created usb extension






created fan hole for Lianli A05N front. with a nice fancy 80mm grill

---

Added on February 16, 2011, 1:00 pmIt require 16mm hole size & depth of minimum 42-43mm.

Just need to connect as per normal how you would connect a casing's power on/off switch & power led light. ( blue/green/red )
Length of cable can be customized to shorter or much longer.

---

Added on February 16, 2011, 1:04 pmmy sleeving ..







customized a back plate for TJ-07 inverted mod



This post has been edited by uglyvamp: Feb 16 2011, 01:04 PM

nice... nice macro too..

u do case mod for others?? n u from jb??

lol... uglyvamp own a shop in sim lim square sg... he mod in singapore...

yea, me shop is in SG, mod in sg.

me originally from johor, b.p. now that there's reply, i can put more pics up

lichye bro, we've the same casing. and I lov this A05 very much for the compact yet spacious size. i did a simple mod to my A05 & now able to house 8x 3.5" HDD

not so IT related. but i was contracted to a broadcasting system builder to do some jobs. this is high bandwith HDTV cable with Canare termination & cable.


custom made with canare audio cable for sound card to speaker


2tone uni sleeving


custom make Sata power cables with 18awg wires.


old watercooled rig, some of u might have seen b4, 1 of the earliest modded watercooled lianli rig to appear in LYN somewhere early 2003.
was a P4 2.0C processor & radeon 9800pro 128mb agp, 4x 256mb RD Ram ( RAMBUS ! then @ 800mhz memory )










on a side note guys, do NOTE that each psu manufacturers modular cable may use the same 6pin ( similar to pci-e 6pin ) connector to their psu.

BUT, the position of the wires : red ( +5v ), yellow ( +12v ), black ( ground ) is not always the same. Get the wrong cable, it will be disastrous. I dont know what will happen but i guess explosion

attached are some references. if anyone need help in this, i will try my best to guide u get the correct wiring.



This post has been edited by uglyvamp: Feb 18 2011, 07:13 PM

Nice sleeving. If only you are in KL area

I guess there are more to come from uglyvamp. Lot of Tj-07s.

TJ-07 sidepanel,

nice

Silverstone SG02 mod. i've done quite a few of this mod already, this one is mroe recent. ( last week )
Sidepanel modded + top added another 120mm fan hole. Fan will be using slim 15mm x 120mm fan on top of case. ( outisde ).









Sony Vaio PC mod. added top hole & cut side panel & added a small LCD thermo reader at the side.

waaaa
nice one...
how many days u take to finish mod 1 casing?

nice

so u still take orders to mod case??
coz i'm interested on A05N, but it lacks gpu cooling~
post more picture

Sony vaio case. very rare sight from a european customer. back of case has a sticker that says made in czech republic.
Upgraded from old DualCore to Sandy.







cut a small squarish hole to put a LCD thermo probe for fun.

this thread is reallly cool. hvnt been back to this section since my high school

@uglyvamp
Are you selling LCD thermo separately?

that Vaio case...very nice looking to me
wonder if there's any sold ever in garage sale

a realy mean casing modi...
two thum up...

my ex-rig, built around year 2005.

Definitely uv infested rig. my modding skill was limited at that time. so played with only colored cables.

i remember each & every one computer i build. be it my customers' or mine.

Athlon64 3000+ processor. fastest single core cpu in that era. enjoy !

Definitely 1 of the best classic example of nice UV effect case mods.
For most alluring case mod thread.
