The ram should arrived today...dont worry...coz i also waiting this ram...lolz..

hmm...

looks like my tracers running fine with 514MHz (1.03GHz)

Vista Ultimate x86 SP1 (Tweaked)

RAM: 5-5-5-15 @ 2.2v

Some Benchmarks:



Everest Ultimate 4.50.1330 Final



Haven't Stress Test it yet, will do it later.

Gonna put my rig on some serious 3D gaming session for a few hours 1st. See if its stable.

how about u guys?

post some results!

This post has been edited by BlackThyra87: Jul 24 2008, 07:13 PM

how bout da temp?
how u cool ur ram arr
mine 2.0v really hot one

imo ur sub timing is a lil loose and its actually better if u could do 1:1 rather than 5:6

This post has been edited by ham_revilo: Jul 24 2008, 09:54 PM

it went high as 54C after 6 hours of ORTHOS!


yea i just leave it auto, whenever i try to adjust it, windows will go BSOD right away.

wonder which subtiming to tweak? any guide?

try tighten ur trd, and performance level... go slowly and for me, i'll try tighten everything. make sure all the timing is tighten to the max. anyways im not that good at sub timing too. so correct me if im wrong.

tRD = Performance Level bro...

will try that.. will go down 1 by 1

well for my case, my trd automatically goes to 5, on memset when i clock my rams to 1100Mhz CL4-4-4-8... still trying to learn how to tweak this things..

http://www.tweakers.fr

i think thats the ram guys..

This post has been edited by a1098113: Jul 25 2008, 10:03 AM

yep.. anandtech pinpointed that for 800MHz strap should be able to set up to 5 tRD aka Performance Level. it has quite huge impact on memory read bandwidth.

im using the exact settings as showed. (strap 800, 5/4 divider)

its a good read!

http://www.anandtech.com/mb/showdoc.aspx?i=3208&p=5

This post has been edited by BlackThyra87: Jul 25 2008, 10:55 AM

yeah that one. i have read on it.. its a pretty good read, this is an essential for an ocer who steps on the next level of overclocking.. ram subtimings and system tweaks Thanks for pinpointing this link dude

UPDATE:

Made some tweaks on memory sub-timings and guess what?



now thats some BIG improvements! but memory write remains about the same

Tried to lower tRD to 6 but system got freezed.

and if i apply any lower than 50 in tRFC, freezed

This post has been edited by BlackThyra87: Jul 25 2008, 07:58 PM

Here is some everest ss of my rig@536fsb with not that tweaked sub timing.

@BlackThyra87,try trtp to 4,might help.

curious about ur sub timings, mind show it to us?

and what OS are u using?

here's the result after setting tRTP to 4:



not much improvement

This post has been edited by BlackThyra87: Jul 25 2008, 10:28 PM

i wish i had everest, then i can show u guys some magic

hmm..my best try so far.....

since everyone is posting their results, here's mind

so far i cant get any higher than that


@BlackThyra87
btw, actually what i meant was the trd_wr.

This post has been edited by ham_revilo: Jul 26 2008, 04:06 AM

nice bandwidth..

btw, what OS ur using? and pls state ur vDIMM/vMCH/vFSB values.

p/s: if everyone feels like posting their results, state your OS too.

This post has been edited by BlackThyra87: Jul 26 2008, 04:27 AM

no prob.

mine is:
OS: Vista Ultimate SP1
VDimm: 2.46v
Vmch: +0.2v
Vfsb: 1.425v (bios)

Don't know you can do 4ghz Don't know who say he a 24/7 non extreme ocer

tkh is always full of surprises
