I notice that the gap between IHS and PCB is very slim and tiny, r u sure stationary knife can delid as the blade of stationary knife is quite large.

has anyone try running IB proc without ihs?
How about temperature without ihs?
better or worse

i see..then not much we can do

my 3770k temp shooting up!! running h100 65-67 degrees stock speed wif turbo.....i tried oc to 4ghz reached 80 :3

what if we remove the ihs replace tim and use the same glue and stick it back would it void warranty?

General characteristics:

-they react to cold,20 to 0 degrees yielded about 100 mhz more at same latency
-they run very tight secondary and tertiary,basically as tight as your imc can handle,only exception is trfc which has to be in the 120-140 range for high frequency
-they react to voltage.Now comes the tricky part,as they don't react in a linear way.Basically 2400 C9 is stable for memtest with 1.64,but over 1.70 NO POST.2400 C8 will post and be stable at 1.77V.2400 C7 will post and somewhat stable for spi at 1.89
-they will not run any twcl lower than 7,but they don't have that twcl 8 bug,so twcl8 is lightly slower than twcl7
-they will run 32M about the same they can post,for example 2800C9 was 32M stable but 2860 did not post no matter what
-they are not binned,basically looks like crucial just threw random chips with no binning,one module did not boot over 2000 no matter what,other 3 did that but only 2 can run 2800 stable
-they do not have any trcd wall like good ole PSC or BBSE,2000 7-7-7,2200 8-8-8,2400 9-9-10,2600 8-9-11,2700 9-10-12,2800 9-10-13 are achievable for 32M

Testing was done using a 3570K with a powerfull imc(3160+ valid on air),Asus Maximus V gene and 0-1 degrees celsius ambient.However the bad fact is they are somewhat slower at 32M that comparative samsung 2800 9-12-12 eventhough they blow them out of the water at AIDA tests,i suspect it's either likely mobo is not tuned specially for this kind of IC's.

The new Micron D9 looks promising.



2800 9-10-13 S-pi 32M


Meet the new Spartans..err Ballistix!

Nice one. Perhaps, you should try this ram kit too, bro.

Don't ask what Vdimm is set...hehe.

Latest RAID ROM (and driver) is 12.5.x.xxxx........just apear today.

bulibulizaimon | 3570K | 4.6Ghz | Asrock Z77 Pro4-M | Air
