QUOTE(marcyeo @ May 24 2020, 08:05 PM)
welcome bro. it is actually much faster with the baseus 45w charger. I started it from 5%. The 25w samsung charger i started from 13%, still slower than the baseus charger. dont forget u need a 5A type c to type c cable ya
Unfortunately my latest test result not match to your video as stock 25W still perform much better Vs Baseus 45W and 65W GaN charger.
Charge Test Items
- Samsung 25W Charger (Stock).
- Baseus 65W GanN 3 Ports Charger.
- OrxnQ USB-C to C E-Marked 10Gbps/100W/5A cable.
- Samsung S20 Ultra Exynos with 5000mah battery.
Charge Test Procedures
- Phone On but Screen Off with AOD on Charging Status.
- Battery charge status from 5% to 100%
- Phone on WIFI and working conditions.
- Reused same OrxnQ cable on both Samsung 25W stock and Baseus 65W GaN chargers in order to reduce noise.
Charge Test Results
- Baseus 65W completed in ~1hr 20mins
- Samsung 25W completed in ~1hr 2 mins.
Observations
- Potential the 5W cable seem to enhance on Samsung Stock 25W charger as initially my charge performance was ~1hr 10mins range, will tried use back stock 3A cable for next test.
- Samsung 25W charger still faster than any OEM charger.
- OEM 45W or 65W unable to meet Samsung stock 25W chargers.
Thx
This post has been edited by chuah_ph: May 25 2020, 07:14 PM
