Newbie here,
Would like to ask about mini interconnect. If I'm using starquad cable, can I use the shielding as the ground and 2 wires for each channel or just 1 wire for each channel and the other 2 wires as the ground? Which one would be the better idea? Thanks in advance  |
|
|
|
|
|
Mar 16 2011, 02:45 AM
Return to original view | Post
#2
|
|
Junior Member
42 posts Joined: Apr 2006
|
Trying to braid at 2am according to Litz's
 Is the pattern looks ok?  |
|
|
May 11 2011, 07:23 AM
Return to original view | Post
#3
|
|
Junior Member
42 posts Joined: Apr 2006
|
QUOTE(Akuma no Hana @ May 10 2011, 12:42 PM) Hi guys, what's the name of this cable and what is the estimated price per meter for it. And where to get it? Is it available in Pasar Road, which shop if it's there? And do i need to ground it if i'm using it for for diy both iem and headphones? I see that there are four pcs of cable here so i assume that it is 2 for left channel and 2 for right without grounding. That's the stripped down Canare L-4E6S. It's available in Pasar Road but I'm not sure which shop. I got mine from a friend. You still need to ground. 2 each channel, 1 for signal and 1 for ground. The easy way: use blue as ground and white as signal line. Combine the blue lines when you are soldering at the mini jack. Here is the guide with visual aids http://www.head-fi.org/forum/thread/50729/...-step-with-pics |
|
|
Jun 25 2011, 07:54 PM
Return to original view | Post
#4
|
|
Junior Member
42 posts Joined: Apr 2006
|
QUOTE(xowangzi @ Jun 20 2011, 10:59 PM) I would like to ask about the cable that alot of LYN Forumers DIY-ERS using... Those combination of single cable blue white blue white... Can I know wads the name of it ? And also I wanna know where can I buy it ~ Canare L-4E6S. I think it's available in Jalan Pasar. |
|
|
Nov 6 2014, 09:12 PM
Return to original view | Post
#5
|
|
Junior Member
42 posts Joined: Apr 2006
|
Detachable cable mod for HD-330 with matching blue L-4E6S terminated with Sennheiser plug
 |
