Network Band: GSM 850, GSM 900, GSM 1800, GSM 1900, 3G 900
Dimension: Height 123mm x Width 68mm x Thickness 11.8mm
Weight: 164g with battery
Screen Size (Diagonal): 4.3 inches (Gorilla? Glass)
Screen Resolution: 480 x 800 pixels (SHARP or AOL TFT-LCD)
Ringtone Type: Monophonic, MP3, Polyphonic
CPU: 1.0 Ghz Qualcomm Snapdragon QSD8255 processor
Internal Memory: 1.5 GB; 768MB RAM
Expandable Memory: Up to 32GB microSD (SD 2.0 compatible)
Camera: 8MP, auto focus with dual LED Flash, face detection.
Video Recorder: 720p HD video recording
Operating System: Android 2.2.1
Messaging: Email, Instant Messaging, MMS, SMS
Bluetooth: Bluetooth? 2.1 with Enhanced Data Rate & A2DP for wireless stereo headsets
WiFi: IEEE 802.11 b/g/n
GPS Hardware: Yes
Other Features: FM Radio, Dolby Mobile and SRS virtual surround sound.
Battery Capacity: 1230mAh

1.84.707.2 - Available via FOTA (Firmware Over The Air) Update - Improve system performance and Camera feature enhancements
-- tarbana90 report 1.84.707.2 fix the root exploit... proceed at your own risk...

More Info Regarding FOTA Updates Can Be Found Here

NEW!! Ori Set = Available Now through either DiGi contract, SenQ or HTC dealers: RM2000 ~ RM2290
NEW!! AP Set = Available Now (Check the Handphone Section of LYN Garage Sales): RM1600 ~ RM1700
USED!! Ori Set with registered warranty (24 months minus usage): RM1500 ~ RM1800
USED!! Ori Set without registered warranty (12 months minus usage):: RM1400 ~ RM1600
USED!! AP Set with warranty (12 months minus usage): RM1200 ~ RM1500

Note: All information above are based on time of checking (Last updated: 21-03-2011), especially @ Lowyat.net Garage Sales. Price may varies accordingly to seller, economy, etc.

Version 1 - by Cynox
Version 2 - by johnkor
Version 3 - by johnkor
Version 4 - by johnkor
Version 5 - by johnkor
Version 6 - by johnkor
Version 7 - by Cynox
Version 8 - by koinibler
Version 9 - by monza84
Version 10 - by Atsutane-Shirane
Version 11 - by Atsutane-Shirane
Version 12 - by syuki
Version 13 - by polarzbearz
Version 14 - by Calex
Version 15 - by Calex
Version 16 - by aeronchan
Version 17 - by rosalynbaby
Version 18 - by winter-X

It is TFT LCD. Although the colour saturation not as good as Amoled but the size of the screen is more than enough to compensate this little shortcoming.

The battery can last a day for moderate usage. For heavy users, get yourself a second battery or a mobile battery booster. It is definitely not a deal breaker.

For the HTC Navigation, you will receive a voucher code to select a map of a region for free, map can be pre-download to your Desire HD for navigation later. (only applicable for SiS Malaysia & HTC Singapore set).
Some popular GPS application like Papago X5 do not need a data connection for navigation purpose.

You can get the Desire HD from the following:
1. DiGi with 12 or 24 months SmartPlan contract.
2. SenQ / SenHeng
3. Other authorise dealer

1. Battery and sim card / microSD card cover – check whether it closes tightly before you open it.
2. Run some self test
a. Tap Phone
b. Key in *#*#3424#*#*
c. You can find quite a number of tests here – LED, Backlight, Vibrator, Display, Audio, Line Drawing, Button, HST status, Camera, System Info & Battery Run Down tests.
Note: This code will not work on custom ROM.
Also, for original set, remember to register your set to get 1+1 year warranty by SiS, the second year warranty only valid if you register online within 7 days of purchase.
Sis Web site: https://www.sis.com.my/siswarranty
There is an option to upload your purchase invoice online to SiS. So scan a copy of your invoice first and save into JPEG format.

REMINDER: Kindly request and print the transfer ownership form by SIS Warranty and fill it during COD. Failure to do so would mean a negation of warranty (no warranty at all), do not be tricked by those claiming that such a form is not needed.
Download ---> Transfer Ownership Form.pdf

After completing the transaction, scan/photo and upload the:-
(1) Invoice/Receipt with date of purchase clearly shown
(2) Filled Transfer Ownership Form with SIGNATURE

Mail it to SiS Warranty

1. Check packages (see below for Standard Desire HD package)
2. Check phone conditions (external)
-- Check for Scratches / dent
-- Check the phone for stickers (if original set) and make sure the sticker, where usually is affixed to the SCREW is still there.
3. For Original SIS sets
-- If possible, request IMEI before you do COD and check online via:
------- HTC Genuinity Check - Check and see if it says "Warranty in Malaysia!" or not.
------- SIS Warranty Registration - Then, go to this link and paste the IMEI, Serial no(can anyhow fill), false other informations and click NEXT. If it says "Warranty is registered under <insert name here>", your interested set is original and registered for warranty extension! (extra 1 year of warranty from date of purchase).
-- Also, during COD, don't forget and check if the IMEI provided beforehand matches the unit you receive, and matches the BOX or not.
4. Check phone conditions (internal)
-- Make calls, test speaker, camera, check LCD for dead pixel (easier with the test key below)
-- You can do some tests via "Phone > tap *#*#3424#*#*" and run some tests. NOT WORKING ON SOME CUSTOM ROM!!
-- To check if the firmware is stock or not, you can go to Menu > Settings > About Phone > Software Details and see. Custom Rom usually have different name like Android Revolution / Leedroid / Etc.
5. Make sure that receipt is provided, in case of warranty claim.
6. Basically that's all! Enjoy the second-hand unit that you bought and smile for the $$ saved

1. HTC Desire HD x 1
2. Battery x 1 (preinstalled inside the phone, need to pull it out and remove a plastic sheet before the phone can be turned on)
3. Samsung 8GB Class 2 microSD card x 1 (preinstall inside the phone) OR Sandisk 8GB Class 4 microSD card x1
4. Headset x 1
5. microUSB charge/data cable x 1
6. Charger x 1 (with SiS sticker)
7. 3-pin plug x 1
8. Warranty card x 1 (need to get dealer stamp)
9. HTC Locations Premium Navigation Voucher - small piece of paper with 12-digit code and barcode at the lower left. Refer to the instructions inside the paper on how to use it. Dun throw it away!!
10. A quick start guide and some other printed materials.
Note: The box is sealed with SiS hologram sticker. PLEASE BE CAREFUL IF THE SEAL IS BROKEN WHEN YOU RECEIVE IT, double check everything or best if possible - get a new sealed set. And there is a big SiS sticker on the left side with warranty information.

Warranty: 1+1 year warranty by SiS, the second year warranty only valid if you register online within 7 days of purchase.
Sis Web site: https://www.sis.com.my/siswarranty
There is an option to upload your purchase invoice online to SiS. So scan a copy of your invoice first and save into JPEG format.

go to location >> menu >> upgrade >> key in your voucher code - if its like forever verifying- go back to manage license and content- menu- sync license-jobs done
to double confirm u can see spore and malaysia (life cycle) under navigation

go to email menu>more>newaccount

select (POP/IMAP) for Gmail/Yahoo/Hotmail then follow the automate setting if the auto setting fail to asign then should try below manual input.
GMAIL Setting
Protocol : IMAP
Email : xxxx@gmail.com
username : xxxx@gmail.com
password : xxxxxx

IMAP Server : imap.gmail.com
Security Type : SSL
Server Port : 993

NEXT
Login Required
Username: xxxx@gmail.com
Password : xxxxxxx

SMTP Server : smtp.gmail.com
Security Type : SSL
Server Port : 465

NEXT to asign your email Name then Finish Setup
Yahoo Mail Setting
Protocol : IMAP
Email : xxxx@yahoo.com
username : xxxx@yahoo.com
password : xxxxxx

IMAP Server : imap.mail.yahoo.com
Security Type : SSL
Server Port : 993

NEXT
Login Required
Username: xxxx@yahoo.com
Password : xxxxxxx

SMTP Server : smtp.mail.yahoo.com
Security Type : SSL
Server Port : 465

NEXT to asign your email Name then Finish Setup
MSN (Hotmail) Mail Setting
Protocol : POP
Email : xxxx@hotmail.com
username : xxxx@hotmail.com
password : xxxxxx

POP Server : pop3.live.com
Security Type : SSL
Server Port : 995

NEXT
Login Required
Username: xxxx@hotmail.com
Password : xxxxxxx

SMTP Server : smtp.live.com
Security Type : TSL
Server Port : 587

NEXT to assign your email Name then Finish Setup

Your Desire HD new battery may not reach its optimum level yet. Please use the Desire HD for a few weeks first. If the battery still draining fast, perform the Battery Calibration tip in the next post, it might help.

Generally, the following will conserve your battery too:
1. Turn down the brightness of your screen. [Menu>>Settings>>Display>>Brightness]
2. Tun off sync with HTCsense.com - it is not working at the moment so dun bother sync with it at the moment. [Menu>>Settings>>Accounts & Sync>>HTC Sense>>uncheck Sync HTC Sense]
3. Change your mobile network to GSM only when you are not using data connection. [Menu>>Settings>>Wireless & networks>>Mobile networks>>Network Mode>>select GSM only]

Please do not bother with HTCSense.com as it is not working as it should now. So leave it alone and turn off your HTCSense.com at your Sync setting to conserve battery life.

This is Google Navigation which is not supported for Malaysia. To use the HTC Navigation, select Car Panel >> Navigation (with Green Arrow).

Turn on the USB Debugging Mode - Menu >> Settings >> Applications >> Development >> select USB debugging. This will solve the problem most of the cases.

Copy the MP3 ringtone to the respective folder in the microSD card:
/sdcard/alarms OR /sdcard/media/alarms
/sdcard/notifications OR /sdcard/media/notifications
/sdcard/ringtones OR /sdcard/media/ringtones

1. Clear type - excellent on screen clarity and colour saturation but will attract more fingerprint.
2. Matte type - fingerprint resistant but will affect the screen clarity or colour. However some users mention the effect is tolerable so it is personal preference.

1. Silicone/TPU casing
2. Case-mate - Barely There, Pop, Tough, Gelli and Safe Skin.
3. Otterbox - Commuter and Defender series.
4. Noreve Saint-Tropez Luxury Leather Case - can tailor made your very own case.
5. Epik Case

Belkin USB Car Charger
Basically you can use any of the USB-to-microUSB Car Charger.. even my Belkin Charger + Nokia Cable works fine

1. SANYO Mobile Booster KBC-L2B

There's two type of Bluetooth Headset - Mono or Stereo

Bluetooth Mono Headset would be something like this
Bluetooth Stereo Headset would be something like this

Note: By default, Android does not support music/audio streaming (except calls, etc) via Bluetooth Headset (MONO). But STEREO ones are supported. A fix/temporary overcome is by using BTMono, available for free in the market.
However, the outcome quality from a MONO headset is . You have been warned

DNA MicroSD Card 16GB Class 10: RM90 ~ RM150

WARNING:

To transfer your data to new MicroSD Card, do not Copy EVERYTHING and PASTE it in your NEW card via your PC, some forummers reported that your card will be unreadable by the system (Android). Do it in the following way:
1. Unmount your current SDCard. (Setting > Storage > Unmount SD Card)
2. Take it out, put the new one in
3. Let the system detect the card, and usually will auto-mount it.
4. Unmount it, and press 'Format SDCard'
5. It'll auto mount after formatting.
6. Use any method that you prefer, to transfer ALL the data from OLD SDCARD to NEW SDCARD. Since I already had my data's in my PC, I unmounted the card and put into a card reader, for a faster transfer.
7. When you are prompted to replace ANY files, DO NOT replace!! DO NOT replace any files / folder at all!!
8. You have done copying the old files to NEW SDCard, put it back to your phone and mount it, if you have to.
9. Enjoy!

Another method, recommended by lunatique

You can use a barcode scanner (eg. Google Goggles) to scan the QR code (the box with alot of dots in it) for an easy link to the app in the Market.

Free Apps (all links clickable)
1. ASTRO File Manager
2. Barcode Scanner
3. Titanium Backup - need ROOT
4. Chrome to phone
5. Gmote
6. SwipePad Beta
7. Dropbox.com for setting up account and Dropbox Android Apps
8. Shootme (for screen capture - need ROOT)
9. Handcent SMS
10. GO SMS
11. MyBackupRoot
12. Aldiko Book Reader
13. Skype
14. Dolphin Browser HD
15. WhatsApp
16. LOOK Out Mobile Security
17. Wheres My Droid
18. PULSE News Reader
19. Google Goggles
20. Maxis Movies
21. CamScanner
22. VitalPlayer
23. VitalPlayer Neon
24. Talkbox
-- if someone else got any other recommended apps, please do update me --

Free Games (all links clickable)
1. Angry Birds
2. Angry Bird Seasons
3. Super Dynamite Fishing
4. Gun Bros
5. Grave Defense
6. Hungry Shark
7. Demon Hunter
8. Words With Friends
9. Bubble Blast !
10. Bubble Blast 2
11. Shark or Die
12. Free Running
13. Pig Rush
14. Tap Tap Revenge 4
15. Mega Jump
16. Ghost Wars
17. Androidify
-- if someone else got any other recommended apps, please do update me --

backup rom = rom manager (clockwork mod)
backup image of phone = nandroid backup (also provided by rom manager using recovery startup)
backup simcard = my backup pro
backup sdcard = just copy & paste (Ctrl A and Ctrl C then Ctrl P) your sdcard into PC
backup apps + saves = titanium backup (make sure u have the exact same version of whatever apps u r using previously when restoring saves)

Swype
If you can't stand tapping the screen and always tapping the wrong button, do not fret! There's alternative in touch screen input. Instead of tapping, you do 'swiping motion' on your phone.


Simply Trace a Path

The word “quick” was generated from tracing the path shown above in a fraction of a second, by roughly aiming to pass through the letters of the word. A key advantage to Swype is that there is no need to be very accurate, enabling very rapid text entry.

Interested? Sign up for their Swype for Android Beta now before they remove it!

Source: http://www.swypeinc.com/ Currently the beta is closed, so we'll have to wait for a official release.

8Pen

1. Use the Desire HD until the battery totally flat and auto off.
2. Turn it ON and Charge for 8 hours or more with wall charger.
3. Unplug the device and Turn the phone OFF and charge for 1 hour.
4. Unplug the device Turn ON wait 2 minutes and Turn OFF and charge for another hour.
5. Use the Desire HD until the battery totally flat and auto off.
6. Turn it ON and Charge until full (NO NEED to charge for 8 hours again).
Steps 2-4 is the original steps. My DHD battery life is still the same as before after step 4. Only after I did step 5 and 6 the battery become super long lasting.

First, my laptop and DHD is connected the same WIFI network.

TURN OFF ANY FIREWALL, ON WINDOWS OR ANTI VIRUS.

on the router - Enable Universal Plug & Play

On the computer
Go to My computer > Network > Media Device > click on the device name
Media Player will launch
Go to Stream>tick " Allow remote control of my player. Please check the "More streaming Options. Make sure the "Media program on this PC and remote connection" is Allowed.

LET THIS WINDOW MEDIA PLAYER OPEN, DO NOT CLOSE IT.

On the DHD
Go to "Connected media" app, select music, photos or videos
eg.
select photos>you will see a button at the bottom called " Connected media". It will searching the media device.
go to album ( camera shots ), select any photo, then you should able to select the player.

Another Details Walkthru : Click Me!!

The following is a quick version of this guide, each setting is later explored in details.

* Manually set your focus, wait for the focus signal to turn green, keep your hand steady until the shot is taken (keep it till the preview appears)
* Make sure the camera protection glass is wiped clean
* To fix image quality: Disable digital sharpness so it’s set to -2 or reduce it to -1 if you feel its too soft but never sharpness 0, or you can later increase sharpness using external apps.
* To fix the video recording freezes: update to firmware 1.72 also make sure no apps are busy in the background (i.e. skype)
* To fix low light bad video FPS: reduce the exposure setting to -2, it will go up to 30fps, use the flash to boost the brightness back.
* To fix the green tint caused by the flash: set white balance to Fluorescent.
* To fix the changing colors while recording video indoors: set the white balance manualy. Auto is good during daylight but jumpy indoors.
* Higher ISO will always boost the camera available light, so higher ISO improves frame rate, reduces motion blur and reveals more detail in darkness.
However keep in mind higher ISO will reduce image quality since it introduces noise to the image. Auto ISO is pretty smart.
* If your photo is washed out, use the auto enhance effect from the gallery to fix levels and color balance, your photo will stay at 8MP
reference:xda-Desire HD Camera guide

ClockworkMod – also known as Clockwork and CWM – is a custom recovery for Android phones and tablets that allows you to perform several advanced recovery, restoration, installation and maintenance operations on your Android device that aren’t possible with the stock recovery.

DO NOT copy & paste everything directly!
Refer to Post #3 (Accessories Section --> Memory Card) for the full guide. With two methods

1. download chainfire3d from market
2. follow this guide

Simply put - Rooting is the process to gain the SuperUser status of the device so you can do modification to the system. Flashing ROM is like installing a different flavour of system into the device. You can do Rooting only, to be able to use certain application like Titanium Backup and Shootme, but no need to go further if you do not want to. However, if you want to Flash custom rom, then you must first Root the phone first before you can flash new rom.

Yes. Rooting and flashing will void the warranty of your Desire HD. However if you are able to flash back the original rom and UnRoot it before you send it back to HTC for warranty/service, it should not be a problem.

YOU ARE SUGGESTED TO HAVE HTC SYNC INSTALLED IN YOUR COMPUTER FIRST BEFORE PROCEEDING!!!
(Available in your SDCard\HTC Sync or download it here
------------------------------------------------------------------------------------------------------------------------------------------------------------------------
**HOW TO FLASH RECOVERY & INSTALL ROM** ~~~~~~~ assuming you did permarooted, Radio S-OFF, ENG S-OFF
If not, read syuki's guide below. Much detailed with FULL steps

------------------------------------------------------------------------------------------------------------------------------------------------------------------------

**HOW TO ROOT & FLASH** ~~~~~~~credit to syuki


------------------------------------------------------------------------------------------------------------------------------------------------------------------------

**HOW TO FLASH RADIO IMAGE**

Check your APN.
Menu >> Settings >> Wireless & Networks >> Mobile Network Settings >> Access Point Names

Example on how to use below information

DiGi

Maxis

Celcom

Alternative way for rooted phones

You can do backup by various way using this utilities;
Google >>> contact, application
Mybackup root >>> almost everything except ROM
Titanium backup >>> apps, data

You also can backup data by application;
SMS >>> SMS Backup, SMS Backup & Restore, GO sms
Contact >>> People, Google,

For easy understanding, you can watch this video and at the same time, flash kernel using Kernel Update Utility
P/S: Make sure after plugin usb cable, choose charge only. You can download the tool at Post #8..

How to downgrade 1.7x/1.8x to 1.32.405.6
Credits: Scotty2, rhcp, jkoljo and Guhl
Personally tested and work with Digi DHD, and wanna help others with new 1.84 build too. I did rewrite some part to make it more understandable, and include some missed steps.

About:
The problems started when HTC released their 1.84xxxx OTA update. That update could not be rooted, and many people got stuck in stock roms. Now a downgrade method has arrived! After this process, you can use any root (+ S-OFF) method you want. Basically your device will be just like any other Desire HD with OLDER BUILD VERSION.

System requirements:
HTC Sync (or ADB drivers)
Desire HD with build number 1.72 or higher (1.84)

How to downgrade:
IF you have a branded device, you have to make a Goldcard. Use "mmc2",
IF you dont have a branded device, Use "mmc1"
Digi machine is branded, so use "mmc2" and needed to make a GOLDCARD, check post 2.

Let's Begin,
Download the Downgrade ZIP and extract it in c:\ (C:\Downgrade)
Get stock 1.32 PD98IMG.zip ROM
Connect Desire HD to a computer. Charge only, USB Debugging enabled!
Open up a cmd and go to Downgrade folder, (can try holding shift and right click on the folder to open up a cmd to this folder)
Go to cmd execute below:

adb push psneuter /data/local/tmp
adb push misc_version /data/local/tmp
adb shell chmod 777 /data/local/tmp/psneuter
adb shell chmod 777 /data/local/tmp/misc_version
adb shell /data/local/tmp/psneuter
adb shell
If you got "#" in the result, you have temproot! Proceed:
cd /data/local/tmp
./misc_version -s 1.31.405.6

Go to your DHD, switch connection to disk,
Put PD98IMG.zip to your SD card.
You can close the cmd and set connection to disk drive.
Reboot while holding volume down, it will go to the bootloader
Follow the instructions
Done.
You can now proceed with old S-OFF methods with syuki guide and remember remove the PD98IMG.zip from your SD. I recommend Radio S-OFF for new users.

Troubleshooting:
- "Main version is older"? You did not type everything correctly. Please try it again and see if any errors come up.
- "Error opening backup file"? You did not use "Charge only" -connection, or your SD card is faulty.
- "CID mismatch/CID incorrect"? Your device is branded.

Just make a Goldcard, put the PD98IMG.zip to the card again and go to the bootloader.
- Zip will not load in bootloader? Format your SD card to FAT32, no quick format! You can try another SD.
- Problems while making Goldcard? See this post.
- PD98IMG.zip md5sum is: C3D244A9F056E48EE3851A14FF52204C

FAQ:
Q: Will I lose all my settings and applications?
- Yes, so make a backup with MyBackup Pro.
Q: I have done Radio S-OFF and SuperCID, do I need this?
- No, with those you do not need this kind of trickery.
Q: It says '#' but I still cannot use root applications!
- That is normal, this method only gives root in command line. Just go ahead and downgrade.

Credits: Scotty2, rhcp, jkoljo and Guhl

Here is a guide to downgrade from 2.37
[/SIZE][/COLOR][/B]
Special thanks to har0ld for guiding me through this

1. Create a Goldcard (I strongly recommend using the Goldcard Helper from the Android Market)

2. Download this ROM - Mirror

3. Put the PD98IMG.zip onto the root of your SDCard

4. Boot phone into Bootloader (hold volume down whilst power on), follow the steps and continue to update

5. When it has completed and your phone boots up, download stock 1.32 PD98IMG.zip ROM

6. Delete the previous PD98IMG.zip from your SDCard. Put the 1.32 PD98IMG.zip onto the root of the SDCard

7. Download the Downgrade tools

8. Connect your Desire HD to the computer via USB. Choose charge only and make sure USB Debugging is enabled

9. Open up CMD and go to Downgrade folder, execute commands:




10. If you get '#' then you have temproot, now execute commands:



11. Close CMD. Boot phone into Bootloader, follow the steps and continue to update


You will now have 1.32 which you can root & S-OFF and install custom ROMs

HOW TO MAKE A GOLDCARD

This guide explains how to create a GoldCard. A GoldCard is a special SD card which, when inserted into your device, allows you to flash RUU files with a different CID to your own device.

Requirements
Spare microSD card (any size, recommended 2GB - should be enough)
Windows PC (recommended)
ADB (part of the tools folder of the SDK, available for download here http://developer.android.com/sdk/index.html
HxD Hex Editor, available for download here http://mh-nexus.de/en/downloads.php?product=HxD
Step by step instructions
Format the microSD card to FAT32 format , allocation size 512 bytes, untick quick format. (please use normal format)
Put the microSD card in your device and boot it.
Ensure you have unzipped the SDK, then open a command prompt to the extract location. Change to the 'tools directory.
Enter 'adb shell cat /sys/class/mmc_host/mmc2/mmc2:*/cid'
You should get a very long number which looks like this: "532600bd227d9c0347329407514d5402"
Visit this page http://hexrev.soaa.me/, paste in your number and reverse it. In our example the result would be 00544d5107943247039c7d22bd002653.
Visit this page http://psas.revskills.de/?q=goldcard, enter your reversed number and create your goldcard image, which will be e-mailed to you.
Open the HxD hex editor.
If you are using Windows Vista or Windows 7, you must run the application as administrator.
In HxD hex editor,
Go to the 'Extra' menu and select 'Open Disk'.
Under physical disk, select Removable Disk (your microSD card), uncheck 'Open as Readonly' and click OK.
Note that you should select physical disk NOT the logical disk. This is important!
Go to the 'Extra' menu again and select 'Open Disk Image'. Open the goldcard image that you received by email.
You should now have two tabs - one is your removable disk, the other is your goldcard image.
Press OK when prompted for 'Sector Size' (selecting 512 (Hard disks/Floppy disks)) and click OK.
Click on the goldcard image tab.
Go to the 'Edit' menu, choose 'Select All' then select the 'Edit' menu again and select 'Copy'.
Click on the 'Removable Disk' tab.
Highlight offset (line) 00000000 to offset (line) 00000170 (including the 00000170 line), then click on the 'Edit' menu and select 'Paste Write'.
Click on the 'File' menu and select 'Save', accepting the warning.
You now have a goldcard!

Credits: MiSSigNNo, Paul

Development ROM User List

Android Revolution HD


LeeDrOiD HD


MIUI


CyanogenMod


CoreDroid


RCMixHD


Stock ROM





To uploaders :

cwteoh1 - Alor Star
banji - Gurun
Deswin - Penang
halokx - Penang
chkhoo76 - Seberang Prai
evilpuppy - Seberang Prai
algohks - Simpang Ampat
GreenSamurai - Ipoh
billy_overheat - Ipoh
stormlcc - Ipoh
soonghm98 - Ipoh
raymannlucas - Penang (Current location - Subang Jaya)

ykc - Cheras
tituslee -Cheras
lowyard - Cheras
giomanach - Cheras
adam_dkh - Cheras
eddmecha - Cheras
ramen241 - Cheras
eugenechoong - Cheras
William Yeo - Cheras
ir2shah - Ampang
Calex - Ampang
kianonn - Ampang
pluginbaby - Ampang
Syuki - Pandan Indah
InvinCibleXz - Kepong
Cloudlim - Kepong
cyjh - Petaling Jaya
ccgenius - Petaling Jaya
Ghostblind - Subang Jaya
vincemy - Subang Jaya
Old School - Puchong
dude1218 - Puchong
aberrant80 - Puchong
viruz019 - Puchong
Onizuka88 - Seri Kembangan
lunatique - Shah Alam
polarzbearz - Shah Alam
ahmadkey - Shah Alam
tjann86 - Shah Alam
aeronchan - Kota Kemuning
winter-X - Klang
ckvsck - Bandar Bukit Tinggi
karheng - Desa Petaling
Sesshoumaru - Jln Klang Lama
damhamaza -Damansara
lhongwuh - Batu Caves
YoGi BoY - Selayang
xuldigiorgio - Gombak
unclemike - Setapak
Hezegroth - Kuala Lumpur
Whykidzz - Kajang (Currently studying at Monash Sunway)
zubir2k - Kajang
Peisqo - Petaling Jaya (Currently working in Puchong)
ivn79 - Ampang (Currently working in KL)
asherapth - Kuala Lumpur
Rosalynbaby-Kuala Lumpur
Elfen_lied - Kuala Lumpur

napoli26 - Melaka
alxman - Melaka
keeycheng - Melaka
soonlee33 - Melaka
Cynox - Johor Bahru
sythersly - Johor Bahru
loobighead - Johor Bahru
desmondgasper - Johor Bahru
Kusoparty - Melaka (Currently studying at Setapak)
02286 - Melaka/Seremban
snoopy5 - Kluang Johor

katz79 - Kuala Terengganu
heLL[tuRt] - Dungun, Terengganu

koinibler - Kota Kinabalu
Reversal - Kota Kinabalu
piring - Kota Kinabalu
Sylwest - Kota Kinabalu
Monza84 - Kuching
ineser - Kuching
EternalC - Kuching
raven143 - Kuching
dlyz - Miri
terry3386 - Miri
Erote - Sarikei
rulmufc - Sabah
chiangjh - Sabah (Currently working at KL)

-

26/5/2011
-- New thread V18
-- Updated Summary for previous Thread
-- Added "How to play tegra games on DHD?" at post 5
-- Added talkbox into usefull apps

4/5/2011
-- New thread V17
-- Added more users into user list

4/4/2011
-- V14 thread closed, V15 made
-- Added more users into user list

31/3/2011
-- Added RCMixHD 5.5 into ROM list
-- Slowpoke-added CyanogenMod 7 RC3 into ROM list
-- Changed monza84's current ROM to RCMixHD
-- Changed Calex's current ROM to MIUI
-- Added CyanogenMod 7 RC4 into ROM list

29/3/2011
-- Added LeeDroid Kernel 2.2.9
-- Added new alternative text input (8Pen) method to FP

28/3/2011
-- Added lunatique's method on transferring data to new MicroSD
-- Added gathering info & summary
-- Added some quick FAQ's/Guides for MicroSD Card and Bluetooth Headset: Under Accessories section
-- Added new APN settings method by Atsutane
-- New V14 thread made, overhaul of thread done.
-- Added raven143 into owner list
-- Added zubir2k into owner list
-- Added tarbana90 into owner list

26/3/2011
-- Added some new ROMs RcMix, ARHD, LeeDroid

25/3/2011
-- Added BUZZ Kernel 1.3.8.3
-- Added REMINDER for secondhand unit buyers - fill the Transfer Ownership Form

24/03/2011
-- Customisation & Tips section finally completed @ 4am..
----- Thanks to those who helped! Especially syuki for bootanimation/splashscreen guide.

23/03/2011
-- added several users to the list!
-- added ARHD 4.0 Beta 4
--added Spike's Pure Gingerbread ROM download link - thanks koi!!

22/03/2011
-- added ramen241 to the user list
-- added couple of new download links

21/03/2011
-- added new guide/FAQ: What to check on second-hand units
-- added new download link for ARHD 4.0 Beta 3.1 - thanks koinibler!
-- changed koinibler to ARHD ROM.
-- restructured/organised user location information. grouping similar/nearby locations together
-- added 'Summary for previous Thread' and 'Archive'
-- changed lunatique from ARHD to LeeDroid ROM
-- changed monza84 from RCMixHD to ARHD ROM
-- Thread v13 prepared & modded
----- changed post locations to suit the 'flow' of information (General Info > Software Tips > Rooting, flashing, etc > The Beauties & Customisation > Log)
----- modified design for fresh look
----- fixed user list. no 113 is missing
----- added JenLOI's guide on downgrading & making Gold Card
-- initial release of HTC Desire HD Version 13 Thread

20/03/2011
-- changed koinibler from CM7 to CoreDroid Userlist
-- added JenLOI in ARHD ROM Userlist
-- added CoreDroid V4.5 download link
-- added link info about CWM on Post #3
-- added banji in Happy Owner, Regional and ARHD user list

19/03/2011
--added LeeDroid Kernel 2.2.8 download links
-- added MIUI 1.3.18 ROM download link
-- added CM7 Battery Fix Kernel #9 links
-- added Android Fonts Library download links

18/03/2011
-- changed Calex from CM7 to MIUI ROM
-- changed aeronchan from CM7 to ARHD ROM
-- changed lunatique from CM7 to ARHD ROM
-- added Spike's CM7 Build 22 ROM links

17/03/2011
-- added cwteoh1 in Happy Owner & Regional user list
-- added Spike's CM7 Build #21 download links
-- added terrence0488 in Happy Owner user list

16/03/2011
-- added ARHD 3.2 recommended radio links
-- added soonghm98 in Northen Region
-- added Android Revolution HD 3.2 ROM link
-- added links for Buzz Kernel 1.3.8.2 OC+ (1.61Ghz) / OCUV (1.2Ghz)
-- added links for LeeDroid Kernel 2.2.7 R2
-- added link for CM Kernel 1.8Ghz CFS fixed for MIUI
-- added link for MIUI 1.3.11 English ROM
-- added Onizuka88 into Happy Owner & Region user list
-- added wim1983 into LeeDroid user list
-- added ywkwy into CoreDroid user list
-- initial release of HTC Desire HD Version 12 Thread

15/03/2011
-- Added link for Buzz Kernel 1.3.8 OC+ (1.61Ghz)
-- Added link for CM7 Battery Fix Kernel #7
-- Added xuldigiorgio into Central Region
-- Added xuldigiorgio into User list
-- Added link for CM7 Spike Build #19
-- Added link for LeeDrOiD Ace V2.2.7 Kernel
-- Added winter-X into ARHD user list

14/03/2011
-- Added YoGi BoY into user list
-- Added aberrant80 into Central Region
-- Added aberrant80 into ARHD list
-- Added info regarding FOTA update for DHD
-- Added link for Buzz Kernel 1.3.8 OCUV
-- Added link for LeeDrOiD Ace V2.2.6 Kernel

13/03/2011
-- Added new screenshots by polarzbearz
-- Added viruz019 into Central Region
-- Added new screenshots by angrysnail
-- Added new instruction on how to request for screenshots @ FP
-- Change koinibler into CM7
-- Added new screenshots by Ghostblind
-- Added link for CM7 Spike

12/03/2011
-- Added luvjim into user list
-- Change aeronchan into CM7
-- Added new screenshots by syuki
-- Update link for LeeDroid 2.3.4 Beta 4 R2
-- Change lunatique into CM7

11/03/2011
-- Added ykc into RevoHD
-- Added CoreDroid 4.0 link
-- Added RevoHD 3.1 link
-- Added LeeDroid 2.3.4 Beta 3 Link
-- Added CM7 RC2 link
-- Added CoreDroid 3.2 link
-- Added radio for 1.84 base ROM
-- Added Calex new screenshot
-- Added lhongwuh into user list
-- Added link for RevoHD 4.0 Beta 2

10/03/2011
-- Added new link for Buzz Kernel 1.3.7 OCUV & OCUV+
-- Added new link for Kamma Kernel 2.3
-- Added cyjh in the happy user list
-- Change userlist request format
-- Added damhamaza in the happy user list
-- Change Calex from RevoHD to CM
-- Change syuki from LeeDroid to MIUI
-- Added polarzbearz into RevoHD

09/03/2011
-- Official Thread open for public
-- Add ahmadkey in stock rom user
-- Add Ghostblind in northern region user

08/03/2011
-- Initial Release

Poster
not yet

Version 16
Started on April 14, 4:25PM
Ended on May 4, 08:25 PM

Time Taken for next version: 484 hours (20d 4h)
--------------------------------------------------------------
Version 15
Started on April 4, 8:59AM
Ended on April 14, 5:37PM

Time Taken for next version: 248 hours (10d 8h)
--------------------------------------------------------------
Version 14
Started on March 27, 9PM
Ended on April 4, 9AM

Time Taken for next version: 180 hours (7d 12h)
---------------------------------------------------------------
Version 13
Started on 2011 March 21
Ended on 2011 March 28

Time Taken for next version: 192 hours (8d)
---------------------------------------------------------------
Version 12
Started on 2011 March 16
Ended on 2011 March 21

Time Taken for next version: 124 hours (5d 4h)
---------------------------------------------------------------
Version 11
Started on 2011 March 9
Ended on 2011 March 16

Time Taken for next version: 192 hours (8d)
---------------------------------------------------------------
Version 10
Started on 2011 March 1
Ended on 2011 March 9

Time Taken for next version: 216 hours (9d)
---------------------------------------------------------------
Version 9
Started on 2011 February 18
Ended on 2011 March 1

Time Taken for next version: 288 hours (12d)
---------------------------------------------------------------
Version 8
Started on 2011 February 4
Ended on 2011 February 18

Time Taken for next version: 360 hours (15d)
---------------------------------------------------------------
Version 7
Started on 2011 January 25
Ended on 2011 February 4

Time Taken for next version: 264 hours (11d)
---------------------------------------------------------------
Version 6
Started on 2011 January 10
Ended on 2011 January 25

Time Taken for next version: 384 hours (16d)
---------------------------------------------------------------
Version 5
Started on 2010 December 29
Ended on 2011 January 10

Time Taken for next version: 312 hours (13d)
---------------------------------------------------------------
Version 4
Started on 2010 December 18
Ended on 2010 December 29

Time Taken for next version: 288 hours (12d)
---------------------------------------------------------------
Version 3
Started on 2010 December 10
Ended on 2010 December 18

Time Taken for next version: 216 hours (9d)
---------------------------------------------------------------
Version 2
Started on 2010 November 26
Ended on 2010 December 10

Time Taken for next version: 360 hours (15d)
---------------------------------------------------------------
Version 1
Started on 2010 July 15
Ended on 2010 November 26

Time Taken for next version: 134 days (4mth 11d)
