I think this answers your question.


I used to have EH10BQ hood (now changed to JQG9009) while my hob is GCG 90301 it is wider than GAG 86210 and we do not have problem with it.

The distance between hob to the wall need to follow the installation manual?
The manual recommend that the distance shall be 75 mm or more.
The problem is the kitchen top is 600 mm and does not have much clearance for the hob (GAG86210), which is 500 mm width.

Well standard installation height is 750mm from table top.

Standard table top is 600mm, the hob is 500mm, shouldnt have any problem

Thanks for your help.
Can you help to check this manual:
http://www.fotile.com.my/pdf/User_Manual/GA_series.pdf

In page 8, Figure 9-3, the side view shows that the hob needs to stay away 75 mm from the wall. Do I need to follow this dimension?
Can I let the glass of hob to touch the skirting of table top without having this 75 mm gap?

Also, need to check with kitchen cabinet contractor whether there is any space limitation for the wood frame underneath the table top. I assume they can cut a bit to suit the hob.

The cut out hole is away 75mm from wall not the hob. The reason why they recommend 75mm is in case your WOK is big, it wont be blocked by the wall.

As per my photo, my wok is kinda near the wall (mine 65 mm) if you make less than 65mm you cant use a wok of my size (42cm diameter).

Btw, mine is GCG 90301 but the cut out is same as GAG 86210 and glass is also 500mm, just my width is 900mm while GAG 86210 is 860mm. Prefer GCG over GAG for the easy cleaning design and black color design that matches well with my cabinet and hood. I have been using it about 2 years and it still look so clean and nice The new 2015 facelifted GCG 90301 looks even nicer

This post has been edited by zheilwane: May 24 2015, 09:21 AM


Attached thumbnail(s)

Thanks a lot.

Kitchen cabinet contractor confirms the cut out hole size for Fotile hob GAG86210 can be fitted to table top and it will not interfere with the underneath wooden frame. Thanks for your help, zheilwane.

have anyone used livinox hob and hood?

What type & brand of gas regulator and hose should I get for the hob?

Just the normal 1, low gas pressure one. Ask the salesperson when you are buying it is kinda standard bt some comes with insurance cost rm 100 while some as cheap as rm 20

Most welcome

oh my

what is wrong with my Rubine hood

instead of sucking, now it's blowing! Any idea how to make the motor turn the other direction?

Outlet is blocked, go outside of your house and feel the air blowing out at the end cap is it strong? if not strong, get ur installer to check. I bliv the didnt remove the flapper

This post has been edited by zheilwane: Jun 3 2015, 10:33 PM

Yes, i took out the hose and they forgot to remove the flapper!

Good Job

If you still not getting your kitchen appliances, you won't wanna miss the chance to grab our special deal for Rinnai and Pacifica. Renovation Expo at this weekend 5-7 Jun PWTC Hall4 9047.


PWTC @ Hall4 9047

Hi Zheilwane,

Will you be participating at the Renovation Expo at PWTC?

I'm looking for kitchen appliances.
Was using Lebensstil before. No too bad. But the oven was so so only.

What would you recommend?

Thanks.

Nope, not joining this time. Actually the best exhibition is still homedec, more varieties and better bargain. Well, i m selling Fotile and Rubine but i m using Fotile JQG 9009 Hood and GCG 90301 hob, while oven KES 6003a all works very well. Previously i was using EH10BQ, performance is great as well.

You won't wanna miss the chance to find out our special promo & packages on Rinnai & Pacifica Kitchen Appliances.
Find us at PWTC Hall 4 @ 9047 (5 -7 Jun 2015)

Hi Zheilwane,

Was at the PWTC exhibition. And I agree with you. Nothing much there.
But I can't wait for homeDec. Might check out the exhibition in Setia Alam next week.

Cheers.
