sulu rebel in Lahad Datu incident can relax at night, with this night attack heli capability, they can't sleep at all...🤪

Hope they deploy these en masse in Sabah.

....hahahha..no worries about starting engine, boss. Becoz in 10 years time, engine sudah lama hilang.

I falled in love with this Heli when I saw it in this Rambo scene

betul tuh,boss.

Masa banjir, boleh buat scouting area tengelam air. Jika ada keperluan sangat, boleh rescue VVIP atau kerabat sama.
Pembelian yang teramat berbaloi!

this is good as majority of our threats are pirates

buy apache bomb sampan ker

taliban supplier?....or donasi?....here comes... they thank US.

Boleh shelling bersih participant guna Apache load.

The only mission that I played multiple times

Singapork with F-35 say hello

What controversy?
rm2 company tu ka?

60 bijik tu brapa bleh terbang?

2014 last 4 bijik je yang terbang

For new update with hellfire launch capabilities
we only have Talon Missile

why not ask opposition MP to go and request the deals and transaction from the US Congress

this is US made military asset unlike smuggled MD500 civil version to the North Korea
all the transaction, data and agents details are recorded

tell you the truth buying US made military asset is the most transparent transaction you can ever get.

come on bro!


lain tugas, lain bidang kuasa lain doktrin!

This post has been edited by atreyuangel: Feb 23 2022, 04:10 PM

ppl been saying hi with apache for many years liao

This post has been edited by 19 Degree South: Feb 23 2022, 04:26 PM

Okay...

So, what exactly is the cause of delays all these while?

6 units cover whole mehsia?

multipurpose light halo...good for insert small special force group in the territory and get out quick while able to preform light attack to distract the enemy

kenapa warna celoreng... nak camouflage tepi pokok ke

to shoot pilak only.
Peninsular and Sarawak defense is gonna need Panzerjager battalions to stop Sinkie and Indon Leopard hordes

You airmen/gr crew dpd 881st ke?

macam lego helicopter

err mind elaborate?

This one can transform one

Actually why we buy this small mosquito helicopter? Last time in Airwolf, this is the type of heli that die first. Why can't we buy those like the Hind from Rambo 3? Those are scary AF, good luck if one is in the air near you.

This is geh. Hind is the best

some analogy there

no, that shit is OP.
