Hi guys.
This is our first modification build here after we registered few days ago.
This time we bring you guys something smaller compare to our previous built/projects. Lian Li PC-Q11.
We choose Lian Li PC-Q11 over Prodigy because of smaller size and lighter feature (aluminum).
The motto is SLEeP which is Smaller, Lighter, Elegant and Powerful.
The project theme is simple, a "Small Monster."
Small yet comes with a desire to conquer the universe.
The main objective is to produces a small yet powerful enough (machine) to handles any games in future.
It s Mobility Hell.

Full specifications of the rig as below:

Processor : Intel Core i7 4770k
Motherboard : Asrock Z87e-itx
Graphic Card : Leadtek GTX 670 ref.
Ram : Corsair Dominator Platinum 1866mhz 16gb kit.
Power Supply Unit : Silverstone SFX 450w 80plus Gold Modular Form Factor.
Sleeve : Colotrail Sleeve.
Ssd : Samsung 840 PRO 512gb

Cooling : Custom Liquid Cooling System:
- Swiftech Apogee Drive 2
- XSPC Razor GTX 670
- XSPC EX240 MP
- Bitspower Multi Link C47 x 2
- Bitspower 7/16-5/8 Compression Fittings x 6
- OEM crystal link@acrylic tube - 10/8m
- Masterkleer White 7/16-5/8 tube[


This post has been edited by Mod'N'Go Design: Dec 8 2013, 11:39 AM

The 'housing' Lian Li PC-Q11
Small yet Elegant.















This post has been edited by Mod'N'Go Design: Apr 2 2013, 10:39 PM

SStone SFX 450w GOLD
A little moster to powered up the whole house.




Fully modular with 24 pins atx, 8 pins eps, 8 pins pcie and 2*6 pins for sata and molex power cables.




Side by side with Samsung Galaxy S2



This post has been edited by Mod'N'Go Design: Apr 2 2013, 10:43 PM

Parts

Processor : Intel Core i7 4770k
Motherboard : Asrock Z87e-itx
Graphic Card : Leadtek GTX 670 ref.
Ram : Corsair Dominator Platinum 1866mhz 16gb kit.
Power Supply Unit : Silverstone SFX 450w 80plus Gold Modular Form Factor.
Sleeve : Colotrail Sleeve.
Ssd : Samsung 840 PRO 512gb
Cooling : Custom Liquid Cooling System:
- Swiftech Apogee Drive 2
- XSPC Razor GTX 670
- XSPC EX240 MP
- Bitspower Multi Link C47 x 2
- Bitspower 7/16-5/8 Compression Fittings x 6
- OEM crystal link@acrylic tube - 10/8m
- Masterkleer White 7/16-5/8 tube.



This post has been edited by Mod'N'Go Design: Jul 13 2013, 05:55 PM

i7 4770k



Asrock z87e-itx











The I/O



Placement of the 8pin EPS



Ram slots, 24pins slot, usb 3.0 port and SATA slots.


This post has been edited by Mod'N'Go Design: Jul 13 2013, 06:39 PM

Shipping pakai kapal laut ker Rie~? Ekeke...
Faster, faster...more update on casing's mod... UV side panel~?

Client wants something new.
I heard it ll be released this coming June.
Side panel?
Not UV but something more astonishing compared to UV.


-Irie-

This post has been edited by Mod'N'Go Design: Apr 3 2013, 11:55 AM

The SSD






Ram










GPU

Water Cooling parts

Cpu block








Gpu Block









the backplate

Thanks bro

The radiator.








The fittings.

[/B]Tubing





Gpu +WB









Slim Fans for the rad since Gentle Typhoon cant be used due to clearance issue.





This post has been edited by Mod'N'Go Design: Aug 3 2013, 01:15 AM

Testing the rad





Ram with the mobo



We tried with GT first but then decide to replace it with SS



Psu placement



Cut few screw holes and square cut for the power cord pass trough

Panels.
Design using 2D drawing software like AI, FS and CD.
Then sent for laser cutting services.











Bend the acrylic using custom inline bender.

Bila siap ni masta?

It s complete project already.
We are sorting the images/photos for now.
quite busy lately.

Waiting.....

Fuuu expensive rig u got there

Working on the rad holder + ssd/hdd cover.
