Review UGREEN All-in-One 65W GaN PD Fast Charger, 4 Ports (3 USB-C & 1 USB-A)

views

TSvoncrane
post Dec 5 2020, 09:21 PM, updated 10 months ago

Noir et fier!
*******
Senior Member
7,082 posts

Joined: Oct 2011
From: Wakanda


Hey all, so couple months ago I put up some info about the then upcoming GaN charger from UGREEN. Back then it was still being funded via Indiegogo raising about RM120K from 736 backers. I've now had the charger for a couple weeks and this is my in-depth review of the UGREEN 65W 4 Port (3 USB-C & 1 USB-A) PD GaN Charger. It is a lightweight (172g) wall charger that aims to be the only charger one needs to simultaneously charge up to 4 mobile devices. Laptops, tablets, smartphones, cameras, drones, TWS earphones, and game devices such as controllers, & the Nintendo Switch.

Attached Image

GaN chargers have been the rage for some time now. Did a bit of a shine at CES 2020 and all. However, not all GaN chargers are the same and as shown in my review video below. We need to be sure about what charger used to charge our precious and often expensive devices. Another thing to note is in order to get the full 65W out of this, I strongly recommend pairing the charger with this UGREEN USB3.1 100W Gen2 USB-C to USB-C Thunderbolt 3 10Gbps Multi-functional Cable. Yes, not all USB-C to USB-C cables are equal. Watch on to find out more and why this UGREEN charger is worth your cash.


Specifications
SKU: 70773
Model #: CD224
PCBA Structure: GaN
Total Output Power: 65W
Ports: 3 x USB Type-C, 1 x USB Type-A
Available Plug Types: US, EU, & UK
Input: 100-240V~ 50/60Hz, 1.8A Max
Output (USB-C1/USB-C2): 5V 3A/9V 3A/12V 3A/15V 3A/20V 3.25A, Max 65W
Output (USB-C3): 5V 3A/9V 2A/12V 1.5A, Max 18W
Output (USB-A): 4.5V 5A/5V 4.5A/5V 3A/9V 2A/12V 1.5A, Max 22.5W
Material: PC Fireproof Case, flame retardant rating V0
Product Weight: 172g
Product Size: 65mm x 65 mm x 31.8mm
Packaging: 1x Charger, 1X Multilingual manual

Some Supported Fast Charging Protocols
*PPS/PD3.0/PD2.0
*QC4+/QC4.0/Qc3.0/QC2.0
*Samsung Adaptive Fast Charge (AFC)
*SuperCharge Protocol (SCP)
*Huawei Fast Charge Protocol (FCP)
*Huawei Super Fast Charge Protocol (SFCP)
*Pump Express (2.0, 1.1)
*Microsoft Surface Pro/Go
*Apple 5V 2.4A
*BC1.2
*MTK

Attached Image

Noteworthy Features Include:
*Multi-protection
*Smart power diversion
*Multi-device compatibility
*High energy efficiency conversion rate
*Solidly built with flame retardant materials
*Industry-beating low-temperature operation
*Extra safety with multiple stages of protection systems against overcharging and shorts

user posted image

Some Images
» Click to show Spoiler - click again to hide... «

The 2020.12.12 year end sales is just around the corner and UGREEN's official store is offering the following deals.
1. Up to 90% off storewide
2. Additional 20% off in the first 2 hours (First come - First serve)
3. 50% OFF Voucher
4. Massive flash sales items
5. Exclusive gifts and buy one get one free deals.

The UK plug variant is currently Out of Stock. However, UGREEN has promised it will be available by Dec 10 or 12.12 at the latest. So grab your vouchers and get ready. Kindly use the links below to access the deals and item pages.. Doing a bit of analytics... Thank you. notworthy.gif

Attached Image

Purchase Links
Gearbest
Amazon
Official Lazada Malaysia Product Page (EU Plug)
Official Lazada Malaysia Product Page (UK Plug)
UGREEN 12.12 Year End Sale on Lazada
UGREEN USB3.1 100W Gen2 USB-C to USB-C Thunderbolt 3 10Gbps Multi-functional Cable

Other Noteworthy UGREEN Deals
UGREEN 1Meter USB-C to USB-A Cable USB
UGREEN USB-C to USB-C Fast Charging PD 60W Cable/Data Cable
UGREEN 3A Magnetic USB-A to USB-C Cable (Head+Cable 100cm long)
UGREEN 3Meters Upgrade Nylon USB-C Cable

UGREEN Specific URLs
Official Product Page
UGREEN Malaysia Facebook
Instagram
Twitter

This post has been edited by voncrane: Jun 19 2023, 09:32 PM
blurjoey
post Dec 5 2020, 09:24 PM

Sumo Hammy!
*******
Senior Member
6,035 posts

Joined: Jan 2003
From: Cheras, Kuala Lumpur


Aiya... you beat me to it... anyway another great voncrane review here 🤭

Attached Image
TSvoncrane
post Dec 5 2020, 09:29 PM

Noir et fier!
*******
Senior Member
7,082 posts

Joined: Oct 2011
From: Wakanda


QUOTE(blurjoey @ Dec 5 2020, 09:24 PM)
Aiya... you beat me to it... anyway another great voncrane review here 🤭

Attached Image
*
Haha... No worries, plenty of clout to go around.. I see you flexing those T1s.. tongue.gif Thanks for the compliments.. On to the next device.. biggrin.gif
