TimelineX 3820TG & 4820TG series notebooks have several specifications. Latest batch of TimelineX 3820TG & 4820TG have latest processor, for example Intel Core i5-460M. The specifications below doesn't mean all of the features will be available. For example, not all notebooks in the series have WWAN card. TimelineX is the best ultraportable computer in it class. In fact, TimelineX excel in both performance & battery life. For me, TimelineX notebook is pure pornography.

Acer Aspire 3820TG Notebook Specifications

• Operating System
  • Genuine Windows® 7 Home Premium 64-bit
  • Genuine Windows® 7 Home Basic 64-bit
• CPU and chipset
  • Intel® Core i7-620M processor (4 MB L3 cache, 2.66 GHz with Turbo Boost up to 3.33 GHz, DDR3 1066 MHz, 35 W), supporting Intel® 64 architecture, Intel® Smart Cache
  • Intel® Core i5-430M/i5-520M/i5-540M processor (3 MB L3 cache, 2.26/2.40/2.53 GHz with Turbo Boost up to 2.53/2.93/3.06 GHz, DDR3 1066 MHz, 35 W), supporting Intel® 64 architecture, Intel® Smart Cache
  • Intel® Core i3-330M/i3-350M processor (3 MB L3 cache, 2.13/2.26 GHz, DDR3 1066 MHz, 35 W), supporting Intel® 64 architecture, Intel® Smart Cache
  • Mobile Intel® HM55 Express Chipset
• System memory
  • Dual-channel DDR3 SDRAM support:
    • Up to 4 GB of DDR3 system memory, upgradable to 8 GB using two soDIMM modules (for 64-bit OS)
• Display
  • 13.3" HD 1366 x 768 pixel resolution, high-brightness (200-nit) Acer CineCrystal™ LED-backlit TFT LCD, supporting simultaneous multi-window viewing via Acer GridVista™
    Mercury free, environment friendly
    Super-slim design
    16:9 aspect ratio
• Graphics
  • ATI Mobility Radeon™ HD 5650 with Switchable™ Graphics technology, up to 49015 MB of HyperMemory™ (1024 MB of dedicated DDR3 VRAM, up to 30676 MB of shared system memory), supporting Unified Video Decoder (UVD), OpenEXR High Dynamic-Range (HDR) technology, Shader Model 5.0, Microsoft® DirectX® 11, OpenGL® 3.1, OpenCL™ 1.1
  • ATI Mobility Radeon™ HD 5470 with Switchable™ Graphics technology, up to 35795 MB of HyperMemory™ (512 MB of dedicated DDR3 VRAM, up to 3067C6 MB of shared system memory), supporting Unified Video Decoder (UVD), OpenEXR High Dynamic-Range (HDR) technology, Shader Model 5.0, Microsoft® DirectX® 11, OpenGL® 3.1, OpenCL™ 1.1
    Dual independent display support
    16.7 million colors

    External resolution / refresh rates:
    • VGA port up to 2048 x 1536: 85 Hz
    • HDMI™ port up to 1920 x 1080: 60 Hz
    MPEG-2/DVD decoding
    VC-1 and H.264 (AVC) decoding
    Microsoft® DirectX® Video Acceleration (DXVA) application interface (API)
    HDMI™ (High-Definition Multimedia Interface) with HDCP (High-bandwidth Digital Content Protection) support
• Audio
  • Dolby® Home Theater® v3 audio enhancement, featuring Dolby® Digital Live, Dolby® Pro Logic® IIx, Dolby® Headphone, Dolby® Natural Bass, Dolby® Sound Space Expander, Dolby® Inverse Filtering, Dolby® High Frequency Enhancer technologies
    High-definition audio support
    MS-Sound compatible
    Built-in microphone
• Storage
  • Hard disk drive:
    • 160/250/320/500/640 GB or larger
  • Multi-in-1 card reader, supporting:
    • Secure Digital™ (SD)Card, MultiMediaCard (MMC), Memory Stick™ (MS), Memory Stick PRO™ (MS PRO), xD-Picture Card™ (xD)
• Webcam
  • Acer Video Conference, featuring:
    • Acer Crystal Eye webcam with 1280 x 1024 resolution
• Wireless and networking
  • WLAN:
    • Intel® Centrino® Ultimate-N 6300 a/g/n Wi-Fi CERTIFIED™ with Acer Nplify™, featuring MIMO technology
    • Acer InviLink™ Nplify™ 802.11b/g/n Wi-Fi CERTIFIED™
    • Acer InviLink™ 802.11b/g Wi-Fi CERTIFIED™
    • Supporting Acer SignalUp™ wireless technology
    WPAN: Bluetooth® 2.1+EDR
    WPAN: Bluetooth® 3.0+HS
    WWAN: UMTS/HSPA at 850/900/1900/2100 MHz and quad-band GSM/GPRS/EDGE at 850/900/1800/1900 MHz, upgradable to 7.2 Mb/s HSDPA and 5.7 Mb/s HSUPA
    LAN: Gigabit Ethernet, Wake-on-LAN ready
• Privacy control
  • BIOS user, supervisor, HDD passwords
    Kensington lock slot
• Dimensions and weight
  • 12.7 (W) x 9.25 (D) x 0.86/1.14 (H) inches (324 x 235 x 22/28.9 mm) with 6-cell battery pack 3.97 lbs. (1.80 kg) with 6-cell battery pack
  • 12.7 (W) x 9.25 (D) x 0.86/1.88 (H) inches (324 x 235 x 22/47.8 mm) with 9-cell battery pack 4.34 lbs. (1.97 kg) with 9-cell battery pack
• Power adapter and battery
  • ACPI 3.0 CPU power management standard: supports Standby and Hibernation power-saving modes
  • Power adapter
    3-pin 90 W AC adapter:
    • 5.23 (W) x 2.32 (D) x 1.22 (H) inches (133 x 59 x 31 mm)
    • 0.86 lbs. (390 g)13 with 180 cm DC cable
  • Battery
    • 66.6 W 6000 mAh 6-cell Li-ion standard battery pack
    • 99 W 9000 mAh 9-cell Li-ion standard battery pack
  • Battery life: 8 hours14, 15, with 6 cell battery pack; 12 hours14, 15, with 9 cell battery pack
    ENERGY STAR®

Acer Aspire 4820TG Notebook Specifications

• Operating System
  • Genuine Windows® 7 Home Premium 64-bit2 Genuine Windows® 7 Home Basic 64-bit
• CPU and chipset
  • Intel® Core™ i7-620M processor (4 MB L3 cache, 2.66 GHz with Turbo Boost up to 3.33 GHz, DDR3 1066 MHz, 35 W), supporting Intel® 64 architecture, Intel® Smart Cache
  • Intel® Core i5-430M/i5-450M/i5-520M/i5-540M processor (3 MB L3 cache, 2.26/2.40/2.40/2.53 GHz with Turbo Boost up to 2.53/2.66/2.93/3.06 GHz, DDR3 1066 MHz, 35 W), supporting Intel® 64 architecture, Intel® Smart Cache
  • Intel® Core i3-330M/i3-350M/i3-370M processor (3 MB L3 cache, 2.13/2.26/2.40 GHz, DDR3 1066 MHz, 35 W), supporting Intel® 64 architecture, Intel® Smart Cache
  • Mobile Intel® HM55 Express Chipset
• System Memory
  • Dual-channel DDR3 SDRAM support:
    • Up to 4 GB of DDR3 system memory, upgradable to 8 GB using two soDIMM modules
• Display
  • 14" HD 1366 x 768 pixel resolution, high-brightness (200-nit) Acer CineCrystal™ LED-backlit TFT LCD
    Mercury free, environment friendly Super-slim design 16:9 aspect ratio
• Graphics
  • ATI Mobility Radeon™ HD 5650 with Switchable™ Graphics technology, up to 4091 MB of HyperMemory™ (1024 MB of dedicated DDR3 VRAM, up to 3067 MB of shared system memory), supporting Unified Video Decoder (UVD), OpenEXR High Dynamic-Range (HDR) technology, Shader Model 5.0, Microsoft® DirectX® 11, OpenGL® 3.1, OpenCL™ 1.1
  • ATI Mobility Radeon™ HD 5470 with Switchable™ Graphics technology, up to 3579 MB of HyperMemory™ (512 MB of dedicated DDR3 VRAM, up to 3067 MB of shared system memory), supporting Unified Video Decoder (UVD), OpenEXR High Dynamic-Range (HDR) technology, Shader Model 5.0, Microsoft® DirectX® 11, OpenGL® 3.1, OpenCL™ 1.1 Intel® HD Graphics with 128 MB of dedicated system memory, supporting Microsoft® DirectX® 10 Dual independent display support
    16.7 million colors

    External resolution / refresh rates:
    • VGA port up to 2048 x 1536: 85 Hz
    • HDMI™ port up to 1920 x 1200: 60 Hz
    MPEG-2/DVD decoding WMV9 (VC-1) and H.264 (AVC) decoding Microsoft® DirectX® Video Acceleration (DXVA) application interface (API) HDMI™ (High-Definition Multimedia Interface) with HDCP (High-bandwidth Digital Content Protection) support
• Audio
  • Optimized 3rd Generation Dolby® Home Theater® audio enhancement features, including Dolby® Digital Live, Dolby® Pro Logic® IIx, Dolby® Headphone, Dolby® Natural Bass, Dolby® Sound Space Expander, Dolby® Inverse Filtering, and Dolby® High Frequency Enhancer technologies High-definition audio support
    S/PDIF (Sony/Philips Digital Interface) support for digital speakers MS-Sound compatible
    Built-in microphone
• Storage
  • Hard disk drive
    • 160/250/320/500/640/750 GB or larger hard disk drive
  • Multi-in-1 card reader, supporting:
    • Secure Digital™ (SD) Card, MultiMediaCard (MMC), Memory Stick™ (MS), Memory Stick PRO™ (MS PRO), xD-Picture Card™ (xD)
• Optical media drive
  • 8X DVD-Super Multi double-layer drive:
    • Read: 24X CD-ROM, 24X CD-R, 24X CD-RW, 8X DVD-ROM, 8X DVD-R, 8X DVD+R, 6X DVD-ROM DL, 6X DVD-R DL, 6X DVD+R DL, 6X DVD-RW, 6X DVD+RW, 5X DVD-RAM
    • Write: 24X CD-R, 16X CD-RW, 8X DVD-R, 8X DVD+R, 4X DVD-R DL, 4X DVD+R DL, 6X DVD-RW, 8X DVD+RW, 5X DVD-RAM
• Webcam
  • Acer Video Conference, featuring:
    • Acer Crystal Eye high-definition webcam, 1280 x 1024 resolution
    • Acer Crystal Eye webcam, 640 x 480 resolution
    • Acer Video Conference Manager Software, featuring Video Quality Enhancement (VQE) technology, supoprting 640 x 480 resolution online video calls
• Wireless and networking
  • WLAN:
    • Acer InviLink™ Nplify™ 802.11b/g/n Wi-Fi CERTIFIED™
    • Acer InviLink™ 802.11b/g Wi-Fi CERTIFIED™
    • Supporting Acer SignalUp™ wireless technology
  • WPAN:
    • Bluetooth® 2.1+EDR
    • Bluetooth® 3.0+HS
  • WWAN:
    • UMTS/HSPA at 850/900/1900/2100 MHz and quad-band GSM/GPRS/EDGE at 850/900/1800/1900 MHz, upgradable to 7.2 Mb/s HSDPA and 5.7 Mb/s HSUPA (for 3G models)
  • LAN: Gigabit Ethernet, Wake-on-LAN ready
• Privacy control
  • BIOS user, supervisor, HDD passwords Kensington lock slot
• Dimensions and weight
  • 13.46 (W) x 9.64 (D) x 0.94/1.13 (H) inches (342 x 245 x 24/28.8 mm) 4.65 lbs. (2.11 kg) with 6-cell battery pack
• Power adapter and battery
  • ACPI 3.0 CPU power management standard: supports Standby and Hibernation power-saving modes
  • 3-pin 90 W AC adapter:
    • 5.23 (W) x 2.32 (D) x 1.22 (H) inches (133 x 59 x 31 mm)
    • 0.86 lbs. (390 g) with 180 cm DC cable
  • 66.6 W 6000 mAh 6-cell Li-ion standard battery pack
    Estimated Battery life: 8.0 hours
  • 99.0 W 9000 mAh 9-cell Li-ion standard battery pack
    Estimated Battery life: 11.5
    ENERGY STAR®

3820TG + ATI Radeon HD 5470G Motherboard


3820TG + ATI Radeon HD 5650/6550 Motherboard


Useful Resources for Advanced Users


CPU Overclock


This post has been edited by kizwan: May 29 2011, 06:52 PM


Attached thumbnail(s)

Nice! Link to V1 discussion:

http://forum.lowyat.net/topic/1606856/



Now playing Fable 3... Running on 1366x768, let it AutoDetect graphic setting, gave me mostly High and Medium:



Again, like Dragon Age 2, cut-scene is a little jumpy but gameplay is smooth. Look like this game will keep me occupied for a looong time... I always like Fable...



This post has been edited by cowithgun: May 23 2011, 12:48 AM

Installed Catalyst 11.5a RC3 and CAP2. Didnt notice any performance changes on 3dmark06 and Street Fighter 4.

Also, tested the difference between Catalyst AI (normal/advance) vs Tweaked (Performance/Quality).

The result is: negligible in 3dmark06 and SF4. Although, I got a few more points if I DISABLE "Enable Surface Format Optimization" (only available after you tweak registry).. but again, it's negligible! Dont understand this, enabling it suppose to make it faster on certain game...)

This post has been edited by cowithgun: May 23 2011, 02:13 AM

i always let the enable surface format optimization on! but i play sf4 more smoother than b4.. but play pes11 got a bit flick when kicking ball high in the air.. like moving fast forward..

sifu lee.. i get this kinda option b4 when i early played with regedit for enable MLAA! TFQ_DEF u set 0 is it? as for EQAA set binary value to 31 00 1 will auto change to 30 00 0.. but defaults setting is 32 00 0.. this part i x faham langsung!

This post has been edited by ngkhanmein: May 23 2011, 08:35 AM

No, that one I didn' touch the regedit, after install the driver, it auto come out..
Installed modded driver though...

sifu lee.. i straight installed the driver b4 edit regedit! it show AA x4 the rest also different from urs. ur regedit messed up? how u get AF? i need enable mlaa only get those setting but notice urs got some words is missing at AAA there right? not related bout ur firepro gua.. all the same 1!

This post has been edited by ngkhanmein: May 23 2011, 11:33 AM

off topic : Yay! V2!!!

no off topic bro.. we discuss ati driver! acer laptop r using it got any problem?

I mean I off topic for that post. lol. Been quite long never touch on game, but recently when I play The Sims 3, it shows artifacts. Mine driver is 11.3 MODDED. Other games not much problem i guess.

so fast.. v2...

actually should b v2 earlier, just cowithgun lazy nia!

---

Added on May 25, 2011, 1:08 pmcowithgun.. i called dell.. they will send technician to my house.. change the fan! they asked me backup.. the gal i talked on phone just now.. she very cool.. quiet.. know bout computer as well like very experience but the way she talked v me liau this case very common lah.. this kinda feel!

This post has been edited by ngkhanmein: May 25 2011, 01:08 PM

guys need some help..
My power brick just kaput..can i claim under d warranty?
If cannot,how much it will cost n which brand is d best...

Can claim..
The best for the size, Acbel 90W, slim and light

how much bro?

Melaka here RM140, lowyat almost RM 200 ?

sifu lee.. how's ur ati driver? guess what 11.5b R5 is out!
http://support.amd.com/us/kbarticles/Pages...115ahotfix.aspx

do you install desktop version of the driver or the laptop versions from ATI? Still on v.10.8

This post has been edited by WiiPS3_74: May 26 2011, 04:27 PM

Installed, not yet test.
Tonight wil test it on Portal 2...

Laptop one..

This post has been edited by lee_what2004: May 26 2011, 07:00 PM

my bro desktop is using nvidia.. i later go b try! sifu lee.. ur option still showing weird later nite show me ya.. i will go mcd on9 buy new green cup!

This post has been edited by ngkhanmein: May 26 2011, 04:31 PM

all right thanks,downloading it tonight and testing it out later:)
